Parts for Whirlpool WOD51EC7HS20: Control Panel Parts

This electronic control board regulates the appliance's functions and user interface, restoring proper cycle selection and timed operations when the original board fails. It replaces a faulty main control to bring responsive controls back to the unit. What it does:

• Manages cycle selection, timing, and user interface signals
• Controls power distribution to motors, heaters, valves, and sensors via board relays
• Resolves symptoms like unresponsive controls, erratic cycles, or failure to start
• Helps stop intermittent operation caused by a damaged or burned control board

• One electronic control board

• Disconnect power before attempting service to avoid shock or damage
• Some units require removing an access panel or console to reach the board
• Handle the board by its edges and avoid touching components or connectors

The Oven Control Board is an OEM part for Whirlpool ovens. It regulates and controls the various functions and settings of your oven, including the oven's temperature, timers, and cooking modes.

A bad oven control board can occur due to electrical malfunctions, power surges, or component failure. If you notice symptoms such as an unresponsive control panel, error codes displayed on the screen, or erratic heating and temperature fluctuations, it may be time to replace the oven control board.

Symptoms of a bad oven control board include:

• Unresponsive control panel
• Error codes displayed on the screen
• Erratic heating and temperature fluctuations

Restore your oven by replacing the faulty or malfunctioning oven control board with this genuine OEM part.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


This panel skin is the replacement outer surface for the appliance control console, restoring the console's finished appearance and protecting buttons and trim from wear. It's a direct-fit cosmetic and protective overlay. What it does:

• Covers and protects the control area from scratches, stains, and everyday wear
• Restores faded, peeling, or cracked console surfaces for improved appearance
• Helps prevent dirt and moisture from reaching internal switches and electronics
• Returns the console to its intended look after removal or damage during repair

• Disconnect power to the appliance before starting any repair
• Removal/replacement typically requires removing the console or trim—retain all screws and mounting hardware
• Handle edges carefully to avoid damaging the new skin or surrounding trim
• If clips or adhesive are present, they are intact or replace as needed for secure installation

This control panel is the user interface assembly that houses the oven's touchpads and display so you can select cooking modes and view settings. It replaces a damaged or unresponsive console to restore normal control and display functions. What it does:

• Provides the front-facing buttons/touchpads and display used to set oven temperature, timers, and cooking modes.
• Sends user commands to the oven control board so functions start when selected.
• Commonly replaced for symptoms such as unresponsive buttons, missing/blank display segments, or incorrect readouts.
• Restores reliable input and clear status feedback when the original panel is cracked, worn, or faulty.

• One control panel/user interface assembly

• Disconnect power to the appliance before attempting any repair to avoid shock or damage.
• Basic hand tools are typically required; some models may require removal of the oven door or back panel.
• Handle the display and ribbon connectors carefully to avoid damage; confirm connector seating during reassembly.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This foam seal fits between mating parts to create a tight barrier that helps prevent leaks and rattling. Replacing a worn or missing seal restores proper sealing and helps keep your appliance running quietly. What it does:

• Creates a compliant gasket between components to limit air or moisture passage
• Helps dampen vibration and reduce rattling/buzzing where parts meet
• Helps maintain proper airflow or fluid routing as designed
• Typical symptoms include leaks, condensation/frost near a joint, or new vibration noises

• One foam seal

• Disconnect power; turn off the water supply before service
• Note the original seal's routing/orientation before removal
• Clean and dry all mating surfaces; remove old foam and residue
• Install without stretching or over-compressing; ensure even contact with no gaps

This replacement wire harness assembly restores secure electrical connections between controls and components to help your appliance operate safely and reliably. Use it when wiring is damaged, corroded, or has loose connectors. What it does:

• Routes and connects power and signal wires between controls, sensors, and components
• Restores reliable electrical contact when original wiring is frayed, burned, or broken
• Helps stop intermittent power, control failures, or components that won't operate due to wiring faults
• Prevents shorting from exposed wires by providing intact insulation and connectors

• One wire harness assembly as pictured

• Disconnect power (unplug or shut off breaker) before attempting any repair
• Take photos or label connectors to ensure correct reassembly
• Route harness away from sharp edges, moving parts, and heat sources; secure with existing clips or ties

This mounting bracket is a replacement support bracket that secures appliance components and keeps assemblies aligned for reliable operation. It restores proper fit and helps prevent rattling or movement from loose fittings. What it does:

• Secures panels or assemblies to the appliance frame to maintain proper alignment
• Reduces vibration and rattling caused by loose or damaged supports
• Restores mounting points that prevent sagging or separation of connected parts
• Helps ensure stable operation after repairs involving removed or replaced hardware

• Follow the appliance service manual for exact location and fastener torque
• Disconnect power (and gas if applicable) before beginning any repair
• Use appropriate tools and replace any damaged screws or clips with OEM-equivalent fasteners

This wire harness assembly connects the appliance's electrical components, routing power and signals so controls and circuits work reliably. Replacing a damaged harness restores safe electrical connections and resolves intermittent power or control issues. What it does:

• Routes power and signal connections between control boards, motors, sensors, and other electrical components
• Restores lost or intermittent electrical continuity caused by frayed wires, broken connectors, or heat damage
• Helps eliminate failures such as no power to a module, intermittent operation, or blown fuses related to wiring faults
• Provides factory-style connectors for a direct fit and reliable mating to OEM components

• Disconnect power (unplug appliance or turn off breaker) before beginning any repair
• Handle wiring and connectors gently; match connector shapes and colors when routing and reconnecting
• Secure harness with original clips/retainers and avoid contact with heat sources or sharp edges
