Parts for Ge GFDR485EF1RR: Cabint & Top Panel Parts

Size: 8-18 b.

This hex-head screw secures dishwasher panels, brackets, and internal hardware so parts stay tight and rattle-free. Replace missing or stripped fasteners to restore a secure fit and reliable operation.

• Fastens panels, brackets, and other dishwasher components to the tub or frame
• Replaces a missing, stripped, or corroded screw that no longer holds securely
• Helps eliminate vibration and rattling caused by loose hardware
• Maintains proper alignment and secure mounting of parts during operation

• Disconnect power and shut off water supply before servicing
• Keep track of fastener locations and orientation for correct reassembly
• Start threads by hand; use an appropriate nut driver or socket to tighten
• Tighten snugly—do not overtighten, especially when threading into plastic

Black. 8-18 AB HXW 3/8

Size: 8 - 18 ab.

This block terminal assembly provides a secure, insulated connection point for the appliance power leads and incoming power cord. Replacing a damaged terminal block restores solid electrical contact and helps prevent arcing, intermittent power, or no-heat/power conditions. What it does:

• Acts as the main connection point between the appliance wiring and the incoming power cord
• Ensures firm, reliable electrical contact to heating elements, motors, and controls
• Reduces risk of loose connections, sparking, or burnt terminals that cause intermittent operation
• Used when terminals are cracked, corroded, melted, or wires no longer clamp securely

• One block terminal assembly

• Always disconnect the appliance from power at the breaker or cord before starting work
• Verify correct wire placement and tighten terminals securely; match wire colors/positions exactly
• Inspect mounting hardware and surrounding insulation; replace if damaged

This top panel bushing cushions and secures the appliance top panel, helping reduce vibration and wear where the panel mounts. It restores proper fit and quieter operation when the top panel is loose or squeaks. What it does:

• Acts as a mounting insulator between the top panel and cabinet to prevent metal-on-metal contact
• Reduces rattling, vibration and squeaking caused by worn or missing bushings
• Helps maintain correct alignment of the top panel for a snug fit
• Prevents premature damage to the panel mounting points from movement

• Disconnect power to the appliance before starting any repair
• Remove the top panel or access panel per the appliance's service instructions to reach the bushing
• Press the old bushing out and install the new bushing fully into the mounting hole; verify panel alignment before reassembly
• Wear gloves and eye protection; inspect adjacent mounting clips or hardware and replace if damaged

This Shield Water Valve controls water flow to the appliance's dispenser and ice-making system, restoring proper filling and reducing leaks when the valve assembly is failing. Direct-fit replacement for the original inlet valve assembly. What it does:

• Opens and closes the water supply to the dispenser and ice maker so the appliance fills on command.
• Stops water flow when the dispenser is idle to prevent overfilling and dripping.
• Common symptom: no water from dispenser or ice maker.
• Common symptom: slow fill, irregular dispensing, or visible leak at the valve area.
• Common symptom: valve hums or makes noise when energized.

• One shield water valve assembly

• Turn off power to the appliance and shut off the water supply before starting work.
• Relieve water pressure and have a towel/short hose ready for residual water in lines.
• Replace only with the matching part number; ensure electrical connectors and water lines are secured and not pinched.

The Ground Screw is an OEM part for GE dryers. It ensures proper grounding and electrical safety for your dryer. This screw securely connects the ground wire to the dryer chassis, providing a path for electrical current to safely discharge in the event of a fault or power surge.

A bad Ground Screw can lead to electrical issues and potential safety hazards. Causes of a bad Ground Screw can include corrosion, loose connections, or damage due to accidental mishandling or improper installation.

Symptoms of a bad Ground Screw include:

• Intermittent dryer operation
• Visible signs of damage or deterioration on the screw or ground wire
• Tripped circuit breakers or blown fuses

Replace your faulty or damaged Ground Screw with this genuine OEM GE part to ensure proper grounding and electrical safety for your dryer.

This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This Holder Top Panel secures the appliance's top panel and helps keep controls and components stable for reliable operation. It replaces a worn or damaged top-panel retainer to restore proper fit and alignment. What it does:

• Secures and supports the top panel so adjacent controls and trim sit correctly
• Prevents top-panel movement that can cause noise, rubbing, or loose trim
• Restores proper panel alignment after damage or wear
• Helps maintain a secure fit between the top panel and the appliance cabinet

• 1 Holder Top Panel

• Turn off power to the appliance before beginning any repair to avoid electrical shock
• Handle edges carefully; use gloves to protect hands from sharp sheet-metal edges
• Remove and retain fasteners and trim pieces in the order they were removed for proper reassembly

Oven thermostat that senses and regulates internal temperature for consistent cooking. Replaces a faulty temperature regulator to help restore accurate heat cycling so foods bake and roast more evenly. What it does:

• Senses oven temperature and opens/closes the heating circuit to maintain the set temperature.
• Used when the oven won't reach or hold the correct temperature.
• Can help when oven cycles too frequently, runs too hot, or runs too cool.
• Works as the primary temperature-control component for the oven's heating system.

• Disconnect electrical power (and gas, if applicable) before starting any repair.
• Handle any sensing capillary tube or probe carefully; avoid kinks or sharp bends.
• Verify wiring location and terminal identification before disconnecting; reinstall in the same position.

The Heater Assembly is an OEM part for GE dryers. This part is responsible for generating the heat necessary to dry your clothes effectively and efficiently.

The heater assembly ensures consistent and reliable heat production. It is designed to fit seamlessly within the dryer, providing heating to remove moisture from your laundry.

A bad heater assembly can occur due to wear and tear, damage, or electrical issues. If you notice symptoms such as clothes not drying properly, longer drying times, or no heat at all, it may be time to replace this part.

Symptoms of a bad heater assembly include:

• Clothes not drying properly
• Longer drying times
• No heat

Restore your GE dryer by replacing the faulty heater assembly with this genuine OEM part.

This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This dryer thermostat monitors internal temperature and helps regulate the heating cycle to protect against overheating. Replacing a failed thermostat restores proper heat cycling, helping your dryer heat consistently and operate safely. What it does:

• Senses exhaust/drum temperature and opens/closes to control power to the heater
• Helps prevent overheating by interrupting current when temperature exceeds its threshold
• Failure may cause no heat or low heat, extended dry times, overheating, or nuisance shutdowns

• 1 thermostat

• Disconnect power; turn off gas supply for gas models before servicing
• Access location per your model (commonly on the blower housing or heater assembly); note wire positions
• Transfer wires one at a time to the new thermostat and secure using existing hardware
• Remove lint buildup and verify airflow before test run
