Parts for Bosch B24ID80NLP/01: Compressor Parts

The Water Filter is an OEM part for Bosch refrigerators. This part removes impurities and contaminants from the water supply to your appliance. This part ensures that the water and ice dispensed by your refrigerator are clean, taste fresh, and are free of common waterborne particles and substances.

Over time, the water filter can become clogged with sediments and contaminants, reducing its effectiveness and potentially affecting the taste and quality of the water and ice. Regular replacement is essential for maintaining optimal performance.

Symptoms of a bad Water Filter include:

• Unpleasant taste or odor in the water or ice
• Decreased water flow to the dispenser or ice maker
• Visible particulate matter in the water or ice cubes

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This is a replacement dryer complete assembly designed to restore drying function and structure for compatible Bosch laundry units. It provides the main cabinet and drum enclosure needed for normal tumbling and airflow. What it does

• Houses the drum and internal components so clothes can tumble during the drying cycle
• Provides the enclosure and mounting points for the blower, heating system, and controls
• Restores proper airflow pathways to help the dryer heat and vent as intended
• Helps eliminate issues caused by damaged or severely warped cabinet or drum housings

• One complete dryer assembly as shown

• Disconnect power before servicing
• Follow factory service manual for alignment, seal, and vent reconnection steps
• Inspect and replace any worn seals, ducts, or mounting hardware as needed during installation

This condenser is the refrigeration heat exchanger that helps remove heat from the appliance's cooling circuit so the refrigerator or freezer can maintain proper temperatures. Replacing a faulty condenser restores normal heat rejection and cooling performance. What it does:

• Releases heat collected from inside the cabinet so the refrigerant can cool and recirculate
• Helps the compressor run at designed temperatures and pressures
• Supports efficient cooling when free of damage, blockages, or corrosion

• Disconnect power before servicing and unplug the appliance
• Access may require removing exterior panels; keep fasteners organized
• Avoid bending or damaging fins and tubing during handling

This replacement transformer supplies the lower control voltage used by the appliance's electronic control and user interface, restoring reliable power to control circuits and helping resolve power- or control-related failures. What it does:

• Steps down incoming voltage to the level required by control boards and electronic components
• Restores power to control panels, displays, and relays when the transformer has failed
• Can cause symptoms such as blank displays, unresponsive controls, or the appliance not powering on
• Supports safe operation by providing stable voltage to sensitive electronics

• Disconnect all power to the appliance before beginning service to avoid shock or injury
• Access typically requires removing the back or control panel; follow the appliance's service manual or diagram
• Match connector types and mounting points; replace only with the correct part number

The Water Filter is an OEM part for Bosch refrigerators. This part removes impurities and contaminants from the water supply to your appliance. This part ensures that the water and ice dispensed by your refrigerator are clean, taste fresh, and are free of common waterborne particles and substances.

Over time, the water filter can become clogged with sediments and contaminants, reducing its effectiveness and potentially affecting the taste and quality of the water and ice. Regular replacement is essential for maintaining optimal performance.

Symptoms of a bad Water Filter include:

• Unpleasant taste or odor in the water or ice
• Decreased water flow to the dispenser or ice maker
• Visible particulate matter in the water or ice cubes

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

A replacement housing cover that protects internal components and helps keep the appliance sealed from debris and moisture. Replaces a worn or damaged cover to restore proper component protection and fit. What it does

• Shields internal motor, pump, or electrical components from debris and moisture.
• Helps maintain proper routing and positioning of nearby parts and wiring.
• Can prevent rubbing or contact-related noise caused by a cracked or loose cover.
• Common symptom: visible cracks, breaks, or a loose cover after impact or wear.

• One cover housing as shown.

• Disconnect power and water before starting any repair.
• Remove access panels or components only as needed to reach the cover; keep track of fasteners.
• Inspect surrounding seals, gaskets, and mounting tabs for damage and replace if necessary.

A replacement shock absorber that cushions and appliance component to reduce noise and stabilize movement for smoother, more controlled operation. Restores dampening to doors or tubs that close unevenly or vibrate. What it does:

• Dampens and slows movement to prevent slamming and reduce impact wear
• Stabilizes panels or tubs to cut down on vibration and rattling sounds
• Helps maintain even, controlled closing and opening motion
• Commonly used when a door feels loose, drops, or closes too quickly

• Disconnect power (and water if applicable) before attempting service
• Retain original mounting hardware; only replace items explicitly listed as included
• Ensure correct orientation and secure fasteners; test operation after installation

This foot installs at the appliance base to support and level the unit. Replacing a worn or missing foot restores stability, reduces vibration and rattling, and makes accurate leveling easier.

• Provides a stable contact point between the appliance and the floor
• Allows height adjustment during leveling
• A damaged or missing foot can cause wobbling, uneven operation, vibration, or noise
• Common signs include cracking, deformation, or a loose/stripped attachment

• Disconnect power and shut off any utilities before servicing
• Carefully tip or raise the appliance to access the base; use a helper and proper supports
• Install the new foot and adjust height to level the unit
• Verify stability front-to-back and side-to-side after re-leveling

Replacement reel assembly designed to restore smooth winding and secure routing for a reel-based component in select Bosch appliances. Use this reel to replace worn or damaged reels and reduce snagging, rubbing, or loose routing. What it does:

• Winds and stores a cable, hose, or internal component to keep movement controlled and organized
• Restores smooth retraction/extension and reduces rubbing or binding
• Helps eliminate rattling or loose parts caused by a broken or worn reel
• Supports correct routing to prevent pinched wiring or hoses

• Disconnect power and water before beginning any repair
• Follow OEM instructions for disassembly and reel replacement
• Inspect mounting points and fasteners; replace any damaged clips or screws before reassembly
• Test the reel's movement and check for proper routing before returning the appliance to service

The Water Inlet is an OEM component specifically designed for Bosch refrigerators featuring internal water filtration and dispensing systems. It serves as the entry point for unpurified water into the appliance.

The water inlet utilizes precise engineering to thread securely onto liquid supply lines. Its feed line transport capacity is rated to withstand regular high-pressure pulses from large filtered volumes.

Causes for inlet replacement typically relate to normal wear at the threaded fitting connection over time. Loosening can affect water tightness and risk leak development.

Symptoms of a failing water inlet include:

• Water leakage around the inlet fitting
• Loose inlet face or threads requiring tightening
• Diminished water flow rates into the refrigerator

 This OEM Bosch replacement part is also compatible with Thermador, Gaggenau, and some Kenmore refrigerator models utilizing matching water system architectures. Reinstallation restores a tight seal and reliable supply transport functionality.


The Water Filter Cap is an OEM part for Bosch refrigerators. This secures the water filter within the refrigerator, ensuring a snug and leak-free fit.

The need for a replacement can arise if the original cap is lost during a filter change, damaged, or wears out over time.

Symptoms of a missing or damaged Water Filter Cap include:

• Difficulty in installing or securing the water filter properly, which could lead to water leaks inside the refrigerator.
• Contaminants or particles in the dispensed water, indicating that the filter is not fully sealed and thus not effectively filtering the water.
• The water filter becoming loose or falling out, compromising the refrigerator's ability to provide clean, filtered water.

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Housing is an OEM part for Bosch refrigerator and freezers. This part encases the water filter, ensuring it is securely positioned within the appliance to effectively filter out contaminants from the water supply.

The need for replacing the Housing can arise from physical damage, such as cracks or breaks, which can occur from accidental impacts during filter changes or general wear and tear over time.

Symptoms of a compromised Housing include:

• Leaks or dripping water near the filter area, indicating that the housing may be cracked or not sealing properly.
• Difficulty in installing or removing the water filter, which could suggest that the housing is damaged or warped.
• Unfiltered water taste or odor, hinting at an improperly seated filter due to a faulty housing.

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This condenser fan circulates air across the condenser coil to help remove heat from the refrigerator, improving cooling efficiency and preventing compressor overheating. It replaces a worn or damaged condenser blower assembly. What it does:

• Moves air over the condenser coil to dissipate heat from the refrigeration system
• Restores proper condenser airflow when the original fan is seized, noisy, or not spinning
• Helps prevent excessive compressor run time and warm cabinet temperatures caused by poor condenser cooling
• Rubber mounts reduce vibration and noise transfer to the cabinet

• One condenser fan assembly with rubber mounting grommets

• Disconnect power to the appliance before starting and follow all safety precautions
• Access often requires removing the rear lower service panel or toe-kick; keep track of fasteners
• Handle the fan blade and motor carefully to avoid bending blades or damaging the shaft
• After installation, verify unobstructed blade rotation and test the unit for normal operation

This shock absorber cushions and controls dishwasher door movement to reduce slamming and improve closing action. It helps protect the door and cabinet from impact and can reduce noise during operation. What it does:

• Dampens and slows the dishwasher door as it opens and closes
• Helps prevent sudden drops or slamming that can damage the door or hinges
• Reduces vibration and noise caused by uncontrolled door movement
• Restores smoother, more controlled door operation when the original shock wears out

• One shock absorber

• Disconnect power to the appliance before beginning any repair
• Remove the dishwasher door panels or access panels to reach the mounting points
• Support the door during removal/installation to prevent it from falling or binding
• Use the OEM mounting hardware and verify secure attachment and correct alignment after installation

This holder is a small mounting bracket that secures internal components in place, restoring proper alignment and preventing movement that can cause noise or functional issues. It's a simple replacement that helps keep assemblies stable. What it does:

• Secures and supports an internal component or assembly to the appliance frame
• Prevents rattling, shifting, or misalignment that can lead to poor performance
• Restores proper part positioning after breakage or wear
• Helps maintain safe, consistent operation by keeping parts fixed

• One holder / mounting bracket (exact item as shown)

• Inspect surrounding clips and fasteners; replace any that are damaged before installing
• Use basic hand tools; keep power disconnected before accessing internal panels
• Reassemble panels and run a short test cycle to confirm the component is secure and operating normally

This adhesive tape is a narrow mounting and sealing strip used to secure trim, wiring, or small components and to help reduce rattles and moisture intrusion. It provides a simple replacement for worn or missing adhesive strips. What it does:

• Secures lightweight trim pieces, wire harnesses, and small components in place
• Helps reduce vibration noise and movement of parts
• Provides a basic moisture-resistant seal on smooth, clean surfaces
• Restores adhesive grip where original tape has failed or peeled

• One adhesive tape piece as shown

• Clean and dry surfaces thoroughly before applying for best adhesion
• Press tape firmly along its entire length; allow time to set before stressing
• Replace any tape that is degraded, contaminated, or losing adhesion
• Wear gloves if needed; avoid contact with skin and keep out of reach of children
