Parts for Electrolux EW30CC55GW4: 03 - Controls Parts

This generator is the OEM replacement rotary cam assembly that times and drives mechanical sequences so your appliance operates correctly. It restores proper cycle sequencing to help eliminate failures caused by a worn or damaged cam. What it does:

• Rotates and indexes internal cams/gears to control mechanical switching and timing
• Ensures correct sequencing of cycles and component engagement
• Commonly replaces noisy, stuck, or non-indexing cam assemblies
• Helps resolve symptoms like intermittent operation, failed cycle changes, or mechanical binding

• One generator (rotary cam assembly) as shown

• Disconnect power before servicing to avoid shock or injury
• Access may require panel removal and basic hand tools
• Verify alignment and timing marks during installation for proper operation

The Terminal Block Kit is an OEM part for Frigidaire appliances, typically used for connecting house power to various electrical appliances like ranges and dryers. This kit includes includes screws, nuts, and a unique terminal block. It plays a critical role in the power supply system by providing a reliable connection point for the appliance's main power cord, preventing loose connections and potential electrical hazards.

Symptoms of a bad Terminal Block Kit include:

• Signs of burning or melting at the connection points,
• Flickering power or intermittent operation of the appliance,
• A burning smell from the appliance area.

Causes of terminal block failure often involve loose connections that can lead to arcing and overheating, improper installation, or general wear and tear that degrades the integrity of the electrical contacts.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This is a Frigidaire cooktop relay control board, which monitors and regulates the burners on a stove. The control board can short out due to power surge or exposure to excessive heat. For example, if the oven's self clean function is run too long or too frequently, parts of the control board could melt or otherwise malfunction. If the control board has failed, the stovetop burners may not work at all.Before installing this part, ensure that power to the range has been cut. A screwdriver will be needed to remove the old control panel and secure the new one.This is a genuine OEM part compatible with ranges manufactured by Frigidaire brands, including Electrolux, Gibson, Kelvinator, Westinghouse, and others. No other hardware is included with this product.

This hex flange nut secures components where a broader bearing surface is needed to resist loosening and distribute load. It fits 10-32 threaded studs and is used on fastened assemblies in appliances. What it does:

• Provides a secure threaded connection for 10-32 screws and studs
• Flange spreads clamping force to reduce panel or bracket damage
• Hex shape allows tightening with a wrench for a reliable hold
• Commonly replaces worn or missing nuts that cause loose panels or rattling

• One hex flange nut

• Use the correct 10-32 screw or stud and hand-start threads to avoid cross-threading
• Tighten with an appropriately sized wrench; do not overtighten to prevent thread or part damage
• Disconnect power and follow appliance safety instructions before servicing
• Replace only like-for-like; confirm size and thread match your application
