Parts for Whirlpool 9KSM5CBBK1: 01 - Color Variation Parts

This planetary gear assembly transfers motor motion to the appliance's drive mechanism, restoring smooth rotation and normal operation. It replaces a worn or damaged planetary component to reduce noise and restore consistent drive performance. What it does:

• Transfers motor torque through the gear train to the driven component for proper operation
• Replaces worn or damaged gears that can cause grinding, clunking, or loss of drive
• Helps stop intermittent or failed agitation/spin caused by stripped or broken gear teeth
• Restores correct gear engagement to reduce excessive noise during operation

• One planetary gear assembly

• Disconnect power and water before starting any repair
• Some disassembly of the gearcase or transmission may be required; follow the OEM service manual
• Inspect surrounding seals, bearings, and fasteners; replace any damaged components
• Use proper tools and torque values

This replacement cover protects and secures internal components and wiring, restoring a finished appearance and helping prevent debris intrusion. It's a like-for-like exterior housing piece used on compatible Whirlpool appliances. What it does

• Covers and protects internal electronics, terminals, and wiring from dust and accidental contact
• Restores the appliance's finished exterior where the original cover was missing or damaged
• Helps maintain proper airflow paths and component positioning when installed correctly
• Can reduce vibration-related noise by keeping parts secured and enclosed

• One cover

• Disconnect power (unplug or switch off circuit breaker) before starting any repair
• Removal/installation usually requires removing a few screws and lifting the old cover off; keep fasteners for reassembly
• Handle edges carefully; use gloves to avoid cuts and protect painted surfaces

This cover is a replacement access panel that protects internal components and restores the appliance's exterior appearance. It keeps wiring and controls shielded while maintaining a clean, finished look. What it does:

• Shields control components and wiring from dust, spills, and accidental contact
• Restores damaged or missing exterior panels for a finished appearance
• Helps maintain proper airflow and component clearance by covering openings
• Can reduce rattles or vibration by replacing a loose or broken panel

• One replacement cover

• Disconnect power (and gas or water if applicable) before starting any repair
• Basic hand tools are typically required; follow the appliance's service manual for specific steps
• Handle edges carefully; align tabs/fasteners before securing to avoid damage
• Replace worn fasteners or clips to ensure a secure fit

This cabinet base is the lower support panel that mounts under the appliance to protect internal components and help stabilize the unit. It provides a finished look while covering hookups and wiring at the bottom. What it does:

• Covers and protects the appliance's lower components from debris and accidental contact.
• Helps stabilize the appliance and maintain proper alignment with the floor.
• Prevents direct access to wiring, vents, or drains located at the base.
• Visible signs it's needed: cracked, dented, missing, or loose cabinet base; bottom panel gaps exposing components.

• One cabinet base panel.

• Disconnect power (and water, if applicable) before beginning any work.
• Use two people for removal/installation to avoid damage and injury.
• Remove any kickplate or access panels, then unfasten mounting screws and retainers.
• Align base, secure fasteners, and ensure appliance sits level before returning to service.
