Parts for Frigidaire CFEF272DC2: 03 - Backguard Parts

This door-activated light switch controls the refrigerator interior lamp, turning it on when the door opens and off when the door closes for proper visibility and energy use. It replaces a failed or stuck door switch to restore normal light operation. What it does:

• Opens or closes the lamp circuit when the door is opened or closed.
• Replaces switches that fail to turn the interior light on.
• Fixes lights that stay on after the door is closed or never illuminate.
• Works with plunger-style door mechanisms that press the switch.

• One door-activated light switch

• Disconnect power to the appliance before servicing to avoid shock.
• Access typically requires removing the freezer/refrigerator light lens or door switch bezel.
• Test the switch for continuity before and after installation to ensure proper operation.

This replacement light lens covers and protects an interior appliance light, restoring a finished look and shielding the bulb from spills and debris. It helps maintain proper light diffusion and prevents direct contact with the bulb. What it does:

• Protects the interior light bulb from food, water and impact
• Diffuses light for more even illumination inside the appliance
• Prevents direct contact with a hot bulb to reduce burn risk
• Replaces cracked, cloudy or missing lenses that cause glare or poor lighting

• One light lens (single piece)

• Disconnect power or unplug the appliance before servicing to avoid shock
• Handle the lens carefully to avoid cracking; use a soft cloth when installing
• If the lens is held by screws or clips, save and reuse the fasteners unless replacement is required

A push-button switch that restores user control functions by completing or breaking electrical circuits. Replaces a worn or failed control switch to help restore normal operation and user input response. What it does:

• Acts as the user-operated control input to start or stop a function when pressed
• Opens or closes the electrical circuit that enables the associated control or feature
• Common symptom: unresponsive controls or functions that do not start when buttons are pressed
• May cause intermittent operation or no response if contacts are worn or corroded

• One replacement push-button switch

• Disconnect power to the appliance before attempting any service
• Use appropriate tools and basic electrical safety; avoid bending terminals or forcing the new part into place

This replacement switch restores reliable on/off control for a specific function in the appliance, helping the selected feature respond consistently when operated.

• Controls electrical power to a designated circuit or component when actuated
• Sends an on/off signal to the control or directly to the component it operates
• Failure symptoms can include no response, intermittent operation, or a switch that feels loose, sticks, or is hard to press
• May show signs of heat damage, arcing, or a burning smell near the control area when faulty

• Disconnect power at the breaker before servicing to avoid electrical shock
• Access location varies by model; remove the control panel, backguard, or front panel as needed
• Label or photograph wire positions and transfer them one at a time to the new switch
• After reassembly, restore power and test operation of the associated function

This truss-head machine screw secures a switch to its mounting bracket or panel. Replacing a worn or missing screw restores a solid, aligned switch fit for reliable operation.

• Fastens the switch body to a bracket or chassis panel
• Helps keep the switch aligned for consistent actuation
• Replaces stripped, corroded, or missing mounting hardware
• Common symptoms: loose or wobbly switch, misalignment, rattling or vibration around the switch area

• Disconnect power to the appliance before servicing
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Verify thread size and length match the original hardware
• If multiple screws secure the switch, replace them in a consistent pattern to maintain alignment

This is a #8 screw, 0.500 inch long, used to secure panels and components in appliances. It provides a correct-fit fastener for repairs where the original #8 x 1/2" screw was required, restoring proper assembly and stability. What it does:

• Fastens trim, panels, brackets and small components where a #8 x 1/2" screw is specified
• Holds parts securely to prevent rattling, gaps or loose panels
• Replaces worn, stripped or missing screws to restore proper fit
• Appropriate for common interior and exterior appliance mounting points

• Use the correct screwdriver (typically Phillips) and avoid over-tightening to prevent strip or damage
• Disconnect power and follow appliance manufacturer safety instructions when accessing internal parts

This adhesive control panel overlay is the faceplate for the electronic oven control on select ranges and wall ovens. It restores readable button labels and a clean, protected surface when the original overlay is faded, bubbled, or damaged.

• Provides printed legends for the keypad buttons and display around the electronic control (EOC)
• Protects the touch surface from wear and cleaning
• Restores a neat, easy-to-read control area
• Typical replacement reasons: peeling, bubbling, cracks, discoloration, or illegible labels

• Disconnect power to the appliance before servicing the control panel
• Remove the control panel/bezel as required to access the old overlay
• Peel off the old overlay; clean and dry the mounting surface before applying the new one
• Align with display and key locations; press from center outward to bond and smooth out air
