Parts for Ge AZ85H18EACM2: Capillary Tubes Parts

This lead tube directs gas safely from the appliance manifold to the valve assembly, helping maintain a sealed fuel path for reliable burner operation. It's a direct-fit replacement when the original tube is cracked, corroded, or leaking. What it does

• Channels gas between the manifold and gas valve or burner assembly to support proper ignition
• Restores a sealed gas path if the original tube is damaged or leaking
• Helps prevent gas leaks that can cause poor burner performance or safety risks
• Matches OEM fit and routing to maintain correct clearance and connection alignment

• One replacement lead tube as shown

• Turn off gas supply and disconnect power before servicing; follow all local codes
• Inspect fittings and seals; use replacement gaskets or sealant only if specified by the appliance manufacturer
• Tighten connections to the manufacturer's torque recommendations and check for leaks with a soap solution or approved leak detector

This capillary tube is the refrigerant metering line that controls refrigerant flow into the evaporator for proper cooling balance. Replacing a damaged tube restores correct refrigerant delivery and can help recover normal cooling performance. What it does

• Acts as the refrigerant metering device between the condenser/receiver and the evaporator.
• Maintains proper refrigerant flow and pressure drop for efficient evaporator operation.
• Symptoms that may indicate replacement: poor or inconsistent cooling, uneven temperatures, or visible kinks/damage to the tube.
• Small-diameter tube is sensitive to bends and restrictions that can block refrigerant flow.

• One capillary tube

• For safety, disconnect power before servicing and follow manufacturer instructions.
• Avoid sharp bends or kinks when routing the tube; secure per original mounting to prevent vibration damage.
• Verify system integrity and proper charge after installation.
