Parts for Ge AZ58H09EADM1: 02 - Base & Chassis Parts

This pump housing cover protects and seals the appliance drain/pump assembly to help direct water flow and prevent leaks. It replaces a worn or damaged cover to restore proper drainage and reduce water under the appliance. What it does:

• Seals the pump housing so water drains through the pump instead of leaking out
• Helps maintain correct flow path for the drain system
• Common replacement for symptoms like leaks under the appliance or water pooling after cycles
• Can be needed if cover is cracked, warped, or the pump seal area is damaged

• Disconnect power and water supply before starting any repair
• Drain remaining water from the appliance and work on a dry surface
• Remove access panels and mounting hardware to reach the pump housing; keep fasteners for reassembly
• Inspect sealing surfaces and gaskets; replace any damaged seals to ensure a leak-free fit; test appliance after reassembly

This replacement fan housing secures the evaporator fan motor and blade assembly to restore proper airflow inside the freezer compartment, helping the appliance maintain consistent cooling and temperature control. What it does:

• Holds the evaporator fan motor and blade in the correct position to direct airflow across the evaporator coils
• Restores stable, quiet fan operation when a cracked or damaged housing causes vibration or rubbing
• Helps improve cooling consistency when airflow has been disrupted
• Prevents contact between the fan blade and cabinet that can cause noise or motor strain

• 1 fan housing

• Disconnect power to the appliance before beginning any repair
• Access may require removing interior panels or the evaporator cover; keep fasteners organized
• Inspect the fan blade and motor during install; replace any damaged components to prevent repeat failure
• Do not overtighten mounting screws; ensure the fan spins freely after installation

A replacement rubber O-ring that seals connections to help prevent water or air leaks and restore proper sealing performance. Use this small, flexible gasket where a worn O-ring is allowing drips or loss of pressure. What it does:

• Forms a watertight/airtight seal between joined parts to stop leaks
• Prevents water from dripping at hose, valve, or fitting connections
• Restores reliable sealing when an original O-ring is cracked, flattened, or missing
• Helps maintain pressure and proper flow by eliminating gaps

• Inspect mating surfaces and replace the O-ring only when the exact size and material match the original
• Lightly coat with food-safe silicone or the manufacturer-recommended lubricant
• Ensure the O-ring seats evenly in its groove before reassembling; avoid twisting or pinching
• Disconnect power and shut off water supply before replacing parts; follow all appliance-specific safety instructions

This wire fixing band is a small retainer clamp that secures wiring harnesses and individual wires to appliance chassis to prevent rubbing, pinching, or accidental disconnection. It helps protect wiring from damage and reduces electrical faults. What it does:

• Holds wiring harnesses and loose wires in place to prevent contact with hot or moving parts
• Reduces wear from vibration and movement that can cause frayed insulation or shorts
• Helps maintain safe routing of wires to avoid pinch points and strain on connectors
• Commonly used where a simple clipped band or strap is needed to fasten wires to sheet metal

• Inspect surrounding wiring and connectors before installation; replace damaged wires or insulation
• Secure the band to the designated chassis hole or stud without over-tightening to avoid crushing wires
• Disconnect power before accessing wiring and follow all appliance safety procedures

This D filter is the dryer lint screen that traps lint and debris from the drying drum, helping maintain proper airflow and reduce lint build-up for more efficient drying. Fits dryers that use a D-shaped lint screen. What it does:

• Captures lint, fibers and small debris to prevent them from re-entering the drum or vent
• Helps maintain airflow to avoid longer dry times and poor drying performance
• Reduces lint buildup that can contribute to overheating or vent blockages
• Works as the removable screen you clean between cycles to keep the dryer running efficiently

• One D filter

• Disconnect power before inspecting or replacing the lint screen
• Remove the old screen by pulling it out of the housing, clean the housing, then insert the replacement until it seats fully
• Clean the screen after each load; replace if cracked, warped or damaged
• If dryer still shows poor airflow after replacement, inspect the venting system for blockages or damage

A condenser plate that secures and shields the refrigerator condenser assembly for stable operation and proper airflow. Replaces a damaged or missing plate to help maintain condenser protection and consistent cooling performance. What it does:

• Secures the condenser assembly and related components to the cabinet/frame
• Protects the condenser coil from debris and physical damage
• Helps direct airflow around the condenser for efficient heat dissipation
• A failing or missing plate can allow vibration, rattling, or reduced cooling effectiveness

• One condenser plate

• Disconnect power to the appliance before starting any repairs
• Use care handling the plate—edges may be sharp
• Retain and reuse existing mounting hardware if compatible; verify hole alignment before tightening
