Parts for Frigidaire FFSG5115PW1: 04 - Controls / Top Panel Parts

This control board is the electronic brain of the dishwasher, managing cycle timing and power to key components. Replacing a failed board can restore normal operation when the unit won't start, behaves erratically, or won't complete cycles.

• Distributes power to the wash motor, drain pump, inlet valve, and heater as directed by the selected cycle
• Coordinates timing and sensor inputs to run and complete programs
• Issues can include no start, stopping mid-cycle, unresponsive controls with power present, or error indications
• Similar symptoms can be caused by wiring, door latch, UI board, or power issues—diagnose before replacing

• Disconnect power at the breaker before servicing; do not rely on the door switch
• Access the control (location varies by model), label/photograph connections, and transfer connectors one at a time
• Handle the PCB by the edges and observe ESD precautions
• After installation, restore power and run a test or diagnostic cycle per the service information

This electrical wiring harness connects refrigerator components to restore reliable power and signal paths. It replaces a damaged or worn harness to help stop intermittent operation and return affected circuits to normal function. What it does:

• Routes power and control signals between components and the main control
• Restores connectivity when a frayed or broken wire causes intermittent or no operation
• Helps resolve symptoms such as non-working lights, controls, dispenser, or ice maker when caused by a failed harness
• Provides factory-style connector plugs for a direct replacement fit

• Disconnect power to the appliance before starting any work.
• Access may require removing interior panels or appliance trim; keep fasteners organized.
• Match connector shapes and colors; do not force connectors together.
• Inspect mounting points and secure harness to avoid contact with sharp edges or moving parts.

Color: White

Color: White

This damper is the refrigerator air-control flap that regulates airflow between compartments to help maintain consistent temperatures and proper cooling. It replaces a worn or stuck damper to restore normal airflow and temperature balance. What it does:

• Opens and closes to direct cold air where needed between freezer and fresh-food sections
• Helps maintain even temperatures and prevents one compartment from getting too warm
• Common symptom: uneven cooling or warm fresh-food section despite running compressor
• Common symptom: damper stuck or not moving, causing poor temperature control

• Disconnect power to the appliance before starting any repair
• Remove interior panels to access the damper; use basic hand tools
• Handle the damper and any wiring harness carefully to avoid damage
• After installation, verify damper operation and allow time for temperatures to stabilize

No.8 pan head `10 - 10b x 0.50 `cr/sq drive
