Parts for Ge DWXR473ET1WW: 01 - Backsplash Assembly Parts

Installation instructions manual for your dryer. Replace lost, damaged, or missing setup guides to ensure proper installation and safe operation.

A small mechanical release lever used with certain refrigerator ice makers to manually cycle the unit and release built ice. Helps diagnose or temporarily operate an ice maker while troubleshooting or waiting for a replacement. What it does:

• Manually trips the ice maker harvest cycle so the molded tray releases ice.
• Lets you verify the ice maker's motor/harvest mechanism is working.
• Useful for testing when ice cubes are not being ejected or the unit won't cycle.
• Can be used as a temporary workaround while diagnosing fill, temperature, or advance issues.

• One mini manual release lever

• Disconnect power to the refrigerator before accessing the ice maker to avoid shock or injury.
• Access may require removing the ice maker assembly or freezer interior panels; follow OEM instructions.
• Handle gently to avoid damaging the ice maker mold, gears, or electrical connections.
• If symptoms persist after testing, further diagnosis or a replacement ice maker module may be required.

Snow white. Left hand

Snow white. Right hand side

Dryer timer knob control for selecting drying cycles. Replace if your original knob is cracked, broken, stripped, or missing from the control panel.

8 - 18 ab flt 5/8 sn wh

This is a plastic selector knob that comes with a retaining clip, used on the washer's control panel to select cycle settings. It attaches to the control shaft and allows you to choose wash cycles and options. Replace this knob if it is cracked, broken, or if the clip has snapped, causing the knob to spin freely or fall off the shaft.

Dryer won't start when you press the button? This rotary start switch activates your dryer cycle. Simple DIY fix in minutes with basic tools.

The Knob Clip is an OEM part for GE washing machines and dryers. This small but crucial component is designed to secure the control knob to the appliance's control panel.

Over time, knob clips can wear out or break due to frequent use or accidental damage. When this happens, the control knob may become loose, fall off easily, or fail to engage the control panel properly, making it difficult to set the appliance to the desired cycle or function.

Symptoms of a bad Knob Clip include:

• The control knob is loose or falls off the panel easily.
• Difficulty in adjusting settings due to a loose knob.
• The knob does not stay in place or slips when turned.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Replacement screw for securing dryer components like drum supports, panels, and housings. Needed when screws are lost, stripped, or damaged during repair.

Fix a dryer that won't advance, runs continuously, or stops unexpectedly. This timer controls cycle progression and power routing. 15-minute DIY repair.

Includes 12 screws. Size: 8-18 ab.
