Parts for Bosch B30IR800SP/01: Compressor Parts

This electronic control board is the dishwasher's primary control module that manages cycles, buttons, and displays so your appliance responds correctly to commands. Replaces a failed or faulty main control assembly to restore normal operation. What it does:

• Receives input from the user interface and starts, stops, or advances wash cycles
• Controls wash timing, pump, and valve signals to coordinate dishwasher functions
• Helps manage display lights and error reporting for diagnostic feedback
• Commonly replaced for unresponsive controls, no-start conditions, or intermittent/erratic operation

• Disconnect all power to the appliance before starting work to avoid shock or damage
• Handle the PCB carefully and avoid contact with components; protect against electrostatic discharge
• Note connector locations and wiring; reconnect all harnesses securely before testing
• Reassemble panels and verify normal operation before finishing the repair

This foot installs at the appliance base to support and level the unit. Replacing a worn or missing foot restores stability, reduces vibration and rattling, and makes accurate leveling easier.

• Provides a stable contact point between the appliance and the floor
• Allows height adjustment during leveling
• A damaged or missing foot can cause wobbling, uneven operation, vibration, or noise
• Common signs include cracking, deformation, or a loose/stripped attachment

• Disconnect power and shut off any utilities before servicing
• Carefully tip or raise the appliance to access the base; use a helper and proper supports
• Install the new foot and adjust height to level the unit
• Verify stability front-to-back and side-to-side after re-leveling

This rack wheel lets your dishwasher rack glide smoothly along its rails. Replacing a worn, cracked, or missing wheel restores easy in-and-out movement and helps keep the rack properly supported during loading and unloading.

• Mounts to the rack/rail to support and guide the rack
• Allows the rack to roll smoothly on the track
• Helps prevent sticking, wobbling, or the rack jumping off the track
• Common symptoms: hard-to-slide rack, wheel damage, or rack derailing

• Unplug the dishwasher. Turn off water supply.
• Pull the rack out; release the old wheel from its clip/fastener.
• Attach the new wheel in the same position and ensure it spins freely.
• Reinstall the rack and test for smooth travel.

This valve magnet is the solenoid coil used to operate a dishwasher/washing appliance water/control valve, restoring reliable valve actuation and proper water flow control. Replaces a worn or failed coil to help stop intermittent filling or valve clicking. What it does:

• Energizes the valve plunger to open and close the water/control valve when the appliance control signals it
• Restores proper valve response when the original coil is burnt, shorted, or no longer generating magnetic force
• Helps stop common symptoms like no-fill, intermittent filling, repeated clicking at the valve, or valve that won't actuate
• Works with the matching valve assembly; does not include the valve body unless explicitly listed

• Disconnect power and water supply before servicing; follow manufacturer safety instructions
• Inspect valve plunger and seals when replacing the coil; replace the full valve assembly if mechanical parts are damaged

This cable connector is a replacement wire terminal used to restore a secure electrical connection in compatible Bosch appliances. It helps reestablish reliable power or signal continuity where a damaged or corroded connector causes intermittent or failed operation. What it does:

• Provides a secure electrical connection between wiring and appliance components
• Replaces damaged, corroded, or loose terminals that cause intermittent power or errors
• Helps prevent arcing and poor contact that can lead to component failure
• Suitable for repairs where the original connector is worn or physically broken

• Disconnect power before starting any repair to avoid shock or equipment damage
• Compare the replacement connector to the original for correct fit and orientation
• Use proper crimping or terminal tools if required; ensure a snug, strain-relieved connection

This power module supplies and regulates electrical power to the dishwasher control electronics so the machine can start and run reliably. Replaces a failed power supply assembly to restore control board operation and normal cycle power. What it does:

• Provides the control board's main low-voltage power so electronics and display can operate
• Commonly fails when the dishwasher does not power on, shows no lights, or has intermittent resets
• Prevents erratic control behavior caused by unstable or no power to the control electronics
• Works as the electrical interface between incoming mains and the dishwasher's control circuitry

• Disconnect all power (unplug or shut off breaker) before starting any service
• Access typically requires removing the lower front panel or console; keep fasteners and wiring orientation noted
• Handle the module carefully to avoid static damage; do not touch electronic components unnecessarily

A replacement housing cover that protects internal components and helps keep the appliance sealed from debris and moisture. Replaces a worn or damaged cover to restore proper component protection and fit. What it does

• Shields internal motor, pump, or electrical components from debris and moisture.
• Helps maintain proper routing and positioning of nearby parts and wiring.
• Can prevent rubbing or contact-related noise caused by a cracked or loose cover.
• Common symptom: visible cracks, breaks, or a loose cover after impact or wear.

• One cover housing as shown.

• Disconnect power and water before starting any repair.
• Remove access panels or components only as needed to reach the cover; keep track of fasteners.
• Inspect surrounding seals, gaskets, and mounting tabs for damage and replace if necessary.

This is a replacement dryer complete assembly designed to restore drying function and structure for compatible Bosch laundry units. It provides the main cabinet and drum enclosure needed for normal tumbling and airflow. What it does

• Houses the drum and internal components so clothes can tumble during the drying cycle
• Provides the enclosure and mounting points for the blower, heating system, and controls
• Restores proper airflow pathways to help the dryer heat and vent as intended
• Helps eliminate issues caused by damaged or severely warped cabinet or drum housings

• One complete dryer assembly as shown

• Disconnect power before servicing
• Follow factory service manual for alignment, seal, and vent reconnection steps
• Inspect and replace any worn seals, ducts, or mounting hardware as needed during installation

This adhesive tape is a narrow mounting and sealing strip used to secure trim, wiring, or small components and to help reduce rattles and moisture intrusion. It provides a simple replacement for worn or missing adhesive strips. What it does:

• Secures lightweight trim pieces, wire harnesses, and small components in place
• Helps reduce vibration noise and movement of parts
• Provides a basic moisture-resistant seal on smooth, clean surfaces
• Restores adhesive grip where original tape has failed or peeled

• One adhesive tape piece as shown

• Clean and dry surfaces thoroughly before applying for best adhesion
• Press tape firmly along its entire length; allow time to set before stressing
• Replace any tape that is degraded, contaminated, or losing adhesion
• Wear gloves if needed; avoid contact with skin and keep out of reach of children

This condenser fan circulates air across the condenser coil to help remove heat from the refrigerator, improving cooling efficiency and preventing compressor overheating. It replaces a worn or damaged condenser blower assembly. What it does:

• Moves air over the condenser coil to dissipate heat from the refrigeration system
• Restores proper condenser airflow when the original fan is seized, noisy, or not spinning
• Helps prevent excessive compressor run time and warm cabinet temperatures caused by poor condenser cooling
• Rubber mounts reduce vibration and noise transfer to the cabinet

• One condenser fan assembly with rubber mounting grommets

• Disconnect power to the appliance before starting and follow all safety precautions
• Access often requires removing the rear lower service panel or toe-kick; keep track of fasteners
• Handle the fan blade and motor carefully to avoid bending blades or damaging the shaft
• After installation, verify unobstructed blade rotation and test the unit for normal operation

This shock absorber cushions and controls dishwasher door movement to reduce slamming and improve closing action. It helps protect the door and cabinet from impact and can reduce noise during operation. What it does:

• Dampens and slows the dishwasher door as it opens and closes
• Helps prevent sudden drops or slamming that can damage the door or hinges
• Reduces vibration and noise caused by uncontrolled door movement
• Restores smoother, more controlled door operation when the original shock wears out

• One shock absorber

• Disconnect power to the appliance before beginning any repair
• Remove the dishwasher door panels or access panels to reach the mounting points
• Support the door during removal/installation to prevent it from falling or binding
• Use the OEM mounting hardware and verify secure attachment and correct alignment after installation
