Parts for Ge CDB36LP2PHS1: Cabinet 1 Parts

Interior light not working when door opens? This light switch controls refrigerator illumination. DIY-friendly install takes 30-45 minutes with video.

This standoff LED board secures the appliance's LED light assembly, keeping the LED panel properly positioned for reliable interior illumination. It replaces a damaged or loose standoff to restore correct light mounting. What it does:

• Secures the LED board to the appliance housing so the light stays aligned
• Helps prevent rattling or intermittent contact from a loose mount
• Restores proper positioning after impact or wear
• Compatible where the OEM standoff is used to support the LED assembly

• Disconnect power to the appliance before servicing to avoid shock
• Handle LED components carefully; avoid touching LED surfaces directly
• Remove any trim or panels needed to access the light assembly; keep screws/fasteners for reuse
• Replace with OEM-equivalent fasteners

This 10-24 x 1/2 screw is a direct-fit fastener used to secure appliance panels and components. It restores proper fit and prevents loose or rattling parts for safer, quieter operation. What it does:

• Fastens appliance panels, trim, brackets, or components where a 10-24 x 1/2 screw is required
• Replaces missing or stripped screws that cause loose panels, vibration, or misalignment
• Helps maintain electrical and mechanical connections by keeping parts securely mounted
• Suitable for interior and exterior appliance body attachment points using standard 10-24 threads

• Use the matching screwdriver or nut driver; avoid over-tightening to prevent stripping or cracking parts
• Disconnect power to the appliance before accessing internal panels or components
• Wear basic PPE (gloves/eye protection) when working on appliances

Fix uneven cooling or defrost issues with a new temperature sensor. Most DIYers complete this repair in under an hour with basic tools and our video.

Rubber grommet that seals the water fill tube where it passes through the refrigerator liner. Replace if cracked, worn, or missing to prevent leaks.

LED light board assembly that restores interior refrigerator illumination when lights fail or dim. Replace when experiencing uneven lighting or dark areas. Verify fit with your refrigerator model number before ordering.

Replace your refrigerator's LED light lens cover when cracked, yellowed, or missing. This clear plastic cover protects the LED module and diffuses light.

This rear wheel assembly replaces a worn or broken refrigerator drawer roller to restore smooth, stable movement and proper drawer alignment. It helps prevent sticking, scraping, and uneven wear on the drawer track. What it does:

• Replaces a damaged rear roller so the drawer opens and closes smoothly
• Keeps the drawer aligned and prevents it from binding or tilting
• Reduces scraping and uneven wear on the drawer and track
• Supports normal load on the rear of the drawer for stable operation

• Remove drawer contents and slide the drawer out according to your appliance manual before starting
• Inspect the front and rear tracks; replace only the damaged roller(s) and test drawer movement after installation
• Use basic hand tools; avoid forcing parts
• No special wiring or electronic handling required; follow general safety precautions

Secures the evaporator fan shroud to the rear compartment frame. Replace if rusted, cracked, or broken to properly support the fan assembly and alignment.

Mounting screw for refrigerators and freezers. Secures internal components and panels. Replace if stripped, missing, or damaged during maintenance.

The Lid Bumper is an OEM part for GE refrigerators. It is designed to provide cushioning and protection for the refrigerator lid, preventing damage and ensuring smooth, quiet closing.

Causes of a bad Lid Bumper can include deterioration over time due to frequent use, exposure to temperature variations, or damage from accidental impacts. A worn or damaged bumper may no longer provide adequate cushioning, leading to potential damage to the lid or the refrigerator itself.

Symptoms of a bad Lid Bumper include:

• The refrigerator lid closing too hard
• Unusual noises when closing the lid
• Visible wear or cracks on the bumper

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Fix loud fan noise and poor cooling with a new evaporator fan blade. Restores airflow across coils. Moderately difficult install in tight freezer space.

If your refrigerator compartment isn't cooling while the freezer stays cold, the evaporator fan motor likely failed. DIY-friendly repair with video guide.

Secures the evaporator fan motor to the refrigerator cabinet. Replace if your original bracket is bent, broken, or cracked to restore proper mounting.

Rubber grommet that seals and cushions where the evaporator fan motor shaft mounts. Replace if cracked, worn, or missing to eliminate noise and vibration.

Size: 8-16 x 2 inch ss.

Fixes uneven cooling in fresh food section. This air diffuser directs chilled air for consistent temperatures. Simple DIY repair restores airflow.

Mounting bracket that secures the damper assembly inside your refrigerator. Replace if cracked, broken, or missing to properly support the damper component.

A small spring-style cotter clip that secures shafts and pins to keep moving parts in place. Restores a secure fit to linkage, rods, and pivot points so components stay aligned and don't slip free during operation. What it does:

• Holds shafts, pins and rods in position to prevent components from sliding off
• Provides a spring tension lock around a grooved pin or hole for reliable retention
• Commonly used on linkage, pivots and fastener pins where a compact retaining clip is needed
• Helps stop rattling, loose connections or parts that drop out of place

• Disconnect power before servicing any electrical appliance and work with the appliance in a stable position
• Use needle-nose pliers to spread and install the clip over the pin groove; ensure it seats fully
• Inspect mating pin/hole for wear or damage and replace if deformed
• Replace with an identical clip size and style to maintain secure retention

This 3/8-inch washer is used in refrigerators to secure components and prevent loosening. Replace if washer is missing, cracked, or worn out.

This base shaft is the support shaft that helps the washer's tub or drum stay aligned and rotate smoothly. Replacing a worn shaft restores proper drum support and reduces noise, wobble, and uneven operation. What it does:

• Provides a stable pivot and support for the tub/drum during operation
• Transfers rotational force from the drive components to the drum assembly
• Prevents excessive wobble, vibration, and metal-on-metal contact when intact
• Worn or damaged shafts can cause noise, drum misalignment, or premature bearing wear

• Disconnect power and water supply before servicing; follow all safety precautions
• Replacement typically requires removing the cabinet and drum assembly for access
• Inspect adjacent bearings, seals, and mounting hardware and replace if worn
• Use appropriate tools and follow the OEM service manual

Refrigerator not cooling or freezing over? The defrost heater melts ice buildup on evaporator coils to restore proper airflow and temperature control.

Guides defrost water into the drain opening to prevent puddling and ice buildup. Replace if cracked, broken, or missing to keep water flowing properly.

Fix fresh food section freezing or not cooling issues with this air damper assembly. Controls airflow between freezer and refrigerator compartments.

Secures heater and sensor wiring to the evaporator area in your refrigerator. Replace if cracked, broken, or missing to maintain proper wire routing.

Left-side evaporator baffle directs cold air flow in the freezer compartment. Replaces cracked, broken, or missing baffles to restore proper airflow.

Routes defrost and condensation water from your refrigerator to the drain system. Replace if cracked, split, or clogged to prevent water pooling.

Replacement roller wheel for refrigerators and freezers. Installs on the base to support smooth movement. Replace if cracked, worn, or missing.

Freezer getting too warm during defrost? This defrost thermostat regulates evaporator coil temperature. Moderate DIY repair with wire splicing.

Bottom cover panel for refrigerator condenser assembly. Protects internal components and provides structural support. Replace if cracked, broken, or missing.

Collects defrost water under your refrigerator. Replace if cracked, leaking, or missing to prevent water damage and moisture buildup on your floor.

Evaporator drip pan that catches and channels defrost water away from the freezer evaporator. Replace if cracked, damaged, or missing to restore drainage.

This front roller assembly includes a small wheel and bracket designed to support and guide a sliding component inside the refrigerator, such as a drawer or shelf track. It allows smooth, low-friction movement when opening and closing drawers. Replace this roller if drawers feel sticky, wobble, or no longer glide evenly.

Replaces a cracked or broken drain trap in your refrigerator. Installs on the drain hose at the back of the unit. Use pliers to remove the old trap.

This screw handle trim replaces the small decorative cover that hides and secures the mounting screw on a range/oven handle, restoring a finished look and preventing debris buildup around the screw. What it does:

• Covers the handle mounting screw and provides a clean finished appearance
• Helps keep crumbs and grease out of the screw cavity
• Stops a loose or missing trim from catching on clothing or hands
• Restores cosmetic look after handle removal or damage

• One screw handle trim

• Safety first: unplug the appliance or shut off power to the range before working
• Remove the handle screw, fit the trim over the screw area, then reinstall and tighten the screw securely (do not overtighten)
• Use the correct screwdriver and avoid forcing the trim; check alignment before final tightening
• If the original mounting hardware is damaged, replace it with OEM hardware

This drain fan assembly circulates air around the refrigerator's drain/evaporation area so defrost water can dry properly. Replacing a worn or seized fan restores intended airflow and helps reduce lingering moisture and related odors. What it does:

• Moves air across the drain/evaporation path to aid drying after defrost cycles
• Helps minimize standing water and musty odors near the drain pan area
• Supports proper moisture management in the machine compartment
• Common symptoms of a failing fan include not running, intermittent operation, rattling/squealing, or occasional water pooling near the base

• One drain fan assembly

• Disconnect power before servicing; wear cut-resistant gloves
• Location and access vary by model—refer to your model's service information
• Note wire connections and mounting orientation before removal; transfer any reusable hardware from the original assembly
• After installation, ensure the blade spins freely and wiring is routed clear of moving parts
