Parts for Kenmore 790.36909905 (79036909905, 790 36909905): Burner Parts

This replacement tube routes defrost and condensation water from the freezer/refrigerator to the drain system, helping prevent leaks and ice buildup in the cabinet. It's a simple, direct replacement that restores proper water flow. What it does:

• Channels defrost and condensate water into the refrigerator drain system to prevent pooling
• Helps stop visible leaks and water pooling inside the fresh food or freezer sections
• Reduces risk of ice buildup from trapped melt water in the cabinet
• Works with the factory drain path and drain pan to maintain normal condensation removal

• One replacement tube

• Inspect and clean the drain passage before installing to ensure proper flow
• Secure tube to existing fittings/clips; do not force or over-bend the tube
• Turn off power to the appliance before accessing internal components

If your burner won't light or the flame is too high or too low, this gas valve controls flow to restore proper ignition and flame adjustment on your cooktop.

Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.

Replacement surface burner head for gas ranges and cooktops. Distributes gas through precision ports for even flame. Needed when original is clogged, damaged, or corroded.

Replacement burner head for gas ranges and cooktops. Mounts over the orifice to distribute flame evenly. Needed when original is cracked or damaged.

Replaces a cracked, corroded, or damaged burner on your gas range or cooktop. Installs on top to restore the heat source for your cooking zone.

Replacement gas burner for ranges and cooktops. Restores even flame distribution when original is clogged, damaged, or worn from boilovers and daily use.

Ignitor orifice assembly installs near the burner valve on gas cooktops. Replace this part if the original is cracked, corroded, or missing components.

This ignitor orifice assembly delivers and meters gas to the oven/range ignitor so burners light reliably. Replace a damaged or clogged assembly to restore consistent ignition and proper burner lighting on compatible gas appliances. What it does:

• Routes and meters gas flow to the ignitor so the burner can light
• Supports consistent ignition timing for oven and range burners
• Commonly used when an oven won't light, has weak or uneven flames, or ignition failures occur
• Helps prevent gas leaks by providing a secure connection when installed correctly

• Disconnect power and shut off the gas supply before starting any work
• Only install on compatible appliances; follow the OEM instructions
• Hand-tighten connections and check for leaks with a soapy-water solution after restoring gas

Combines spark igniter electrode with orifice holder for gas surface burners. Replace when cracked, broken, or no longer securely holding components in place.

This component creates the spark to ignite gas burners and includes the gas orifice for proper fuel delivery, located beneath each surface burner. Replace if the burner won't light, takes excessive time to ignite, or produces an irregular flame pattern.

A direct-replacement tube that routes fluid inside the appliance to restore proper flow and help stop leaks from a damaged or cracked line. Use this tube when the original is broken, split, or degraded. What it does:

• Replaces a damaged internal tube to re-establish fluid flow and routing
• Helps stop leaks caused by cracks, holes or brittle tubing
• Prevents intermittent flow problems tied to collapsed or kinked lines
• Restores proper operation of the system components the tube connects

• One replacement tube

• Inspect the tubing path and fittings before installing; replace any damaged clamps or connectors
• Disconnect power and water supply (if applicable) before starting work
• Cut tubing squarely and seat fully into fittings; use new clamps where required

Regulates gas pressure from your home's supply line to the range burners. Replace if cracked, leaking gas, causing whining noises, or damaged threads.

This is a gas safety valve that controls the flow of gas to the oven burner. It works in conjunction with the oven igniter - when the igniter reaches the proper temperature, the safety valve opens to allow gas to flow and ignite. Replace this valve if your oven does not heat, the igniter glows but gas never flows to the burner, or you smell gas when the oven is turned off.

Replace a cracked, worn, or damaged electric range surface burner element. Installs in the cooktop receptacle to restore a functional heating zone.

Oven won't light or ignites with a loud pop? A faulty igniter is usually the cause. Simple DIY fix—disconnect two screws and wire nuts to replace.

Fixed natural gas orifice that meters fuel to cooktop or range burners. Replace worn, damaged, or incorrect orifices to restore proper flame size.

Burner orifice regulates gas flow to your range burners. Replace if clogged with debris, corroded, or damaged to restore proper combustion and heat output.

Burner orifice controls gas and air flow to cooktop burners. Replace if cracked, corroded, or when converting between natural gas and propane fuel types.

Burner orifice for gas ranges and cooktops. Controls gas flow to burner. Replace if cracked, corroded, or when converting between natural gas and propane.

Secures gas valve assemblies and mounting brackets to your range. Replace if screw is stripped, missing, or corroded to keep valve hardware stable.

Replacement mounting screw for ovens and ranges. Secures panels, brackets, and components. Order a new screw if yours is stripped, missing, or damaged.

Replace a damaged or frayed range wire harness. This internal wiring component connects electrical systems inside your range. Order when wires are cut or worn.

This is a wiring harness that routes electrical connections between the control board, heating elements, switches, and other components inside the range. It ensures proper power distribution and signal communication throughout the appliance. Replace this harness if you experience intermittent heating, error codes, or if the wiring shows signs of heat damage, melting, or broken connectors.

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.

Converts your range between natural gas and propane fuel types. Includes orifices and parts needed to safely reconfigure gas burners for proper operation.

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation
