Parts for Dacor ER30DSCHLP: Cooktop Parts

This re-ignition module controls spark for gas surface burners and automatically re-sparks if the flame goes out, helping burners ignite consistently and stay lit when the original module has failed. What it does:

• Sends high-voltage pulses to the burner igniters to light gas
• Provides re-ignition if a burner flame is extinguished
• Distributes spark output to multiple burners as designed
• Common failure symptoms: no spark on all or most burners, continuous clicking, or intermittent ignition across burners

• 1 re-ignition module

• Disconnect electrical power at the breaker and shut off gas supply before servicing
• Access location varies by model; remove rear cover or top as required
• Label and transfer each wire one at a time; mount the module securely and route wires away from heat
• After installation, test each burner for proper ignition and that clicking stops once flame is established

This wafer-head Phillips screw (#8 x 3/8 in) is a factory fastener used to secure panels, brackets, and covers in compatible appliances. Replace a missing or damaged screw to restore a tight, properly aligned fit. What it does:

• Secures sheet-metal or plastic components to the appliance chassis or subassemblies
• Helps maintain proper alignment and reduce vibration or rattling
• Replaces lost, stripped, or corroded screws of the same size and type
• Used at panel, bracket, and cover mounting points designed for this fastener

• One wafer-head Phillips screw (#8 x 3/8 in)

• Disconnect power (and gas, if applicable) before servicing
• Start threads by hand to avoid cross-threading; use a #2 Phillips driver
• Do not overtighten, especially into plastic or thin sheet metal
• Replace only with the same size/type fastener removed to ensure proper fit

This service assembly secures and aligns the injector used in the appliance's dispensing/ice/water system, restoring proper positioning and reliable flow. Replace a damaged holder to stop misalignment that can cause leaks or intermittent dispensing. What it does:

• Holds and aligns the injector/nozzle in the dispenser or ice/water delivery path
• Keeps seals and hoses seated to prevent leaks and poor water flow
• Restores correct injector position when cracked, warped, or broken
• Helps resolve intermittent dispensing or dispenser misfeeds tied to misalignment

• Disconnect power and shut off water supply before beginning any repair
• Remove access panels and mounting fasteners to access the injector area; handle plastic clips gently to avoid breakage
• Inspect adjacent seals, hoses and the injector for damage; replace any worn parts as needed

This dual burner gasket seals the dual burner assembly to the cooktop surface, keeping spills out and the burner properly supported. Replacing a worn gasket restores a snug fit and consistent, reliable burner operation.

• Creates a tight barrier between the dual burner base and the cooktop
• Helps maintain correct burner height and alignment for stable operation
• Limits liquid and debris intrusion that can cause corrosion or binding
• Common signs: visible cracking/flattening, burner not sitting flush, liquids seeping below, or the burner shifting during use

• Disconnect power and shut off the gas supply; allow the appliance to cool completely
• Remove grates, caps, and burner components to access and remove the old gasket
• Clean mating surfaces before installation; do not stretch or twist the new gasket
• Reassemble and verify the burner sits flat and operates normally

This service pack includes the burner cap and burner ring used on compatible Samsung gas cooktops and ranges. It restores proper gas flow and stable flame by replacing worn or damaged burner top components. What it does

• Replaces the visible burner cap and surrounding burner ring for one cooktop burner
• Helps restore even flame distribution and consistent heating on the affected burner
• Can resolve ignition issues caused by warped or corroded burner tops
• Useful when the burner shows yellow tipping, uneven flame, or poor simmer performance

• One burner cap and one burner ring service pack

• Turn off gas supply and disconnect power before servicing the appliance
• Remove grates and existing burner components, then fit new ring and cap in correct orientation
• Inspect ignition electrode and gas orifice while servicing; clean or replace if needed

This service pack includes the burner cap and burner ring used on compatible Samsung gas cooktops and ranges. It restores proper gas flow and stable flame by replacing worn or damaged burner top components. What it does

• Replaces the visible burner cap and surrounding burner ring for one cooktop burner
• Helps restore even flame distribution and consistent heating on the affected burner
• Can resolve ignition issues caused by warped or corroded burner tops
• Useful when the burner shows yellow tipping, uneven flame, or poor simmer performance

• One burner cap and one burner ring service pack

• Turn off gas supply and disconnect power before servicing the appliance
• Remove grates and existing burner components, then fit new ring and cap in correct orientation
• Inspect ignition electrode and gas orifice while servicing; clean or replace if needed

This burner base assembly replaces the oven's damaged or worn burner base to restore stable combustion and proper heat distribution for gas ranges. It fits original equipment configurations and mounts where the burner connects to the range. What it does:

• Provides the appliance's burner mounting and gas flow interface for ignition
• Helps restore even flame pattern and consistent heating across the burner
• Replaces cracked, warped, or corroded burner bases that cause poor performance
• Can resolve ignition and flame stability issues when base damage is the cause

• Disconnect the appliance from gas and power before servicing.
• Use proper gas-line fittings and check all connections for leaks after installation.
• Inspect surrounding seals and gaskets; replace if damaged to maintain proper operation.

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This replacement thread ring features M22x1 threads and is used to secure a dual-assembly component within the appliance. Replacing a worn or stripped ring restores a firm fit, proper alignment, and dependable operation.

• Secures and retains a mating component using M22x1 threads
• Helps maintain correct alignment and spacing within the assembly
• Resists loosening from vibration and normal use
• Typical failure signs: stripped/worn threads, difficulty threading, inability to tighten, looseness or wobble after assembly

• Disconnect power and shut off gas supply if applicable; allow the unit to cool before servicing
• Remove the old ring and clean both the internal and external threads
• Start the new ring by hand to avoid cross-threading; tighten snugly per manufacturer guidance—do not overtighten
• If this ring interfaces with a gas component, perform a leak check after reassembly

This LED isolator board supplies and protects the LED lighting/display circuitry on compatible Samsung appliances. It restores proper LED operation by isolating and regulating the LED power feed for reliable lighting and display performance. What it does:

• Routes and isolates power specifically for LED modules and display LEDs
• Helps stop LED flicker, dimming, or intermittent lighting caused by a failing isolator board
• Supports stable LED backlight and control signals to the appliance display
• Serves as a direct replacement for the original service board when the LED circuit is at fault

• One LED isolator/service board (DE81-06682A)

• Disconnect all power to the appliance before starting any repairs
• Handle the PCB by its edges and avoid static-sensitive contact with components
• Verify correct board orientation and connector seating during installation
