Parts for Ge DWXR473ET0AA: 01 - Backsplash Assembly Parts

A small mechanical release lever used with certain refrigerator ice makers to manually cycle the unit and release built ice. Helps diagnose or temporarily operate an ice maker while troubleshooting or waiting for a replacement. What it does:

• Manually trips the ice maker harvest cycle so the molded tray releases ice.
• Lets you verify the ice maker's motor/harvest mechanism is working.
• Useful for testing when ice cubes are not being ejected or the unit won't cycle.
• Can be used as a temporary workaround while diagnosing fill, temperature, or advance issues.

• One mini manual release lever

• Disconnect power to the refrigerator before accessing the ice maker to avoid shock or injury.
• Access may require removing the ice maker assembly or freezer interior panels; follow OEM instructions.
• Handle gently to avoid damaging the ice maker mold, gears, or electrical connections.
• If symptoms persist after testing, further diagnosis or a replacement ice maker module may be required.

Almond. Left hand

Almond. Right hand

Color: Almond. For white order WE1X1263. Insert included.

Size: 8-18 AB FLT 5/8.

The Control Knob and Clip is an OEM part for GE washing machines and dryers. It attaches directly to the control shaft and is used to set the machine's cycles and settings. This knob allows for easy adjustment of washing or drying operations, making it a user-friendly interface for managing the appliance's functions.

Symptoms of a bad Control Knob and Clip include:

• The knob failing to engage the control shaft, resulting in no response when turned.
• Cracks or breaks in the knob, making it difficult to grasp or turn.
• The knob slipping or spinning freely without changing settings, indicating that the clip may be worn or broken.

Causes of a bad control knob and clip can include physical damage from excessive force, wear and tear from frequent use, or degradation of the materials due to age or environmental factors.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This Rotary Start Switch is an OEM replacement part for GE dryers It is responsible for initiating the dryer's operation when the user turns the knob to the desired cycle and presses the start button. The rotary start switch is typically located on the control panel of the dryer, where the user interacts with the various settings and functions.
The GE dryer rotary start switch can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This part fixes the following symptoms:

• The dryer not starting or responding when the start button is pressed
• The start button feeling loose or not engaging properly
• The dryer starts intermittently or only when the start button is held down
• The dryer starts but immediately stops once the start button is released
• The start switch becomes unresponsive or difficult to turn
• The dryer not cycling through the different drying modes or settings

The Knob Clip is an OEM part for GE washing machines and dryers. This small but crucial component is designed to secure the control knob to the appliance's control panel.

Over time, knob clips can wear out or break due to frequent use or accidental damage. When this happens, the control knob may become loose, fall off easily, or fail to engage the control panel properly, making it difficult to set the appliance to the desired cycle or function.

Symptoms of a bad Knob Clip include:

• The control knob is loose or falls off the panel easily.
• Difficulty in adjusting settings due to a loose knob.
• The knob does not stay in place or slips when turned.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This replacement part is a screw, and it is intended for use in different types of appliances. This is a genuine replacement part made by General Electric. This screw is compatible with many different areas of the appliance. Screws are generally used for keeping parts of the machinery secure and in place during use. It is possible that screws can become loose over time and need to be replaced after years of normal wear and tear.A new screw might be needed if the user notices parts of the appliances are becoming loose or are even falling off. This can be due to screws becoming stripped over time or if the appliance is bumped during transport. The repair for this part is simple. Remove the old screw and replace it with a new part. The only tools needed for this repair are a screwdriver and possibly pliers if the damaged screw is stuck in place.This screw is sold individually and is a genuine OEM replacement part sourced from the manufacturer.

This timer controls the drying cycle by advancing through settings and routing power to the motor and heater. Replace a worn timer if the cycle won't advance, runs indefinitely, or stops unexpectedly on certain selections.

• Advances the dryer through timed/auto cycles and sets overall cycle length
• Directs power to motor and heater according to the selected program
• Coordinates cycle start/stop and end-of-cycle shutoff
• Failure symptoms include: timer not advancing, dryer runs but won't shut off, stops mid-cycle, or won't start on certain settings

• Disconnect power before servicing
• Access the timer from the control panel; retain and reuse original mounting screws
• Move wires to the new timer one at a time; label or photograph connections for reference
• Reassemble and test all cycle selections for proper advance and shutoff

Includes 12 screws. Size: 8-18 ab.
