Parts for Bosch HMV3061U/01: Door Assembly Parts

This inner dishwasher door panel provides a rigid, sealed surface that supports the latch, controls and detergent area. It replaces a dented, corroded or damaged inner door to help restore proper fit and sealing for normal dishwasher operation. What it does:

• Forms the interior surface of the door, protecting internal components from water and steam
• Supports the latch/strike and mounting points for the control and dispenser assemblies
• Helps maintain a watertight seal when the door is closed
• Common symptoms: visible dents or corrosion, door that won't latch properly, water leaking from the front or along the door seam

• Disconnect power and water supply before beginning any repair
• Follow the model-specific parts diagram for screw locations and trim removal
• Handle carefully to avoid bending or scratching the panel; use proper fasteners and torque
• If door alignment or springs are damaged, inspect and replace those parts as needed

This glass front panel replaces a cracked or scratched control/display surface to restore the appliance's appearance and allow normal access to controls. Tempered exterior glass designed to fit the original door assembly. What it does:

• Protects the control area from moisture, dirt, and daily wear
• Restores a smooth, intact surface when the front glass is cracked, chipped, or scratched
• Keeps touch and button interfaces accessible and visible
• Helps prevent moisture intrusion that can affect underlying electronics

• Handle carefully; tempered glass can break if dropped or struck
• May require partial door disassembly to remove the old panel and secure the replacement
• Use proper fasteners and avoid over-tightening to prevent cracking

The Hook is an OEM part for Bosch microwave doors. Manufactured from heat resistant composite materials, it firmly holds the door closed during cooking cycles.

Causes of a faulty latch/hook include failures of being worn down from repetitive opening/closing motions over time. Exposure to high heat or abrasive cleaners also leads to decreased functionality.

Symptoms of a damaged latch/hook involve:

• Doors not sealing fully or locking properly
• Failure to open after cooking
• Degrading latch fittings allowing moisture or debris entry

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This replacement spring restores the proper tension and return action for the mechanism it serves in your appliance. It helps moving parts operate smoothly and reset reliably so doors, levers, or linkages stay aligned and feel correct. What it does:

• Provides controlled tension so doors, flaps, levers, or linkages move and return to position correctly
• Helps maintain alignment and consistent feel of the mechanism
• Typical failure signs: weak or broken return, sticking/sluggish movement, parts that won't stay in position, or unusual popping noises
• Visible distortion, rust, or a missing spring indicates replacement is needed

• Includes 1 spring

• Disconnect power (and water, if applicable) before servicing; wear gloves and eye protection
• Springs store energy—release and install with care, keeping fingers clear
• Note original routing/orientation; take photos to match placement during reassembly
• Use needle-nose pliers or a hook tool for control; replace paired springs together if your model uses two

This replacement frame is a structural support piece used to hold and align its associated assembly within the appliance. Replacing a damaged or warped frame restores proper fitment and helps prevent looseness, rattling, or misalignment.

• Provides mounting and structural support for the related assembly
• Keeps panels, covers, or hardware properly positioned
• Helps reduce vibration, rubbing, and premature wear
• Common clues it's needed: cracked/missing tabs, distortion, loose fit, difficulty opening/closing the related component

• Disconnect power (and water or gas, if applicable) before servicing
• Note orientation and hardware locations; take photos for reference
• Transfer any clips, screws, seals, or brackets from the original part if required
• Do not overtighten fasteners; confirm smooth fit and test operation before reassembly

This support secures a lower dishrack roller to its rail, helping the rack roll smoothly in and out without wobbling. Replacing a worn support restores stable, easy rack movement.

• Holds the lower rack wheel/roller in position on the track
• Helps maintain smooth rack glide and proper rack alignment
• Common failure signs: rack binds, tilts, or the wheel falls off; grinding/scraping when moving the rack
• Can reduce strain on tracks and prevent uneven loading caused by a loose wheel

• Unplug power and shut off water before servicing the dishwasher
• Pull the lower rack out; remove the affected wheel and old support
• Snap the new support into the rail and reinstall the wheel as designed
• Check rack travel for smooth, even motion before returning to service
