Bosch 00187527 Door Spring (Gm 276) OEM Part

Product Details

Genuine Bosch part. Bosch brands include Bosch, Thermador, Gaggenau, and others. See all items in Dishwasher Spring.

Cross Reference Information

Part Number 00187527 replaces AP3196080, 00182640, 1096936, 182640, 187527, AH3440300, EA3440300, PS3440300, PS8698196.

Description

This dishwasher door spring counterbalances the door's weight for smooth, controlled opening and closing. Replacing a worn or broken spring restores proper door tension and helps prevent the door from dropping quickly or feeling heavy.

• Provides tension to counterbalance the dishwasher door during opening and closing
• Helps prevent the door from slamming open or feeling overly heavy
• A weakened or broken spring can cause uneven door movement, squeaks, or the door not staying in a partial-open position
• Restores smooth, even door operation when replaced

Install notes:

• Disconnect power and turn off water supply before servicing
• Remove the toe-kick and carefully slide the dishwasher out to access the side/frame area where the spring attaches
• Note the original spring attachment points and orientation; install the new spring in the same locations
• Springs are under tension—use caution and hand protection; many replace both springs together to maintain balanced tension
