Parts for Ge PCR06BATJSS: Cabinet & Shelves Parts

This hinge and cam riser assembly replaces the upper hinge support that helps properly position and pivot the refrigerator door for smooth opening and a correct seal. It restores door alignment and stable hinge operation. What it does:

• Supports the top door hinge and provides the cam surface the hinge pin rides on
• Restores proper door alignment and helps prevent door sag or uneven gaps
• Reduces rubbing, binding, or noisy hinge movement caused by a worn riser
• Helps the door close fully so the gasket can seal properly

• One hinge and cam riser assembly

• Disconnect power or follow appliance safety guidance; support or brace the door before removing the hinge
• Loosen and remove top hinge fasteners to replace the riser; keep hardware for reinstallation
• Verify correct orientation and alignment before fully tightening fasteners; do not overtighten

This is a replacement glass shelf designed for compatible refrigerators to restore a flat, stable storage surface and keep items organized. Replaces a cracked, chipped, or missing shelf to help maintain usable interior space. What it does:

• Provides a stable, flat surface for storing food and containers
• Helps contain spills and keeps items organized on a dedicated shelf level
• Restores proper spacing and usable storage when an existing shelf is damaged or missing
• Matches OEM fit and form for intended refrigerator shelf supports

• One (1) glass shelf

• Remove all items from the refrigerator before installing the shelf
• Slide shelf into the existing support rails or brackets until seated; do not force
• Handle the glass with care and wear cut-resistant gloves to avoid injury
• Replace damaged shelf clips or supports to ensure a secure fit

This front guide helps align and support a refrigerator drawer, restoring smooth opening and stable positioning. It replaces a worn or damaged guide to reduce sticking, slipping, or drawer misalignment for reliable daily use. What it does:

• Holds the front edge of the drawer in place and keeps the drawer track aligned
• Guides the drawer during opening and closing for smoother travel
• Prevents the drawer from binding, catching, or falling out of the track
• Helps reduce noise and uneven operation caused by a damaged guide

• Disconnect power to the appliance before beginning any service
• Remove the drawer and existing guide per the appliance service instructions
• Install the new guide in the same orientation; secure with the original fasteners or clips
• Test drawer movement after installation; do not force components or overtighten fasteners

This short frame guide helps support and guide the refrigerator drawer or bin for smooth opening and stable operation. It replaces a worn or broken guide to restore proper alignment and reduce drawer sticking or wobble. What it does:

• Guides and supports the drawer/bin along its track for consistent movement
• Helps prevent drawer misalignment, binding, and uneven wear
• Restores secure seating and reduces rattling or shifting during use
• Works as the short/secondary guide where appliances use paired guides

• Disconnect power to the appliance before servicing to avoid shock or injury
• Typical installation requires removing the drawer/bin and fastening the guide with original screws or clips
• Retain and reuse any original hardware unless replacement is explicitly supplied

This replacement hinge cover snaps over the refrigerator door hinge to restore the cabinet's finished appearance and help protect the hinge from dust and debris. Simple cosmetic repair for a cracked, missing or broken hinge cover. What it does

• Covers and protects the door hinge from dirt and moisture.
• Hides exposed hardware for a clean, factory appearance.
• Helps prevent clothing or fingers from catching on the hinge.
• Commonly replaced when the cover is cracked, broken, or missing.

• Unplug the appliance or disconnect power before installing for safety.
• Remove any obstructing trim or move the door if required.
• Snaps or screws into place depending on model; use basic hand tools.
• Inspect hinge alignment and door operation after installation.

A single replacement frame screw that secures the appliance's front frame or trim so panels stay aligned and stable. Use this OEM-style screw to replace a missing or damaged fastener and restore a snug, rattle-free fit. What it does:

• Secures the front frame or trim to the appliance cabinet to maintain proper panel alignment
• Stops loose or vibrating trim that can cause noise or visible gaps
• Replaces stripped, corroded, or missing screws that prevent panels from seating correctly
• Small hardware solution for restoring proper fit and finish after repairs

• Turn off and unplug the appliance (or shut off power at the breaker) before accessing panels
• Use the correct driver bit and hold the trim firmly to avoid stripping the head
• Do not overtighten; snug the screw until the panel is flush without distorting the trim
• If existing holes or threads are damaged, inspect for necessary thread repair or replacement parts

This LED board provides the display/backlight lighting for the appliance control area, restoring proper illumination and visible status indicators. It replaces a failed or dim display board to make the control panel readable again. What it does:

• Powers and drives the LED light segments used for the control/display backlight
• Restores dim, flickering or dark control panel illumination
• Helps ensure display indicators and touch/press areas are visible
• Works with the appliance's control assembly to provide status feedback via lights

• One LED board as shown

• Disconnect power before servicing to avoid shock—unplug or switch off breaker
• Handle the board by edges; avoid static discharge and contact with components
• Remove control housing or console trim to access the board; follow OEM disassembly steps
