Parts for Electrolux ECCI3668AS: Control / Generator Units Parts

This electronic control board manages a refrigerator's user interface and core functions so the appliance responds correctly to settings and temperature changes. Replacing a faulty board can restore control and resolve erratic operation. What it does:

• Interprets user inputs from the console and runs the refrigerator's control logic
• Sends signals to start the compressor, fans, and defrost cycle as needed
• Monitors and responds to temperature-sensor readings to regulate cooling
• Can stop erratic behavior caused by failed or intermittent control electronics

• Disconnect power at the breaker or unplug the appliance before servicing
• Handle the board carefully; avoid static discharge and contact with circuit traces
• Remove any protective panels or covers to access the control board; keep fasteners for reinstallation

This electronic control board is the appliance's main printed circuit board that controls functions and user inputs, restoring reliable control and proper cycle/feature operation when the original board fails. What it does:

• Receives user commands and runs the appliance's control programs
• Manages timing, sensors, and output signals to motors, valves, heaters, or compressors
• Common symptoms: unresponsive touchpad or buttons, blank or erratic display, cycles that won't start or complete
• May resolve intermittent operation or incorrect cycle behavior caused by a faulty board

• One electronic control board (main PCB) as shown

• Disconnect power before starting — risk of shock or damage if powered
• Handle the board by its edges; avoid touching components or connector pins to prevent ESD damage
• Verify connector seating and wiring harness alignment during reinstall; do not force connectors

The Terminal Block Kit is an OEM part for Frigidaire appliances, typically used for connecting house power to various electrical appliances like ranges and dryers. This kit includes includes screws, nuts, and a unique terminal block. It plays a critical role in the power supply system by providing a reliable connection point for the appliance's main power cord, preventing loose connections and potential electrical hazards.

Symptoms of a bad Terminal Block Kit include:

• Signs of burning or melting at the connection points,
• Flickering power or intermittent operation of the appliance,
• A burning smell from the appliance area.

Causes of terminal block failure often involve loose connections that can lead to arcing and overheating, improper installation, or general wear and tear that degrades the integrity of the electrical contacts.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.
