Parts for Bosch B30IR800SP/01: Drawer & Shelf Parts

This glass turntable plate replaces a broken or missing microwave carousel surface so dishes rotate evenly for consistent cooking and reheating. Durable glass provides a stable platform for cookware during operation. What it does

• Replaces the microwave's rotating glass surface used to support plates, bowls, and cookware.
• Restores even heating when food was cooking unevenly due to a damaged or missing plate.
• Stops rattling or misalignment caused by a cracked or chipped turntable.
• Provides a smooth, heat-resistant surface that mates with the oven's roller guide.

• One glass turntable plate.

• Unplug the appliance before installing and handle the glass with care to avoid cuts.
• Ensure the plate is properly seated on the roller guide/center support and spins freely before use.
• Do not use if the glass is cracked or chipped; replace immediately to avoid injury or further damage.
• Clean with non-abrasive cleaners and avoid sudden temperature changes to reduce breakage risk.

Replacement glass shelf plate for side-by-side refrigerators. Restores storage space when original glass is cracked, broken, or missing. Direct fit.

Replacement rail that guides and supports sliding shelves or drawers in your refrigerator. Install when your original rail is cracked, broken, or worn.

This is a metal slide rail that guides a freezer drawer in and out of the cabinet smoothly. It mounts on the interior side wall of the freezer compartment and supports the drawer's weight during operation. Replace this rail if the drawer feels sticky, uneven, or won't slide properly, or if the existing rail is bent or broken.

Door shelf rail for refrigerators. Attaches to the door to support and secure storage bins. Replace if cracked, broken, or no longer holding shelves properly.

This LED diode is a small indicator light used on appliance control or display circuits. Replacing a failed or dim LED restores clear, reliable visual feedback for power, cycle status, or alerts so the interface is easy to read.

• Provides low-voltage illumination for indicators or backlighting on the user interface or PCB
• Helps signal power, program progress, or warnings
• Typical failure symptoms: no light, dim/flickering light, or intermittent operation
• Physical damage to the LED lens or leads can also indicate replacement is needed

• Disconnect power at the breaker or unplug the appliance before servicing
• Access the control panel or board; note polarity/orientation marks and match them during installation
• Use ESD protection; some applications are board-mounted and may require soldering
• Test operation before reassembling the appliance

This slide rail retainer secures the freezer drawer or shelf rails in their proper position within your freezer compartment. It prevents the rails from shifting or coming loose during normal use of the drawer system. Replace this part if your freezer drawer doesn't slide smoothly, falls off its track, or if the rails have become loose or misaligned.

Secures components inside the freezer compartment. Replace if broken, cracked, or missing to keep parts properly positioned during door operation.

Small retaining clip that secures panels, trim, or covers inside your refrigerator. Replace when worn, broken, or missing to restore tight fit.

This plate is a replacement support plate used to secure and stabilize internal components, restoring proper alignment and function. It provides a durable mounting surface to keep parts positioned during operation. What it does:

• Acts as a support/mounting surface for internal appliance components
• Restores proper alignment when a bent, cracked, or missing plate causes vibration or noise
• Helps prevent component movement that can lead to wear or intermittent operation
• Useful when visible damage or mounting-point failure is present

• One replacement support plate

• High-level swap: remove access panels and fasteners to reach the damaged plate, then replace with the new plate using original hardware
• Keep track of screws and any small parts; reassemble panels securely
• Disconnect power (and water, if applicable) before beginning repair to avoid shock or injury

This electronic control board manages the appliance's user interface and key control functions, restoring normal control and cycle operation when the original board has failed. It replaces a faulty main control to help the appliance respond to commands. What it does

• Receives input from the control panel and sends signals to start and stop cycles.
• Controls power distribution to motors, pumps, valves, and heaters as designed.
• Can correct symptoms like unresponsive buttons, failure to start, or erratic cycle behavior.
• May clear certain control-related error codes when replaced.

• Disconnect power to the appliance before starting any work.
• Handle the board carefully to avoid static damage; use ESD protection if available.
• Installation typically requires access by removing the control console or inner panel and disconnecting wiring harnesses.

This is a small humidity filter designed for the temperature-controlled drawer compartment in a refrigerator. It helps regulate moisture levels inside the drawer to keep fruits, vegetables, and deli items fresh longer. Replace this filter if you notice excessive condensation, frost buildup, or premature spoilage of food stored in the drawer.
