Parts for Ge DPVH890EJ2MG: 05 - Cabinet Parts

This hex washer-head screw secures dishwasher components like brackets, shields, and panels. Replacing a stripped or missing screw restores a tight fit and helps prevent vibration, rattling, and loose parts during operation.

• Fastens parts where a #10-16 x 1/2-inch hex washer-head screw is specified
• Secures brackets, panels, and assemblies to the tub or frame
• Helps resolve symptoms like loose panels, vibration, or rattling noises
• Restores proper hold when the original screw is stripped, missing, or damaged

• Disconnect power and shut off water to the dishwasher before servicing
• Match length and thread to the original; replace screws one at a time to maintain alignment
• Start threading by hand to avoid cross-threading; tighten snugly—do not overtighten, especially into plastic
• Verify no wires or hoses are pinched before reassembly

• Size: #10-16 x 1/2 inch
• Head: hex washer-head
• Type: AB tapping screw

Package of 12

Adjustable

This gold top cover provides the appliance's finished upper surface and protects internal components while restoring the original appearance. Durable painted finish helps conceal wear and maintain a uniform look. What it does:

• Replaces a damaged, cracked, or faded upper exterior cover to restore the appliance's appearance
• Shields controls and internal components from dust, spills, and everyday wear
• Matches the original gold finish for a consistent cosmetic repair
• Common issue addressed: chipped or discolored top trim or cover

• One gold top cover

• Disconnect power to the appliance before starting any repair
• Removal typically requires removing mounting screws and any adjacent trim pieces; keep hardware for reassembly
• Handle painted surfaces carefully to avoid scratching; use gloves or a soft cloth during installation

This rear level leg bracket replaces the rear mounting bracket that secures a leveling leg to the appliance frame, restoring proper support and helping keep the appliance stable and level for safe, quiet operation. What it does:

• Secures the rear leveling leg to the appliance frame so the cabinet sits evenly
• Restores proper height and prevents the appliance from tilting backward
• Reduces rocking, wobbling, and vibration caused by a damaged or loose bracket
• Helps maintain safe, stable operation under normal load conditions

• Disconnect power (and gas supply if applicable) and move the appliance to a safe, accessible area before starting.
• Support the appliance cabinet so it cannot tip when the rear leg or bracket is removed.
• Use basic hand tools to remove and install the bracket; follow the appliance manufacturer's instructions.
• Inspect the leveling leg and front mounts while servicing; replace any worn or damaged hardware.

Rear bracket and leveling screw assembly.

The Power Terminal Block is an OEM part for GE dryers. This component serves as the connection point for the dryer's power cord, distributing electrical power to the various internal components of the dryer. It ensures that the dryer receives the proper electrical supply needed for its operation.

Causes of a bad power terminal block can include electrical overloads, corrosion from moisture exposure, and loose or frayed wiring connections. These issues can lead to improper power distribution or complete loss of power to the dryer.

Symptoms of a bad power terminal block include:

• The dryer not starting or losing power during a cycle
• Intermittent electrical issues or power surges
• Visible signs of damage such as burn marks or melted plastic
• Electrical arcing or sparking from the terminal block area

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This terminal block cover shields the dryer's rear power connection at the terminal block. Replace a missing or damaged cover to help protect wiring from accidental contact and lint intrusion, maintaining a cleaner, safer connection area.

• Covers and helps protect the power cord terminals and wiring at the rear terminal block
• Helps prevent accidental contact and keeps lint/debris away from the connection area
• Restores a secure cover when the original is cracked, warped, or missing
• Common signs you need this part: exposed terminals at the rear panel, a loose or broken cover

• Disconnect power to the dryer before servicing
• Access the terminal block from the rear; remove the retaining fastener(s) and lift off the old cover
• Ensure the cord strain relief and wiring are properly positioned, then set the new cover in place and secure it

A replacement strain relief bracket that secures the appliance power cord at the entry point, protecting wiring and the terminal connection from pull and wear. Restores proper cord routing for safer, more reliable electrical connection. What it does:

• Secures the power cord where it enters the appliance to prevent tension on terminals and wiring.
• Helps reduce intermittent power, loose connections, or arcing caused by a tugged or poorly routed cord.
• Maintains correct cord routing and support to match the original mounting location and fit.
• Useful when the original bracket is cracked, broken, or no longer holds the cord firmly in place.

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Access is typically from the rear; remove the back access panel to reach the cord entry and terminal block.
• Remove mounting screws holding the old bracket, position the cord, and secure the new bracket without over-tightening; reuse original hardware if appropriate.
• Inspect the power cord and terminals for damage—replace damaged wiring.

Size: 8-32 t. Includes 12 screws.

Includes 12 screws. Size: 8-18 ab.

This main power board assembly supplies and regulates the appliance's primary electrical power and controls core functions for reliable operation. Replacing a failed board restores power distribution and control response. What it does

• Distributes and regulates incoming power to control circuits and major components.
• Provides the control signals that enable start/stop cycles and user interface responsiveness.
• Failsafe symptoms include no power to the appliance, unlit display or controls, or complete failure to start.
• Intermittent power, unexpected shutdowns, or certain error codes can indicate a faulty board.
• Works in conjunction with door switches, thermal fuses, and other safety devices.

• Disconnect electrical power before servicing to avoid shock or damage.
• Observe ESD precautions; handle the board by its edges and avoid touching components.

A small plastic spacer that positions and main control board away from the cabinet to prevent shorts and reduce vibration. Keeps the control board secure so electrical connections stay stable and components avoid contact with metal. What it does

• Separates and insulates the main control (MC) board from the chassis to prevent electrical shorts.
• Holds the control board at the correct height and alignment for connectors and mounting hardware.
• Dampens vibration and reduces board movement that can cause intermittent electrical issues.
• Common symptom: loose or sagging control board, board contacting metal, or intermittent control/module behavior.

• Always unplug the appliance or disconnect power before accessing the control board.
• Handle the control board by its edges and avoid touching components or connector pins.
• Remove existing spacer(s) and install the replacement in the same location and orientation; secure board with original fasteners.
• If the board shows damage or mounting hardware is missing, inspect further or replace damaged parts as needed.
