Parts for Ge JB350RF4SS: Control Panel Parts

The Control Oven TO9 is an OEM part for GE ranges. This part manages the oven's various functions, including temperature regulation, cooking modes, and timer settings. It serves as the central interface for the user to control the oven's operations, ensuring precise and reliable cooking performance.

Causes of a bad control module can include electrical surges, general wear and tear, or physical damage from impacts or spills.

Symptoms of a bad control oven module include:

• Unresponsive or malfunctioning buttons and dials
• Incorrect temperature readings or inconsistent heating
• Display not functioning properly
• Oven not turning on or shutting off unexpectedly

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Range Surface Burner Control Switch is an OEM part for GE ranges. This switch manages the temperature of the surface burners on your range, providing the ability to adjust the heat level. Whether you're simmering sauces or boiling water, the control switch ensures precise temperature management, enhancing your cooking experience.

The causes of a faulty burner control switch often include prolonged use leading to wear on the electrical contacts, exposure to moisture causing short circuits, or physical damage from impact or excessive force when turning the knob.

Symptoms of a bad surface burner control switch:

• The burner not turning on or off
• Inability to adjust the heat level, with the burner staying at one temperature regardless of the knob setting.
• Intermittent burner function

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Infinite Control Switch is an OEM part for GE ranges. This part controls the temperature of the surface burners by regulating the power sent to the heating elements, allowing for precise heat adjustments during cooking.

Causes of a bad infinite control switch can include electrical issues such as short circuits, wear and tear from regular use, or internal mechanical failures.

Symptoms of a bad infinite control switch include:

• The burner not heating up or getting stuck on one temperature
• Inconsistent or erratic heating
• Difficulty in adjusting the burner temperature
• The burner not turning off or on properly

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This is the replacement control knob for the cooktop's infinite switch. It lets you turn a surface element on/off and select heat levels, restoring normal operation and appearance when the original knob is cracked, stripped, or missing. What it does:

• Mounts on the infinite switch stem to control a surface element's power and setting
• Replaces cracked, broken, or missing knobs so the burner can be operated normally
• Helps correct loose, slipping, or spinning knobs that no longer grip the shaft
• Restores proper alignment of the pointer with the control panel markings

• 1 surface element control knob

• Turn off power at the breaker/unplug the range before working around controls
• Pull the old knob straight off the switch shaft; avoid prying with tools
• Align the flat/D-shaped side of the new knob with the shaft and press straight on until fully seated
• If it doesn't seat easily, re-align to avoid damaging the switch stem

This pilot indicator light mounts in the control panel and illuminates to show when a surface element or another heating circuit is powered. Replace a burned-out or stuck-on light to restore a clear, reliable power-on warning.

• Lights when the corresponding heating circuit is energized
• Alerts users that heating components are active
• Common symptoms: light does not turn on, stays on constantly, flickers, or is very dim
• Shows physical damage to the lens or terminals when failed

• Disconnect power at the breaker before servicing
• Remove the backguard or control panel cover to access the indicator light from behind
• Note wire positions; move connectors to the new light one at a time and secure the light in the panel
• Restore power and test operation before reassembly

The Light Lens is an OEM part for GE gas ranges. It is the protective glass cover that shields the oven light on the control board.

Causes of a bad light lens include cracks, chips or breaks that compromise its protective function.

Symptoms of a bad light lens include:

• Broken or missing lens exposing the interior light bulb
• Inability to illuminate on the board
• Risk of bulb breakage from impacts or debris on the panel

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore gas range models.

This hinge pin secures the rangetop to the cooktop assembly, providing a reliable pivot point for lifting and lowering the top. It restores proper alignment and stable movement for safe, everyday use. What it does

• Replaces a worn or damaged hinge pin that can cause the rangetop to wobble, stick, or sit unevenly.
• Restores smooth pivot action when opening or closing the cooktop/top.
• Helps maintain proper alignment between the rangetop and the range frame to prevent binding.
• Works with the original hinge components to ensure a secure, stable connection.

• One hinge pin for the rangetop.

• Basic hand tools required; follow the range manufacturer's disassembly steps.
• Disconnect power supply and gas and ensure the appliance is cool before beginning work.
• Handle edges and springs cautiously; support the rangetop during removal/installation to prevent injury or damage.

This Main Top Wire Harness routes power and signals to the cooktop controls and surface components, restoring proper electrical connections on the appliance's main top. It's a direct-replacement harness used where factory wiring has failed or been damaged. What it does:

• Connects power and control circuits between the console and main cooktop components for proper operation
• Replaces broken, burnt, or damaged wiring that can cause burners, lights, or control functions to stop working
• Prevents intermittent loss of power or arcing from compromised or frayed conductors
• Restores factory wiring paths so controls and sensors communicate reliably

• One main top wire harness assembly

• Recommended for installers or experienced DIYers familiar with appliance wiring and safety procedures
• Disconnect power at the breaker or unplug the appliance before removing panels or touching wiring
• Match connector shapes and wire routing to the original harness; secure harness away from heat and moving parts
• If you see melted connectors or extensive damage, inspect adjacent components and replace as needed

This right-side main top wiring harness routes power and control signals to the cooktop's switches, burners and ignitors so the surface elements operate reliably. It replaces a damaged or worn top harness to restore proper electrical connections. What it does

• Carries power and signal between the console/switches and right-side surface elements or igniters.
• Enables ignition and heat control for the right-side burners when intact.
• Commonly associated with symptoms like a non-working or intermittent right burner, no spark/ignition at the right surface element, or visible burned/damaged wires.
• Replaces a faulty harness that shows frayed wires, melted insulation, or loose/broken connector pins.

• One right-side main top wiring harness (WB18T10544) as shown.

• Disconnect power at the breaker or range plug before starting any work.
• Handle connector pins carefully; match and seat each connector fully to ensure reliable contact.
• Route and secure the harness following the original path; replace any mounting clips or grommets if worn.

Black. 8-18 AB HXW 3/8

This lubricant/cleaner is used during service of cooking appliances to dissolve residue and provide light lubrication on small moving parts. It helps restore smoother operation of control shafts and valves when burner knobs feel stiff or sticky. What it does:

• Cleans deposits and old grease from control shafts and valve components
• Provides light lubrication to reduce friction and sticking
• Helps address symptoms such as hard-to-turn burner knobs or rough valve rotation
• Supports preventative maintenance during range/cooktop service

• Lubricant/cleaner

• Disconnect power and shut off gas; allow the appliance to cool before servicing
• Work in a well-ventilated area and keep away from open flames or ignition sources
• Apply sparingly per service instructions; avoid contact with igniters, electrical components, and flame ports
• Replace any worn or leaking valve—do not rely on lubricant/cleaner to correct a leak

This silicon controlled rectifier (SCR) switches and regulates power to heating elements and motors in compatible appliances, restoring controlled current flow for proper operation. It's a direct-replacement electronic switching component. What it does:

• Acts as a solid-state switch to control AC power to heater or motor circuits
• Helps regulate current during timed or thermostatic cycles
• Common replacement when appliance shows intermittent heating, no heat, or erratic motor control
• Replaces a failed/shorted SCR that can cause blown fuses or control board errors

• One silicon controlled rectifier (single SCR)

• Intended for technicians or experienced DIYers; disconnect power before servicing
• Verify correct SCR orientation and secure the 8-32 screw terminal; avoid overtightening
• Observe ESD precautions and handle the part by non-conductive areas
