Parts for Kitchenaid KBCS24RSSS04: 01 - Cabinet Parts

The Dryer Light Bulb is an OEM part for Whirlpool dryers. This bulb is specifically designed to provide illumination inside the dryer drum, allowing for better visibility when loading and unloading laundry. It ensures a well-lit drying environment.

Causes of a bad dryer light bulb can include normal wear and tear, electrical issues, or accidental breakage.

Symptoms of a bad dryer light bulb may include:

• The bulb not turning on when the dryer door is open.
• Dim or flickering light inside the dryer drum.
• A burnt-out or broken bulb.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This heater assembly provides the heat source for a dryer so clothes dry efficiently. It replaces a failed or damaged heating element to restore proper drying performance and reduce extended cycle times. What it does:

• Generates heated air used during the drying cycle
• Restores normal drying when a dryer produces little or no heat
• Works with thermostat and thermal fuse to maintain safe operating temperature
• Prevents overheating by failing open when faulty (leading to no heat)

• Disconnect power (and gas supply for gas dryers) before servicing
• Handle element carefully to avoid damage; avoid touching terminals with bare hands
• Check related parts (thermal fuse, thermostats, airflow) if heating issues persist
• Follow OEM instructions for installation

This Leveler is the adjustable foot that supports and levels your appliance. Replacing a worn, cracked, or missing leg helps stop rocking and vibration, improving stability and ensuring smooth, quiet operation.

• Screws into the base to set height and keep the appliance level and secure
• Helps reduce rocking, vibration, and rattling that can cause excess noise
• Supports proper alignment and smooth door/closure operation when level
• Common symptoms: appliance wobbles, leg is stripped or broken, difficult to keep unit level

• Disconnect power and shut off gas/water if applicable before servicing
• With help, tip or lift the appliance slightly and protect the floor
• Thread the new leveler into the mounting boss and adjust height with a level
• Verify the unit is stable by gently rocking and recheck level after initial use

This thermostat is the temperature control that helps maintain consistent cooling in your refrigerator. Replacing a worn or faulty thermostat restores stable interior temperatures and prevents food spoilage from fluctuating temps. What it does:

• Senses cabinet temperature and cycles the compressor or cooling system to maintain the set temperature
• Prevents the refrigerator from running constantly or failing to run when temperature rises
• Common symptom of failure: interior too warm or too cold despite correct settings
• Can cause excessive compressor cycling or inconsistent cooling when defective

• One thermostat

• Disconnect power before accessing the control area to avoid electrical shock
• Remove any trim or access panels to reach the thermostat; note or photograph wire connections before disconnecting
• Reconnect wires to the matching terminals and secure mounting; avoid pinching or bending sensing elements if present
• After installation, restore power and monitor temperatures for a full day to ensure normal cycling.

This black replacement control knob restores safe, easy control of your appliance's settings. It provides the original user interface feel so you can select cycles and temperatures with a firm grip. What it does

• Replaces a cracked, stripped, loose or missing control knob so controls turn smoothly
• Engages the control shaft to select cycles, temperatures, or power settings depending on the model
• Improves user safety and operation by restoring a secure, easy-to-grip surface
• Matches OEM fit and appearance for a factory-style replacement

• One black control knob

• Always disconnect power (unplug or shut off breaker) before servicing the appliance
• Pull the old knob straight off the control shaft; align and push the new knob onto the shaft until fully seated
• Do not force parts; inspect the control shaft and spline for damage before installing

Replacement on/off switch that restores basic power control to the appliance's electrical circuit. Swapping a failed switch can fix ovens, cooktops or other appliances that don't power on or have intermittent power, returning reliable control. What it does:

• Provides the user-accessible on/off function to complete or interrupt the appliance's electrical circuit
• Replaces worn or failed switch contacts that cause intermittent power or no-response conditions
• Can resolve symptoms such as an appliance that won't start, powers off unexpectedly, or fails to respond to the control knob or button
• Acts as the primary electrical contact for the controlled function

• Disconnect power at the breaker or unplug the appliance before starting
• Note or photograph wire locations and switch orientation before removing wires
• Use basic hand tools; handle terminals carefully to avoid bending or breaking
• After installing, restore power and test the function

This defrost thermostat senses evaporator temperature to control the defrost heater. Replacing a failed thermostat restores proper defrosting, prevents overheating during the defrost cycle, and helps maintain stable cooling performance.

• Monitors evaporator coil temperature and closes to power the defrost heater during defrost
• Opens the heater circuit as the coil warms to terminate defrost and prevent overheating
• Helps clear frost from the evaporator so air can circulate between freezer and refrigerator
• Failure may present as heavy frost/ice buildup, reduced cooling in the fresh food section, the evaporator fan hitting ice, or a defrost cycle that fails to start

• Disconnect power before servicing; defrost heavy ice as needed for access
• Located on/near the evaporator coil behind the freezer's rear panel, typically clipped to tubing
• Match original clip orientation and wire routing; ensure firm thermal contact with the coil/tube
• After installation, confirm operation with a continuity check at freezer temperature or run a manual defrost test per the service manual

This fan blade is the replacement blower blade that moves air through the appliance to help maintain proper cooling and circulation. Replacing a damaged blade restores airflow and helps the unit run more quietly and efficiently. What it does

• Spins on the fan motor to circulate air across coils and through the cabinet
• Worn, cracked, or missing blades can reduce airflow and cause warm spots
• A broken or unbalanced blade may make a loud noise or vibrate during operation
• Restoring a properly shaped blade helps the compressor and evaporator work as intended

• One replacement fan blade

• Disconnect power to the appliance before beginning any repair
• Remove access panels and mounting hardware as needed to reach the fan assembly
• Handle the blade carefully to avoid bending or cracking; ensure correct orientation on the motor shaft

This wire harness routes power and control signals between a range of appliance components to restore reliable electrical connections and proper operation. It replaces a damaged or worn harness to help eliminate intermittent faults and loss of function. What it does:

• Connects control board, motors, switches, sensors and other components so they can communicate and receive power
• Replaces frayed, broken or corroded wiring that can cause intermittent operation or component failure
• Helps stop issues such as no power to parts, sporadic cycles, or error codes tied to open/shorted circuits
• Restores secure connector fit and proper wire routing to prevent shorts or pinched wires

• One wire harness

• Always disconnect power to the appliance before starting any repair
• Take photos or label connectors before removal to ensure correct reassembly
• Route harnesses away from sharp edges, moving parts and hot surfaces; secure with existing clips or ties

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
