Parts for Sears 9117138182: Control Panel Section Parts

This spark module controls the ignition sparks for a gas range or cooktop, letting the burner surface and oven ignite reliably. Replaces a failed ignition control to restore sparking at the burner electrodes. What it does

• Sends timed spark pulses to burner electrodes so gas ignites when a burner or oven is turned on
• Replaces a failed or intermittent ignition source that causes clicking without ignition
• Commonly used when one or more burners won't light or spark consistently
• Works with electrode wires and ignition switches to coordinate burner ignition

• Spark module (1)

• Disconnect power and shut off the gas supply before starting work
• Label or photograph existing wire connections to ensure correct reconnection
• Handle the module and wiring harness carefully; avoid pulling on wires or connectors

ST10-16 X 7/16"
