Parts for Frigidaire R530DW2: 04 - Cavity & Panels Parts

This lower oven heat shield is a factory-style replacement panel that protects internal components from direct bake-broil heat and helps direct oven airflow for consistent cooking. Restores heat protection and prevents heat-related damage to nearby parts. What it does:

• Shields wiring, insulation and under-oven components from direct heat and hot spots
• Helps control internal oven heat flow for more even cooking
• Reduces risk of scorched or warped parts caused by excessive localized heat
• Common symptom: visible heat damage, burnt insulation, or a missing/warped shield

• Disconnect power (and gas supply if applicable) and allow the oven to fully cool before beginning work
• Handle carefully; edges may be sharp—wear gloves and eye protection
• Basic hand tools usually required; follow for exact fastener locations
• If corrosion or adjacent component damage is present, inspect and replace affected parts as needed

The Terminal Block Kit is an OEM part for Frigidaire appliances, typically used for connecting house power to various electrical appliances like ranges and dryers. This kit includes includes screws, nuts, and a unique terminal block. It plays a critical role in the power supply system by providing a reliable connection point for the appliance's main power cord, preventing loose connections and potential electrical hazards.

Symptoms of a bad Terminal Block Kit include:

• Signs of burning or melting at the connection points,
• Flickering power or intermittent operation of the appliance,
• A burning smell from the appliance area.

Causes of terminal block failure often involve loose connections that can lead to arcing and overheating, improper installation, or general wear and tear that degrades the integrity of the electrical contacts.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This vent tube directs airflow or drainage away from internal components to the appliance vent opening, helping maintain proper venting and reduce buildup. A simple replacement when the original tube is cracked, split, or disconnected. What it does:

• Routes vented air or condensate from internal ducts to the exterior vent
• Restores proper airflow path when the original tube is damaged or collapsed
• Helps prevent leaks or pooling caused by cracked or disconnected vent tubing
• Reduces chances of performance issues related to restricted venting

• Disconnect power (and gas supply on gas appliances) before starting any repair.
• Inspect surrounding ducts and seals; replace any damaged clamps or connectors for a secure fit.
• Push or clamp the tube fully onto both mating fittings to prevent leaks; secure with the proper fasteners.
• Use basic hand tools.

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

The Oven Rack is an OEM part for Frigidaire ovens, designed to provide a stable and durable surface for baking and roasting inside the appliance. This rack is essential for facilitating proper air circulation around food, ensuring even cooking and optimal baking results. The rack measures about 23 inches wide by 16 inches deep.

The primary reasons for replacing an Oven Rack usually involve normal wear and tear from regular use, including the effects of high heat, spills, and the burden of heavy pots and pans.

Symptoms of a needing replacement Oven Rack include:

• Warping or bending from heat exposure or the weight of heavy cookware, which can affect cooking results
• Rust or corrosion that might not only compromise the integrity of the rack but also pose a risk of contaminating food
• Difficulty in sliding the rack in and out smoothly, which could indicate a misshapen rack or damage to its guides

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This two-piece broiler pan and insert set creates a proper broiling surface in your range or wall oven. The vented top supports food while drippings collect below, helping reduce smoke and splatter for more consistent browning.

• Provides a slotted broiling surface that lets fats drain into the pan below
• Helps protect the oven cavity from spills and reduce smoke during broiling
• Replaces a missing, warped, rusted, or heavily stained broiler pan assembly
• If existing pan causes uneven browning, smoke, or odors, replacing it can restore broiling performance

• Allow the oven and racks to cool completely before handling
• Wash the new pan and insert before first use; dry thoroughly
• Set rack height per your owner's manual; seat insert on the pan and slide onto the rack
• Do not cover the insert with foil unless your manual permits; keep clear of the broil element
