Parts for Frigidaire GDE546RBS0: 05 - Blower And Drive Parts

This dryer thermostat monitors internal air temperature and opens/closes the heater circuit to keep drying safe and consistent. Replacing a weak or failed thermostat restores proper heat and helps prevent overheating or nuisance shutdowns. What it does:

• Senses exhaust/heater housing temperature and switches the heating circuit based on temperature
• Helps maintain target drying temperatures for consistent performance
• Provides over-temperature protection by opening the circuit if heat rises too high
• Common symptoms include no heat or weak heat, long dry times, heat cutting out mid-cycle, or the dryer running hotter than normal

• 1 thermostat

• Disconnect power before servicing; heating components can be live and hot
• Access location varies by model; typically mounted on the heater or blower housing behind a rear or front panel
• Transfer wires from the old thermostat to the new one one-at-a-time and secure firmly; ensure the mounting surface is clean and flat
• After replacement, check and clear the venting/duct for proper airflow to prevent repeat failures

The Dryer Drum Belt is an OEM replacement part designed for use with Frigidaire dryers. This critical component is responsible for turning the drum of your dryer, allowing your clothes to tumble freely and dry evenly.

Causes of a bad Dryer Drum Belt can include wear and tear from regular use, overloading the dryer, which puts extra strain on the belt, or exposure to excessive heat, which can cause the belt to become brittle and break.

Symptoms of a bad Dryer Drum Belt include:

• The dryer motor running but the drum not turning
• Unusual noises, such as thumping or squealing, coming from the dryer when it is running
• The dryer not starting at all, in some cases

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models, ensuring a wide range of users can benefit from its reliable operation.

NOTE: Please note that this dryer drum belt is sold individually. Any additional parts or hardware will require additional purchases.

This replacement screw secures appliance panels and components. With a #10-16 thread and 0.75-inch length, it replaces stripped, rusted, or missing hardware to restore a tight, rattle-free fit and reduce vibration and noise.

• Fastens cabinet panels, brackets, or internal parts in washers and dryers
• Direct replacement for worn or lost screws to keep assemblies aligned and secure
• Helps address loose/vibrating panels, rattling noises, or visible gaps/misalignment
• Spec: #10-16 thread; 0.75-inch length

• Disconnect power; for washers, also shut off water supply
• Match the original screw location; start threads by hand to prevent cross-threading
• Use a driver that fits the screw head properly; tighten snugly without overtightening

This hex head screw spacer is a replacement threaded fastener that secures and spaces components while cutting its own thread in softer mating material for a tight fit. It's useful for repairs where the original spacer screw is missing or damaged. What it does:

• Acts as a spacer and fastener to hold panels, brackets, or assemblies at a set distance
• Thread-cutting tip forms secure threads in compatible materials for reliable engagement
• Helps stop movement or vibration of connected parts that can cause noise or wear
• Commonly used where the original hex-head spacer screw is corroded, stripped, or broken

• Use the correct screwdriver or wrench on the hex head to avoid rounding the fastener
• Start threads straight and apply steady pressure; do not force if resistance indicates misalignment
• Use appropriate torque — overtightening can strip the formed threads or damage parts
• Wear eye protection and follow appliance power/disconnect safety before servicing

No.8 pan head `10 - 10b x 0.50 `cr/sq drive
