Parts for Jenn-Air TC507Q: 01 - Container Parts

Size: 8-18 x 1/2 inch.

This door lock latch assembly secures the washer door during operation so cycles can run safely and water stays contained. It replaces a worn or damaged latch to restore proper door locking and cycle start. What it does

• Secures and locks the washer door during wash and spin cycles so the appliance can operate normally.
• Triggers the door-closed sensor/switch that allows the washer to start and continue a cycle.
• Helps prevent accidental door opening and reduces the risk of leaks during operation.
• Common symptoms indicating this part may be needed: washer won't start, door won't latch or lock, or the latch feels loose or broken.

• Always disconnect power to the appliance before inspecting or replacing the door lock latch.
• Handle the door and glass carefully to avoid damage; align the latch with the strike before tightening fasteners.
• After installation, test a short cycle (no clothes) to ensure the door locks and the washer starts properly.

This E-ring retaining clip secures latch components by locking onto a shaft or pin so the latch assembly stays in place. It's a small but essential metal clip that prevents latch parts from slipping off and causing door or panel issues. What it does:

• Locks onto latch shafts or pins to hold the latch assembly together
• Prevents the latch or related parts from sliding off during operation
• Common symptoms: door or panel won't stay closed, rattling or loose parts near the latch, visible clip missing or deformed
• Helps restore secure engagement of the latch when the clip is intact and correctly positioned

• One E-ring retaining clip

• Disconnect power or unplug the appliance before beginning any repair
• Use pliers or snap-ring tools to remove/install the clip; avoid excessive force that could deform it
• Replace the clip if it is bent, cracked, or worn — do not reuse a damaged clip

This safety switch actuator engages the door/interlock switch so the appliance senses a closed, secure door and will run as intended. Replacing a worn actuator restores reliable door engagement and control-system signaling. What it does:

• Moves the door latch into position to trip the appliance's safety/interlock switch
• Ensures the control board senses a closed door so cycles can start or continue
• Common symptom: appliance won't start or stops when the door is shut or nudged
• Common symptom: door won't fully latch or feels loose when closing

• One safety switch actuator

• Disconnect power (and water if applicable) before starting any repair
• Remove exterior panels or door assembly as needed to access the actuator; keep fasteners organized
• Verify switch alignment with the actuator and test operation before reassembly
• Wear gloves and eye protection

This latch plate secures the appliance door to the cabinet, providing the positive engagement needed for proper door closure and operation. It helps restore a door that won't stay closed or won't trigger door switches. What it does:

• Acts as the door strike that the latch engages to hold the door shut
• Ensures the door closes firmly so door switches can register a closed state
• Can stop issues like a loose or misaligned door, or a door that won't remain closed
• Restores proper alignment and engagement without replacing the full latch assembly

• Disconnect power (and gas if applicable) before servicing
• Remove the door or access panel to reach the latch area
• Inspect related latch components and alignment; replace only the damaged part
• Use basic hand tools; tighten fasteners securely but avoid overtightening

Size: 8-32 x 3/8 inch.

This container roller bearing supports the trash compactor drawer as it slides on its tracks. Replacing a worn bearing restores smooth, quiet movement and helps keep the container aligned for easy opening and closing.

• Provides low-friction support so the drawer glides smoothly on the tracks
• Helps maintain proper container alignment and stability
• Reduces squeaks, grinding, and sticking during operation
• Common symptoms: drawer hard to open/close, scraping noises, binding or uneven movement, visible wear/flat spots on the bearing

• Disconnect power to the compactor before servicing
• Remove and empty the drawer to access the bearing location
• Install the new bearing in the same orientation; transfer any hardware as needed
• Inspect rollers, axles, and tracks; replace any additional worn parts for best results

Size: 3\8-24 inch.

Fits 15 and 18 inch compactors. This kit is for securing the compactor bags. Kit contains a set of 4 buttons and screws.

This replacement screw secures panels, brackets, and internal components inside your appliance to keep them aligned and rattle-free. Replace stripped, rusty, or missing hardware to restore a tight fit and dependable operation.

• Holds metal panels, brackets, ducts, or trim in place
• Helps maintain alignment and reduces vibration and noise
• Replaces missing, corroded, or stripped screws
• Common symptoms: loose panel or component, rattling/buzzing during use, screw won't tighten

• Disconnect power and shut off gas/water before servicing
• Start threads by hand to avoid cross-threading; use the correct driver
• Replace one fastener at a time to maintain alignment
• Tighten snugly—do not overtighten to prevent stripping
