Parts for Bosch HBL8751UC/01: Cabinet Parts

This outer housing replaces a damaged or cracked enclosure that protects a dishwasher's internal components and helps maintain proper alignment and support. Restores structural integrity and helps reduce noise and vibration. What it does:

• Covers and protects internal components from moisture, debris, and accidental contact
• Provides mounting surfaces and alignment for pumps, motors, and other assemblies
• Helps reduce vibration and rattling caused by loose or damaged panels
• Visible damage or large cracks can allow leaks, excessive noise, or poor component alignment

• Disconnect power and water supply before beginning any repair
• Removal typically requires taking off outer panels and disconnecting attached components; follow manufacturer instructions
• Inspect surrounding seals, gaskets, and mounting hardware during reassembly and replace if worn

This trim plate covers and protects the appliance control area while restoring a finished appearance to the front panel. It helps hide fasteners and worn edges for a clean, factory look after repairs. What it does:

• Replaces a damaged, scratched, or missing control-area trim to improve appearance
• Conceals screws and edges around the control panel for a finished look
• Helps prevent dirt and moisture from collecting in the control-panel seam
• Matches the original exterior finish and mounting points for easy fit

• Designed to mount using the appliance's existing screws and clips; screw locations before tightening
• Remove power to the appliance before beginning work to avoid electrical hazard
• Handle edges carefully to avoid scratching the finish during installation
• If trim does not align, do not force; part number and fit before drilling or modifying

This connection piece is a replacement hose connector that joins appliance water lines to ensure a secure, leak-free connection. It restores proper water flow and helps prevent drips at the junction. What it does:

• Connects inlet or drain hoses to the appliance plumbing to maintain proper flow
• Seals hose junctions to reduce or stop leaks caused by worn or damaged connectors
• Stabilizes hose alignment to prevent kinking and unpredictable flow
• Commonly replaced when leaks, loose hose fit, or water pooling occur

• One connection piece

• Turn off power and shut off the water supply before replacing the connector
• Verify correct orientation and seating of any gaskets or O-rings; replace seals if damaged
• Hand-tighten fittings, then snug with appropriate tools—do not overtighten

A replacement trim plate that restores the finished look and edge protection of the appliance front. Replaces a worn, dented, or scratched trim to improve appearance and help keep adjacent panels aligned. What it does

• Covers and protects the exposed edge of the appliance front for a clean, finished appearance
• Helps keep control panels and door edges aligned and properly seated
• Replaces a bent, scratched, or otherwise damaged trim that affects cosmetics
• Reduces gaps where dirt and moisture can collect along the appliance edge

• Remove power to the appliance before starting any service to avoid shock or injury
• Installation typically requires removing adjacent trim or the appliance door/panel; use appropriate hand tools
• Keep fasteners and clips organized—verify orientation before tightening
