Parts for Kenmore 790.46629504 (79046629504, 790 46629504): Burner Parts

This replacement tube routes defrost and condensation water from the freezer/refrigerator to the drain system, helping prevent leaks and ice buildup in the cabinet. It's a simple, direct replacement that restores proper water flow. What it does:

• Channels defrost and condensate water into the refrigerator drain system to prevent pooling
• Helps stop visible leaks and water pooling inside the fresh food or freezer sections
• Reduces risk of ice buildup from trapped melt water in the cabinet
• Works with the factory drain path and drain pan to maintain normal condensation removal

• One replacement tube

• Inspect and clean the drain passage before installing to ensure proper flow
• Secure tube to existing fittings/clips; do not force or over-bend the tube
• Turn off power to the appliance before accessing internal components

If your range burner won't light, stays on high, or has weak flames, the top burner valve may be faulty. This part controls gas flow to surface burners.

If your burner won't light or the flame is too high or too low, this gas valve controls flow to restore proper ignition and flame adjustment on your cooktop.

The igniter switch and harness assembly is the wiring and switch set that sends an electrical signal to the igniter when you turn a burner knob on your gas range. It connects the control knobs to the spark module, triggering the clicking sound and spark that lights the burner. Replace this part if a burner won't spark, sparks continuously on its own, or if clicking persists even after the burner is lit.

Mounting bracket for range installation. Secures and stabilizes your appliance. Replace if bent, cracked, or missing to ensure proper support and alignment.

Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.

For 5k burner.

This orifice holder directs the proper amount of gas to your range's surface burner for optimal flame control. It houses the gas orifice that regulates fuel flow and may include the ignition system for lighting the burner. Replace this component if your burner won't light, has an irregular flame pattern, or produces a yellow instead of blue flame.

Secures gas valve assemblies and mounting brackets to your range. Replace if screw is stripped, missing, or corroded to keep valve hardware stable.

Replacement 10-24 x 3/8 machine screw secures panels, brackets, and trim in ranges and ovens. Replace missing, stripped, or damaged screws.

This is a wiring harness that routes electrical connections between the control board, heating elements, switches, and other components inside the range. It ensures proper power distribution and signal communication throughout the appliance. Replace this harness if you experience intermittent heating, error codes, or if the wiring shows signs of heat damage, melting, or broken connectors.

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.
