Parts for Bosch PGR486GDZS: 54 Grill Assembly Parts

This deflector redirects dishwasher spray to the rack and helps prevent the spray arm from hitting dishes. Replace a cracked or broken deflector to restore proper water coverage and reduce spraying issues. What it does:

• Directs wash water from the spray arm for better coverage of dishes
• Keeps the spray arm clear of obstructions so it can rotate freely
• Helps prevent water from spraying into areas it shouldn't
• Common symptom: visible damage, cracked or missing deflector causing poor cleaning or spray-arm interference

• Disconnect power and water supply before servicing
• Remove the lower rack to access the spray arm and deflector
• This deflector typically snaps or screws into place; use hand tools as needed
• Inspect spray arm and mounting area for debris or damage during replacement

This metal heat deflector mounts inside the range to redirect heat and protect surrounding components from excessive temperatures during cooking. It acts as a shield to guide hot air away from sensitive areas such as controls or adjacent cabinetry. Replace this part if it is warped, corroded, or cracked, which can lead to uneven heat distribution or damage to nearby parts.

Electrode that produces the ignition spark for gas ovens and ranges, restoring reliable burner lighting. Replace a damaged or worn electrode to stop repeated clicking, weak sparks, or burners that fail to light. What it does:

• Delivers the spark at the burner to ignite gas during startup.
• Common symptom fix: oven/range burners that won't light or that click continuously without producing a flame.
• Use when the electrode is cracked, corroded, or the ceramic insulator is damaged.
• Works as part of the appliance's ignition system alongside the spark module/igniter wiring.

• Turn off power and gas supply before beginning any service.
• Avoid touching or chipping the ceramic insulator; handle the tip carefully.
• Reconnect wiring exactly as removed and secure the electrode in the original orientation.

This compression sleeve forms the sealing ring for a 5/16-inch tubing compression joint, restoring a watertight connection when used with a matching compression nut and fitting. Ideal for stopping leaks and restoring reliable water lines. What it does:

• Creates the compression seal on 5/16" tubing when installed with a compatible compression nut and fitting.
• Stops leaks or drips at compression-style water connections.
• Used on appliance water lines (ice makers, water inlets) and other 5/16" tubing joints.
• Replaces worn or damaged sleeves that fail to hold a tight seal.

• Shut off the water supply and relieve pressure before working on water lines.
• Inspect and cut tubing squarely; slide the sleeve onto the tube before threading the compression nut and fitting.
• Tighten the compression nut per the fitting manufacturer's instructions and check the joint for leaks.
• Replace the sleeve if damaged or deformed.
