Parts for Maytag JGD3430BB00: 03 - Burner Box Parts

This replacement drip tray catches and channels excess water beneath the appliance to help prevent puddles and floor damage. It restores the original drain path so condensate and minor leaks drain safely away. What it does:

• Collects and directs water away from the appliance base to prevent pooling on the floor
• Helps contain leaks from defrost or drain systems to limit damage to surrounding areas
• Can reduce musty odors and water stains caused by trapped moisture
• Fits into the appliance base to restore original water collection and drainage

• One drip tray

• Disconnect power to the appliance before servicing
• Remove lower access panels or kickplate as needed to access the tray
• Align the tray with the chassis rails or mounting tabs and slide or snap into place
• Inspect surrounding seals and drain paths; if you find corrosion or other damage, replace those parts as needed.

This spark module controls ignition for four surface burners and provides automatic reignition if a flame goes out. It generates the high-voltage spark and monitors flame for dependable lighting and consistent cooktop performance.

• Generates high-voltage pulses to ignite up to four surface burners
• Senses flame presence and automatically re-sparks if a flame is lost
• Helps stop sparking once flame is detected to reduce clicking
• Symptoms this part is involved with include: no spark on any burner, intermittent or weak spark, or continuous clicking after lighting

• Disconnect power and shut off gas before servicing
• Access is typically under the cooktop or behind a panel; mount the module securely away from heat and moisture
• Transfer wires one at a time to matching terminals; ensure ground/neutral connections are secure for proper flame sensing
• After reassembly, restore power and test each burner for ignition and that clicking stops when flame is present

The Screw is an OEM part for Whirlpool cooktop. It is a small yet vital component that joins together other parts of the range to create a cohesive appliance. The screw is responsible for tightly securing internal components like the oven cavity walls, heating elements, and outer door during operation.

Causes of a bad screw can include wear and tear over time due to repetitive heating and cooling cycles, or damage from handling that results in bending or stripping of the threads.

Symptoms of a bad screw include:

• Detached or damaged internal range components
• Issues with the door like misalignment or inability to latch securely
• Improper heat circulation and hot or cold spots in the oven
• Component malfunctions if mounting positions are compromised

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This manifold pipe assembly distributes gas from the oven's main supply to the cooktop burners, restoring proper fuel flow and consistent burner operation. Designed as a direct-replacement supply pipe for 30" gas ranges. What it does:

• Channels gas from the range inlet to each burner valve for normal ignition and flame
• Restores consistent burner flames and heat when the manifold is cracked, clogged, or leaking
• Can address symptoms such as burners failing to light or uneven/weak flames
• Works with the range's valve and burner assembly to maintain proper fuel routing

• One manifold pipe assembly (30")

• Turn off the gas supply and disconnect power before any service
• Use approved leak-detection methods after installation; never use open flame to test for leaks
• Inspect related valves and fittings for damage; replace any worn seals or gaskets as needed

This gas pressure regulator controls and stabilizes incoming fuel supply to the appliance's burner system, helping ensure consistent flames and reliable operation. Replace it if pressure is unstable or burners/oven won't heat or ignite correctly. What it does:

• Reduces household gas supply to the appliance-rated pressure for proper burner performance
• Maintains steady pressure as burner demand changes to prevent over/under-firing
• Helps prevent yellow, lifting, or flickering flames and sooting caused by pressure issues

• 1 gas pressure regulator

• Shut off gas supply and disconnect power before servicing
• Observe flow-direction arrow on the regulator body; install between supply and appliance manifold
• Use approved gas-rated thread sealant on threaded connections; do not overtighten
• After installation, check all joints for leaks with a non-corrosive leak-detection solution; correct any leaks before use

Gas valve shaft seal.

This wire harness connects multiple electrical components to the appliance's control system, restoring reliable power and signal routing for proper operation. It replaces a damaged or worn harness to help fix intermittent power, non-working controls, or component failures. What it does:

• Routes power and signals between the control board and internal components
• Replaces frayed, broken, or heat-damaged wiring that can cause intermittent operation
• Helps resolve symptoms like controls or lights not responding, error codes, or appliances failing to start
• Maintains proper electrical connections to prevent arcing and short circuits

What's included:

• One wire harness assembly as shown

Install notes:

• Disconnect power and, if applicable, gas supply before starting work
• Compare the replacement harness to the original to ensure connector types and lengths
• Route wires away from heat sources and moving parts; secure with existing clips or ties

This gas surface burner valve regulates fuel flow to a cooktop or range burner for safe ignition and smooth flame control. Replace a worn or sticking valve to restore consistent flame adjustment and reliable knob operation.

• Regulates gas to the surface burner; opens/closes as the control knob is turned
• Helps resolve no-flame or no-ignition conditions when sparking is present
• Restores proper flame adjustment from low simmer to full boil
• Addresses stiff, seized, or inconsistent valve action at the knob

• Disconnect electrical power and shut off the gas supply before servicing
• Remove the knob and access the manifold to detach the old valve; note tubing and orientation
• Transfer any mounting clip or fittings from the original valve if required by your model
• After reassembly, check all connections with an approved leak-detection solution and verify burner operation

A replacement surface burner valve that controls gas flow to a cooktop burner for consistent flame and heat. Restores proper burner response so burners light and adjust as expected. What it does

• Regulates gas flow to a single surface burner so flame size responds to the control knob
• Helps resolve a burner that won't light or produces little or uneven flame
• Replaces a worn or faulty valve that causes inconsistent temperature during cooking
• Use with the corresponding manifold and control knob assembly for full operation

• One burner valve (surface)

• Turn off gas supply and disconnect power before servicing; follow all safety procedures
• Inspect connections and fittings for proper sealing; check for leaks after installation with a soap solution
• Handle components carefully to avoid damage to valve ports and threads

This burner valve controls the flow of gas to a single surface burner, restoring proper burner ignition and heat control. It's a direct-replacement gas valve that helps fix intermittent or no-flame burner operation. What it does:

• Regulates gas flow to one surface burner so the burner lights and the flame responds to the control knob.
• Replaces a valve that is stuck, leaking, or not allowing gas through, which can cause a burner to fail to light or produce a weak/unsteady flame.
• Works with pilot/ignition systems to ensure consistent ignition when the knob is turned.
• Helps eliminate clicking or continuous sparking caused by failed gas delivery (when ignition sequence is otherwise OK).

• One burner valve

• Turn off the gas supply and unplug the appliance before starting any work.
• Verify valve orientation and connections match your appliance.
• Use approved fittings and check all gas connections for leaks with a soap solution or gas leak tester after installation.
• Do not attempt repairs if you smell gas; ventilate the area, avoid open flames.
