Parts for Thermador RDDS30: 06 - Non-Sequence Manifold Assy Parts

The Spark Switch is an OEM part for Bosch ranges. This part ignites the burners by sending a signal to the spark module, which then produces the spark needed to ignite the gas.

Causes of a bad spark switch can include wear and tear from regular use, damage from spills or cleaning agents, or electrical issues.

Symptoms of a bad spark switch include:

• Burners not igniting
  Continuous clicking even after the knob is turned off
  No spark when attempting to ignite the burner
  The cooktop not producing a flame

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This tubing assembly routes water inside the refrigerator to the dispenser/ice system, restoring a sealed water path and reliable flow. Use it to replace cracked, kinked, or leaking tubing for better water delivery. What it does:

• Carries water from the inlet to the dispenser/ice components to enable ice and water dispensing
• Stops leaks and seepage caused by cracked or damaged tubing
• Restores proper water routing when bends or kinks restrict flow

• Tubing assembly

• Turn off the refrigerator and shut off the water supply before starting work
• Drain any remaining water from lines and have a towel/container ready for spills
• Inspect connections and use new fittings or seals if the old ones are damaged

This gas burner jet holder assembly routes fuel through the orifice to the burner and secures the connection. The red 11,000 BTU version is designated for the right-front or left-rear burner, helping restore proper flame and heat output.

• Positions the jet and routes gas from the manifold to the burner for the specified heat output
• 11,000 BTU, red-coded variant designated for RF/LR burner location
• Provides a stable, serviceable connection between tubing and burner base for a consistent flame
• Symptoms include weak or irregular flame, failure to ignite, or incorrect flame size at the RF/LR burner

• Shut off gas supply and power; allow the appliance to cool before servicing
• Remove grates, burner caps/heads, and any panels needed to access the holder
• Support gas tubing and use two wrenches on fittings to avoid twisting or damage during removal/installation
• After installation, check all joints with an approved leak-detecting solution and verify flame quality

Used to hold down the jet holder assembly.
