Parts for Ge PHP900SM2SS: 01 - Control Panel & Cooktop Parts

This filter board is the electronic control board that monitors and communicates your refrigerator's filter status and related dispenser signals, restoring proper filter detection and indicator operation. What it does

• Monitors filter presence and communicates filter status to the display or dispenser
• Sends/receives signals that enable filter-related indicator lights and alerts
• Helps restore dispenser/filter indicator functionality when the original board fails
• Common symptom: filter status light stays on or does not change after replacing the filter
• Common symptom: dispenser or filter indicator behaves intermittently or not at all

• Disconnect power to the appliance before starting service to avoid shock
• Handle the board by the edges and avoid touching contacts; protect against static discharge
• Access typically requires removing the dispenser/display or control housing—retain screws and mounting hardware

This right-side generator board is the replacement control board that completes the unit's ignition/control circuit, restoring proper operation and reliable starts. Use it to replace a damaged or non-responsive right-side generator board. What it does:

• Routes ignition/control signals to the right-side components and helps enable proper spark or control functions
• Common symptom: no ignition or intermittent starting on the right side
• Common symptom: erratic or no response from the affected side's controls
• Helps restore normal operation when the original board is cracked, burnt, or electrically damaged

• Disconnect power (and gas, if applicable) before starting any repair
• Handle the board by the edges and avoid static discharge; use ESD precautions if available
• Inspect connectors and wiring for heat or corrosion; replace damaged wiring or connectors

This generator board supplies the ignition pulse and switching signals for the right/left burner igniters so the range's gas burners light reliably. It replaces a failed ignition control to restore normal spark operation. What it does:

• Generates high-voltage pulses to the right and left burner igniters for ignition
• Routes timing and switching signals between the range's control system and igniters
• Helps stop continuous clicking or lack of spark at the burners
• Addresses symptoms such as no ignition, intermittent sparking, or constant clicking during start-up

• Disconnect power to the appliance and shut off the gas supply before servicing
• Handle the board carefully to avoid static damage; use proper ESD precautions
• Reuse factory mounting hardware and wiring harnesses unless visibly damaged

The Clear Tape is an OEM part for GE cooktops. This specialized tape is used to secure and protect various components of the cooktop, including glass panels and control assemblies. It ensures that these components stay in place during operation and helps maintain the cooktop's structural integrity.

Causes of a bad cooktop clear tape can include exposure to high temperatures over time, wear and tear from regular use, or accidental damage during cleaning or maintenance.

Symptoms of a bad cooktop clear tape include:

• Loose or shifting glass panels
• Parts of the cooktop not staying securely in place
• Visible deterioration or peeling of the tape
• Difficulty in maintaining a stable cooktop surface

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Foam Tape is an OEM part for GE gas ranges. It serves as a sealant, ensuring a proper fit and preventing the escape of heat and gases from the range. This tape helps maintain the efficiency of the range by providing an airtight seal around various components.

Causes of a bad Foam Tape can include wear and tear over time, exposure to high temperatures, or physical damage during cleaning or maintenance. When the foam tape degrades, it can compromise the range's performance and safety.

Symptoms of a bad Foam Tape include:

• Heat escaping from the range
• Gas odors near the appliance
• Visible wear or gaps in the seal
• Decreased cooking efficiency

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This installation bracket secures and positions appliance components during installation, providing a stable mounting point that helps prevent movement and misalignment for long-term, reliable operation. What it does:

• Provides a secure mounting point to fasten panels or assemblies
• Keeps parts aligned during and after installation to prevent sagging or gaps
• Reduces vibration and rattling caused by loose or improperly supported components
• Helps maintain correct clearances for safe, stable operation

• One installation bracket

• Follow the appliance manufacturer's installation instructions and use only the recommended fasteners
• Disconnect power (and gas, if applicable) before starting work
• Verify bracket orientation and fit before final tightening; avoid over-torquing
• Wear appropriate safety gear

A replacement thumb screw that secures panels and components without tools for quick hand-tightening. Ideal for small appliance access points where frequent removal or adjustment is needed. What it does:

• Provides a hand-tightened fastening point for removable panels and brackets
• Replaces stripped or lost thumb screws to restore secure, tool-free access
• Helps stop rattling or looseness caused by missing or damaged screws
• Fits 10-24 threaded holes with a 2.0" length for proper engagement

• Hand-tighten; avoid using pliers or power tools to prevent stripping threads
• Confirm thread size and length match your application before installing
• If metal fatigue or thread damage is present, replace mating fastener or insert as needed
• Disconnect power to the appliance when working near electrical components

This conduit clamp secures 1/2" electrical conduit or flexible armored cable to the appliance chassis, keeping wiring routed and strain-relieved for safe operation. It's a small replacement part used where the conduit passes into the control box. What it does

• Holds 1/2" conduit or flexible armored cable firmly at the entry point to the appliance cabinet.
• Provides strain relief to reduce stress on internal wiring and connections.
• Helps maintain proper wiring routing to prevent chafing or interference with components.
• Commonly used on ranges, ovens and other appliances that require a conduit connection to the control area.

• One conduit clamp (1/2") as shown.

• Always disconnect power to the appliance before servicing electrical components.
• Remove access panel to reach the mounting location; position clamp around the conduit and secure against the chassis.
• May require a small screw or nut to fasten.
• If wiring appears damaged or loose, inspect and repair wiring before reapplying power.

This body screw is a replacement fastener used to secure appliance panels and components, restoring proper fit and reducing vibration or rattling from loose exterior parts. What it does

• Secures appliance body panels, trim, or brackets to the chassis
• Helps stop rattling, vibration, or loose-fit issues caused by missing or worn screws
• Provides the correct threaded connection where an original screw has been lost or damaged
• Matches OEM form and function for reliable panel attachment

• Disconnect power to the appliance before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Thread screw in by hand first, then tighten snugly; do not overtighten to avoid damaging threads or panels
• If threads are damaged, replace the mating clip or insert as needed for a secure fit

Cerama Bryte Cooktop Cleaner is a special cleaner designed specifically for ceramic glass and smooth-top cooking surfaces. It easily removes cooked-on foods, spills, or grease while leaving your cooktop looking like new. This product contains no abrasives or harsh chemicals, so it won’t scratch or damage your delicate cooktop surface.

To use the cleaner effectively, all you need to do is spray it onto the surface and then scrub it with a clean damp cloth. Use circular motions for best results. The product can also be used to remove baked-on foods from grates and drip pans on your stovetop. For tougher stains, let the cleaner sit for a few minutes before wiping it away.
