Parts for Viking Range VMOS200SS: Cabinet Parts

This replacement magnetron restores microwave energy generation so your oven can heat and cook food properly. Designed as a direct substitute for the listed Viking magnetron assemblies to return microwave output without replacing the entire cavity. What it does:

• Generates the high-frequency microwave energy that heats food inside the oven cavity
• Commonly replaces a weak, noisy, or non-heating microwave where the magnetron has failed
• Helps resolve symptoms such as no heat, sporadic heating, or unusual humming during operation
• Intended for use only in compatible Viking microwave assemblies per manufacturer guidance

• Disconnect power and discharge high-voltage components before servicing; high-voltage capacitors can retain a dangerous charge
• Mounting hardware and waveguide cover may be reused if in good condition; replace damaged covers to avoid arcing
• Follow the manufacturer's service manual or IPL for installation steps

This replacement turntable motor drives the rotating glass tray in compatible microwave ovens so dishes cook evenly and rotate smoothly. It restores tray rotation when the original motor fails. What it does:

• Rotates the microwave turntable to promote even heating and cooking
• Replaces a motor that has stopped turning, stalls, or turns intermittently
• Stops or reduces grinding, buzzing, or intermittent motion caused by a failing drive motor
• Interfaces with the turntable coupling and mounting bracket to transfer torque to the tray

• Disconnect power before servicing; verify the oven is fully de-energized to avoid electric shock.
• Access may require removing the turntable, roller ring, and lower access panel or cavity trim.
• Align the motor shaft with the turntable coupling and secure mounting fasteners; confirm the tray spins freely before reassembly.

This high-voltage rectifier converts the microwave section's high-voltage AC to DC to power the magnetron, restoring heating capability when the diode fails. It's a direct-replacement HV diode assembly for affected Viking microwave/oven units. What it does:

• Converts high-voltage AC to DC so the magnetron can generate microwave energy
• Commonly linked to no-heat microwave operation or intermittent heating
• Can cause blown microwave fuses or visible arcing if failed
• Works with the microwave high-voltage circuit and capacitor to maintain proper output

• One high-voltage rectifier (HV diode assembly)

• Disconnect power and unplug the appliance before servicing
• The microwave high-voltage capacitor must be discharged before touching components
• Inspect related parts (capacitor, fuse, magnetron) for damage when replacing this diode

This fan motor powers the blower that circulates air in the appliance, restoring proper ventilation and cooling. Replacing a worn motor helps reduce noise and regain consistent airflow for cooking and exhaust systems. What it does

• Spins the blower wheel to move air through the vent or hood assembly.
• Restores normal ventilation when the fan is slow, noisy, or won't run.
• Prevents overheating by maintaining airflow for components that rely on active cooling.
• Works with the existing blower housing and wiring—matches the OEM function.

• One fan motor

• Disconnect power to the appliance before inspecting or replacing the motor.
• Handle the motor and wiring harness carefully; note wire locations for correct reassembly.
• Use proper tools to remove the blower housing and mounting screws; support the blower wheel during replacement.

Replacement monitor switch and thermal fuse kit that restores the appliance's safety and control continuity. Use this assembly to replace a failed monitor switch and/or fuse so the appliance can resume normal powered operation. What it does:

• Replaces the monitor switch and thermal fuse used in the control/safety circuit
• Restores electrical continuity when a worn switch or blown fuse is the cause of power loss
• Helps prevent uncontrolled operation by providing the designed over-temperature/fault disconnect
• Common symptoms addressed: appliance won't power on, intermittent control power, or repeated fuse/open switch conditions

• Disconnect all power to the appliance before starting any repair to avoid shock or injury
• Basic hand tools required; handle the thermal fuse and switch gently to avoid damage
• Follow OEM wiring orientation and mounting; replace with identical parts only

Replacement secondary/third stop switch that restores reliable position sensing and circuit control for the appliance's stop/position function. Install to address unresponsive stop positions, intermittent control response, or erratic operation. What it does:

• Acts as the secondary/third stop in the control assembly, opening or closing the circuit based on the component's position.
• Replaces a failed switch that can cause unregistered stop positions or inconsistent operation of related controls.
• Designed to match the original switch terminals and mounting for a direct replacement.

• Always disconnect power to the appliance before servicing to avoid shock or injury.
• Document wiring and connector locations (photos recommended) before disconnecting the old switch.
• Reconnect wires to the same terminals and secure mounting; avoid forcing connectors or misaligning terminals.

This oven temperature fuse is a one-time thermal cutoff that protects the oven from overheating by opening the circuit when temperature limits are exceeded. Replacing a failed fuse restores the oven's overheat protection. What it does:

• Acts as a safety thermal cutoff that opens if the oven overheats
• Prevents power from reaching heating elements or controls when tripped
• Commonly linked to symptoms like no heat from the oven or an oven that stops heating unexpectedly
• Restores the oven's temperature-safety function when replaced with the correct part

• One oven temperature fuse

• Disconnect power to the appliance before beginning any repair
• Access typically requires removing back panel or control housing; handle with care to avoid damaging surrounding wiring
• Replace only with the exact OEM part and match mounting/wiring orientation

This cavity temperature fuse (QFS-TA) is a safety thermal cutoff for electric ovens and ranges. It helps stop power to heating circuits when internal temperatures exceed safe levels, protecting the appliance and reducing fire risk. What it does:

• Acts as a one-time thermal cutoff inside the oven cavity to interrupt power if temperatures rise too high.
• Common symptom: oven or broil element does not heat even though controls and power appear normal.
• Common symptom: intermittent heating or a completely non-responsive heating circuit after an overheat event.
• Replaces a failed or tripped temperature fuse to restore proper over-temperature protection (does not reset; replace if open).

• Disconnect power to the appliance at the breaker before servicing.
• Locate the fuse in the oven cavity area or behind the back panel per your model's service instructions.
• Replace only with the exact fuse type; verify continuity before reassembly and restore power only after proper installation.
• If the new fuse opens again, do not repeatedly replace; investigate and repair underlying overheat or control faults.

This turntable motor packing is a small rubber/foam cushion that mounts around the microwave turntable motor to damp vibration and hold the motor securely for smooth rotation. It helps reduce noise and prevents motor misalignment. What it does:

• Cushions and secures the turntable motor to the oven cavity or mounting bracket
• Dampens motor vibration to help cut down on humming or rattling noises
• Helps maintain correct turntable alignment so the glass tray rotates smoothly
• Worn or damaged packing can allow excessive movement, noise, or uneven rotation

• Always unplug the appliance before replacing parts to avoid electrical shock
• Remove the cavity trim and motor access panel as needed; handle the motor and plate carefully
• Replace with the exact packing designed for your motor to ensure proper fit and function
• If you see additional damage to the motor or mounting hardware, inspect those parts and replace as required

This latch hook secures the appliance door by engaging the latch striker, helping the door stay closed during operation for safe, consistent performance. Designed as a direct replacement when the original hook is cracked, bent, or worn. What it does

• Acts as the striker point for the door latch so the door catches and stays closed
• Prevents door from popping open during cycles or while the appliance is in use
• Worn or damaged hook can cause poor sealing, rattling, or difficulty latching
• Simple mechanical replacement restores reliable door engagement

• Disconnect power (and water, if applicable) before starting any repair
• Remove outer door or access panel as required by your model to reach the latch area
• Replace damaged hook using basic hand tools; keep alignment square for proper engagement

This Open Lever is the small mechanical link that connects the push-button to the door latch in your microwave. Replacing a worn lever restores positive, consistent door release so the unit opens properly and operates as intended.

• Transfers push-button motion to the latch mechanism to release the door
• Worn, cracked, or bent lever can prevent the door from opening when pressed
• Can make the button feel loose, stick, or require extra force
• If the door doesn't release/latch correctly, the unit may not run due to interlock switch issues

• Disconnect power before servicing; microwaves can retain dangerous high voltage even when unplugged
• Access the latch mechanism behind the control panel/grille; note lever and spring orientation before removal
• Move over any reusable hardware or bushings from the original part
• After installation, verify smooth door operation and proper interlock function before restoring power

The Waveguide Cover is an OEM part for Viking microwaves. This part protects the microwave's internal components from food splatter and ensuring the efficient distribution of microwaves within the cavity. The waveguide cover is made from a material that allows microwaves to pass through while preventing food particles and moisture from entering the waveguide itself, where they could cause damage or affect the appliance's performance.

Causes of a bad waveguide cover can include accumulation of food particles, moisture leading to the degradation of the material, or physical damage such as cracks or holes.

Symptoms of a bad Waveguide Cover include:

• Arcing or sparking inside the microwave during use
• Uneven cooking or hot spots in food
• Visible damage or deterioration of the cover
