Parts for Ge GUD27ESSJ1WW: Controls Parts

The Control Board is an OEM component specifically designed for GE washers. As the "brain" of the washer, this board processes all electrical functions based on signals from various sensors and switches. It analyzes inputs from components like the water level sensor, lid lock mechanism, spin sensor, and selector switch to precisely coordinate all washer cycles.

Causes of a bad control board can include water damage due to leaks, fluctuations in power supply, or failure of internal electronic components over time.

Symptoms of a bad control board include:

• Washer not powering on at all
• Failure to advance through cycles properly
• Inability to select certain cycles or options
• Error codes are displayed continuously
• Strange electrical humming noises

Replace yours with this authentic GE board and restore optimized functionality to your washer. This OEM part is also compatible with Hotpoint, RCA, and select Kenmore models.

A small replacement hose clip that secures flexible appliance hoses to fittings to help prevent leaks and disconnections. Fits commonly used appliance hose connections to restore a secure seal and reliable water flow. What it does:

• Secures a water or drain hose to a barb or fitting to prevent the hose from coming loose
• Helps stop leaks and drips caused by loose or slipping hoses
• Prevents hose movement and rubbing that can lead to wear or abrasion
• Useful when a hose slips off during operation or after maintenance

• Disconnect power and shut off the water supply before servicing the appliance
• Use appropriate hand tools (needle-nose pliers or hose clamp pliers) to open and seat the clip
• Position the clip over the fitting and tighten until the hose is snug and secure; avoid over-tightening
• Replace only with the correct OEM-style clip for a proper fit

NOTE: This part also requires software update kit CJT30000002. DO NOT INSTALL WITHOUT UPDATING SOFTWARE. Call for more information.

The Compressor is an OEM part for LG refrigerators. As the primary component that circulates refrigerant to chill the refrigerator and freezer compartments, it is crucial for proper cooling operation. The compressor works with the condenser fan and evaporator coil to regulate temperatures inside the refrigerator.

Causes of a faulty compressor can include gradual breakdown of motor windings, loss of refrigerant pressure over time, or failure of electrical components vital to operation.

Symptoms of a bad compressor are:

• Elevated fridge/freezer temperatures unable to be maintained
• Frost patterns indicating poor or insufficient cooling
• Abnormal vibrations or sounds upon compressor cycling
• Error codes displayed regarding cooling performance

It is also compatible with Sears/Kenmore refrigerator models.


A replacement strain relief bracket that secures the appliance power cord at the entry point, protecting wiring and the terminal connection from pull and wear. Restores proper cord routing for safer, more reliable electrical connection. What it does:

• Secures the power cord where it enters the appliance to prevent tension on terminals and wiring.
• Helps reduce intermittent power, loose connections, or arcing caused by a tugged or poorly routed cord.
• Maintains correct cord routing and support to match the original mounting location and fit.
• Useful when the original bracket is cracked, broken, or no longer holds the cord firmly in place.

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Access is typically from the rear; remove the back access panel to reach the cord entry and terminal block.
• Remove mounting screws holding the old bracket, position the cord, and secure the new bracket without over-tightening; reuse original hardware if appropriate.
• Inspect the power cord and terminals for damage—replace damaged wiring.

Includes 12 screws.

This cover protects the appliance's fuse and terminal area, keeping electrical connections insulated and reducing the risk of shorting or arcing. A simple replacement restores the protective barrier over the fuse compartment. What it does:

• Shields the fuse and terminal block from debris and accidental contact
• Helps prevent electrical shorts or arcing at the fuse/terminal area
• Keeps the fuse securely positioned in its holder
• Restores the appliance's intended insulation and safety for the electrical connection

• One fuse terminal cover

• Disconnect all power to the appliance before accessing the fuse or terminal area
• Remove any mounting screws or clips holding the old cover; replace with the new cover in the same orientation
• Inspect the fuse and terminal connections for damage before reassembly; replace any damaged components as needed
• Do not operate the appliance with the fuse or terminals exposed

This electronic water level pressure switch senses air pressure from the wash tub and tells the control when to start and stop filling. Replacing a failed switch restores proper fill levels and helps cycles advance reliably. What it does:

• Monitors tub water level via an air hose connected to the switch
• Signals the control to start/stop the inlet valves at the correct level
• Enables cycle progression by confirming empty/full status
• Common symptoms: won't stop filling, stops filling too soon, incorrect water level, or water-level error codes

• 1 electronic pressure switch

• Disconnect power and turn off water supply before servicing
• Access the switch in the control console or rear cabinet area (location varies by model)
• Move the pressure hose and wire connector(s) over one at a time; ensure airtight hose fit and proper routing without kinks
• Inspect the hose and air dome for cracks, kinks, or blockages; clear or replace if needed

Includes 12 screws. Size: 8-18 ab.

A replacement screw used to secure panels and components in compatible GE appliances. Replacing missing or damaged screws restores secure mounting, reduces rattling, and helps keep parts aligned during normal operation. What it does:

• Fastens panels, trim, brackets, or small appliance components to maintain proper alignment and fit.
• Keeps internal parts secured to reduce vibration, rattling, or movement during use.
• Replaces stripped, rusted, or missing hardware that can cause loose or misaligned panels.
• Small, non-electrical part — does not affect electrical circuits or controls.

• Disconnect power and unplug the appliance before accessing internal parts.
• Use the properly sized screwdriver to avoid stripping the head; hand-start threads to prevent cross-threading.
• Tighten securely but avoid over-torquing; overtightening can strip threads or damage plastic components.
• Keep track of small parts and hardware; replace any damaged or mismatched screws with the correct OEM part.
