Parts for Electrolux EFDE317TIW3: Controls / Top Panel Parts

This electronic control board regulates the refrigerator's functions and restores reliable operation when the original board fails. It replaces a faulty main control to return proper control of cooling and cycle timing. What it does:

• Manages compressor, evaporator fan, and defrost timing to maintain correct temperature cycles
• Processes user inputs and display signals for normal operation
• Stops or prevents erratic cycling and incorrect temperature behavior
• Resolve symptoms like no cooling, continuous run, display errors, or unresponsive controls

• One board assembly

• Disconnect power to the appliance before starting any repair
• Handle the board carefully; avoid static discharge and protect connectors
• Secure mounting and reconnect all harnesses; power on and verify functions before reassembling

This replacement door gasket seals the appliance door to maintain a tight, even seal that helps control temperature and prevent leaks. It restores proper door closure and reduces energy loss when the original gasket is cracked, torn, or hardened. What it does:

• Creates a continuous barrier between the door and cabinet to keep internal air in and outside air out
• Prevents water and air leaks that can lead to frost build-up or inconsistent temperatures
• Improves appliance efficiency by reducing cold/hot air exchange across the door
• Helps the door latch and close evenly for reliable operation

• One door gasket/seal

• Disconnect power to the appliance before starting any repairs
• Remove the old gasket by gently pulling from the door frame; clean the gasket channel before installing the new seal
• Work around the door evenly, pressing the new gasket into the channel to avoid stretching or twisting
• If the gasket is tight after install, allow time for it to relax into place; use care with sharp tools to avoid damage

This top panel in white restores the oven/stove's upper exterior, improving appearance and protecting internal components from spills and debris. It's a direct-replacement exterior shell piece designed to match original fit and finish. What it does:

• Replaces a cracked, warped, dented, or discolored upper cabinet panel
• Protects control housing and internal components from grease, spills, and dust
• Restores a flush, finished look to the appliance top and backguard area
• Helps maintain proper alignment for control and trim pieces

• Disconnect power to the appliance before beginning any work
• Typical removal requires removing screws and lifting the old panel straight out; keep mounting hardware
• Handle edges carefully to avoid cuts and protect the painted finish during installation

This terminal block provides the mounting point and secure electrical connection for the appliance power leads. Replacing a damaged or corroded terminal block restores a solid power connection and reduces arcing or intermittent power. What it does:

• Provides a secure connection between the incoming power cord and the appliance wiring
• Holds and isolates power terminals to prevent shorting and arcing
• Commonly fails when terminals are burned, corroded, loose, or when wires heat at the connection
• Symptoms of a failing terminal include loss of power, intermittent power, visible burn marks or arcing at the connection, and melted or discolored insulation

• One terminal block

• Always disconnect power at the breaker or unplug the appliance before servicing
• Tighten mounting screws and terminal screws securely; inspect and replace any damaged wire insulation

This factory 8-18 screw secures appliance panels, brackets, and components. Replace missing or stripped hardware to restore a tight, rattle-free assembly and dependable operation.

• Fastens components to frames, brackets, and covers
• Replaces missing, damaged, or rusted screws
• Helps reduce looseness, vibration, and rattling noises
• Restores proper alignment of panels and assemblies

• Disconnect power before servicing; shut off gas/water if applicable
• Start the screw by hand to avoid cross-threading; use the proper driver
• Tighten snugly—do not overtighten to prevent stripping metal or plastic
