Parts for Kenmore 790.32553411 (79032553411, 790 32553411): Burners Parts

Burner not lighting or knob won't turn? This gas cooktop surface burner valve controls gas flow to individual burners. Moderate DIY repair.

This gas burner valve controls the flow of gas to a 1,800 BTU surface burner on your cooktop. It features a red stem and regulates gas delivery when you turn the corresponding knob. Replace this valve if the burner won't ignite, produces an uneven or weak flame, leaks gas, or if the knob turns without adjusting the flame.

Can't turn burner off or on? Burner won't light or adjust heat? Your gas cooktop burner valve likely needs replacement. DIY-friendly repair in under 2 hours.

Burner won't light, turn off, or reaches wrong temperature? This gas cooktop valve controls fuel flow to each burner. Moderate DIY difficulty repair.

This electromechanical switch assembly controls a specific user or internal function and restores reliable on/off or selection response. Replace a worn or damaged switch assembly to regain proper control and appliance usability. What it does:

• Acts as the electrical switching component for the appliance control circuit
• Enables user input to be registered (on/off or selection) and sent to the control system
• Common symptom: appliance won't respond when a control is pressed or switched
• Common symptom: intermittent or non-working control operation, no clicking or circuit continuity when activated

• Disconnect power before accessing or replacing the switch to avoid shock
• Access panel or control bezel removal may be required
• Handle wiring connections carefully; match terminals and secure connectors

Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.

Mounting bracket that secures cooktop components to the cabinet frame. Replace if bracket is cracked, bent, broken, or missing to restore alignment.

Replacement surface burner head for gas ranges and cooktops. Distributes gas through precision ports for even flame. Needed when original is clogged, damaged, or corroded.

Replacement burner head for gas ranges and cooktops. Mounts over the orifice to distribute flame evenly. Needed when original is cracked or damaged.

Replaces a cracked, corroded, or damaged burner on your gas range or cooktop. Installs on top to restore the heat source for your cooking zone.

Replacement gas burner for ranges and cooktops. Restores even flame distribution when original is clogged, damaged, or worn from boilovers and daily use.

This assembly combines the spark igniter and orifice holder for a 9,500-BTU cooktop surface burner. The igniter creates the spark to light the gas, while the orifice holder meters the correct gas flow to the burner. Replace this assembly if the burner won't ignite, clicks without lighting, or produces an uneven or weak flame.

This ignitor orifice assembly replaces the oven burner mounting that holds the igniter and gas orifice, restoring reliable ignition and helping the oven light consistently for proper baking and broiling. What it does

• Secures the igniter and gas orifice at the oven bake/broil burner for proper ignition.
• Directs gas flow to the igniter so the burner lights reliably.
• Can resolve symptoms such as the oven failing to light, delayed ignition, weak or uneven flame, or intermittent burner operation.
• Works with the oven's gas valve and igniter to support consistent heating cycles.

• Turn off electrical power and shut off the gas supply before starting work.
• Handle the igniter and ceramic components carefully—avoid dropping or touching fragile surfaces.
• After installation, check all connections and test for gas leaks (use a soap solution; do not use open flame).

This ignitor orifice assembly directs gas flow to the oven/burner igniter for reliable ignition and consistent flames. It replaces worn or clogged orifice parts to restore normal ignition performance. What it does:

• Regulates and channels gas to the igniter so the burner/oven will light
• Helps produce a steady, consistent flame for proper cooking temperatures
• Common repair when a burner or oven fails to ignite or has weak flame
• Prevents irregular ignition caused by damaged or blocked orifice passages

• One ignitor orifice assembly

• Turn off the appliance power and shut off the gas supply before starting
• Inspect fittings and seals for damage and test for leaks after installation (use approved leak-detection methods)
• Use appropriate tools and follow the appliance service manual for removal and reassembly

If your gas cooktop won't light or has delayed ignition, this ignitor orifice assembly restores the spark electrode and gas orifice for reliable starts.

Tube component for gas cooktops. Installs internally to route gas or connect burner components. Replace if cracked, damaged, or missing to restore proper fit.

Fix burners that won't light or have weak flames with this gas cooktop burner tube. Delivers gas from valve to burner for proper heat distribution.

This replacement tube routes water from the refrigerator's supply to the ice maker and dispenser so the ice maker fills properly and the dispenser delivers water. It restores proper water delivery when the original tube is cracked, bent or clogged. What it does

• Carries water from the internal supply line to the ice maker and dispenser
• Replaces cracked, kinked or deteriorated tubing that can restrict flow or leak
• Helps stop intermittent filling or slow water flow to the ice maker
• Prevents leaks and water damage caused by split or brittle tubing

• Disconnect power and shut off the household water supply before starting.
• Remove interior panels as needed to access the tubing and note routing before removal.
• Use proper fittings and tighten to OEM torque; replace any worn O-rings or clamps.
• After installation, restore water and power, then check all connections for leaks and verify ice maker/dispenser operation.

Gas cooktop burner tube that connects the gas valve to the burner assembly. Replace if cracked, corroded, or showing signs of gas leakage or wear.

Replacement tube for gas cooktops. Installs in the burner assembly to direct gas flow. Order a new part if your current tube is cracked or damaged.

Regulates gas flow and pressure to your cooktop burners. Replace if damaged, worn, or if gas won't flow properly through the regulator assembly.

Replace worn cooktop shaft bushings to reduce friction and restore smooth operation. This sleeve supports rotating components for quiet performance. Confirm fit with your model number.

Converting your gas cooktop from natural gas to liquid propane? This LP conversion kit includes all orifices and components needed for safe burner operation.

This genuine replacement screw secures appliance panels, brackets, or trim. Use it to replace a missing, stripped, or rusted fastener and restore a tight, rattle-free fit so components stay properly aligned during operation.

• Holds panels, brackets, or trim securely in place
• Replaces damaged, rusted, or missing hardware
• Helps resolve loose or rattling panels and misalignment
• Maintains proper assembly and stability during use

• Disconnect power; for gas appliances, also shut off the gas supply
• Start threads by hand to avoid cross-threading; use the correct driver
• Do not overtighten to prevent stripping threads or damaging panels
• Repair or replace the mating clip/insert before installation

This bracket provides a secure mounting point for the appliance's internal or external component, restoring proper alignment and support. Replaces worn, bent, or broken brackets to reduce vibration and prevent loose panels. What it does:

• Secures panels or components to the appliance frame for stable operation
• Restores proper alignment to eliminate rattling or shifting parts
• Prevents stress on adjacent fasteners and components that can cause wear
• Serves as a direct replacement for the OEM bracket when damaged

• Bracket

• Disconnect power and water before beginning any repair
• Use the correct-size fasteners and mounting holes; do not force the part into place
• Wear gloves to protect hands from sharp edges and use caution when handling metal parts
• After installation, verify panels/components are aligned and the appliance operates normally

A simple metal mounting bracket that secures appliance components and keeps them aligned for reliable operation. Replaces a worn or damaged bracket to restore proper support and reduce rattling or movement. What it does:

• Provides a secure mounting point for internal components such as panels, assemblies, or modules
• Keeps parts aligned to prevent rubbing, vibration, or noise during operation
• Restores proper support when an original bracket is bent, cracked, or broken
• Helps maintain safe spacing and positioning of components to avoid interference

• One mounting bracket

• Disconnect power to the appliance before beginning any repair
• Use basic hand tools (screwdriver, nut driver) as required; retain original fasteners unless replacement is specified
• Handle edges carefully—brackets and surrounding sheet metal can be sharp

Wiring harness for cooktops. Connects electrical components within the cooktop assembly. Replace if wires are frayed, connectors are damaged, or broken.
