Parts for Bosch HES7052U/01: Door Parts

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

Replacement cooktop frame for your range. Installs around the burner assembly to provide structural support. Order a new frame if yours is cracked or damaged.

This is a sealing ring designed for the pump housing area of a cooktop. It creates a watertight or airtight seal to prevent leaks and ensure proper operation of internal components. Replace this ring if you notice leaking, loss of pressure, or visible cracking and deterioration of the original seal.

Cracked, loose, or faded selector knob making it hard to switch oven functions? This range selector knob restores reliable control and clear settings.

This mounting bracket secures appliance components in place to restore proper alignment and stability. It's a simple replacement part that helps reduce rattling and supports correct panel or assembly positioning. What it does:

• Secures a panel or assembly to the appliance frame to prevent movement and vibration
• Restores proper alignment for doors, panels, or internal components
• Helps stop rattling, noises, or loose components that occur when a support bracket fails
• Provides a direct mechanical replacement—no electrical function

• One replacement mounting bracket

• High-level: remove power and water to the appliance before starting repairs
• Use basic hand tools; keep fasteners from the original part for reinstallation unless new ones are supplied
• If the bracket mounts a door or heavy panel, support the panel during removal and reinstallation to avoid damage

Replace your damaged or cracked range cooktop surface panel. This top panel covers the burner assembly and provides the main cooking surface for your stove.

Burner not heating or taking too long to boil water? This heating element assembly restores proper temperature output. Common fix for cooktops and ranges.

This switch regulates the power level sent to a surface heating element on the cooktop, allowing you to adjust the temperature from low to high settings. It connects between the control knob and the burner element to cycle power on and off at intervals that maintain the selected heat level. Replace this switch if a burner only works on one setting, won't turn off, won't heat at all, or provides inconsistent temperatures.

Decor frame for gas ranges. Installs around the control panel to provide a finished appearance. Order a replacement if your frame is cracked or damaged.

Fix range control issues or power problems with this cable harness. Common fix for unresponsive controls or electrical faults. Moderate DIY repair.

A replacement cable harness that routes power and signals between components to restore electrical connections and control functions. Use this harness to replace damaged, frayed or disconnected wiring that can cause intermittent operation or no power. What it does:

• Transfers power and control signals between appliance components for proper operation
• Replaces damaged, cut, or corroded wiring that can cause intermittent faults or loss of function
• Restores secure, insulated connections to prevent arcing and electrical shorts
• Matches OEM connector arrangement and wire grouping for straightforward wiring replacement

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Compare connectors and wire colors to the original harness to ensure correct fit before installing
• Route harness along the same path and secure with original clips or ties to prevent pinching or chafing

Catalyzer component for electric ovens and ranges. Installs inside the oven cavity. Order a replacement if your catalyzer is cracked, damaged, or missing.

The Convection Fan Motor is an OEM component specifically designed for Bosch combination and convection steam oven ranges. Located within the oven cavity, it powers the convection fan and circulation of hot air.

Symptoms of a bad convection motor include:

• Failure to achieve even heat distribution within the oven
• Loud grinding noises or vibrations from the fan
• Inability to select convection cooking modes
• Burning smells indicating possible overheating

Causes of failure may involve normal wear over extended use. Blocked ventilation from food debris could overload the motor. Accidental liquid spillage presents corrosion risks.

Replacing with this genuine Bosch motor restores essential airflow. Compatible with 500 series models, it features a permanently lubricated design for durable performance. Backed by Bosch quality, this convection replacement ensures reliable cooking for years to come. It is also compatible with Thermador and Gaggenau ranges.


Fix an oven door stuck closed after a cleaning cycle or error code 41. This door latch assembly restores normal lock/unlock operation on gas ranges.

The Oven Light Switch is an OEM part for Bosch ranges. It engages convenient interior illumination through a single motion, allowing monitoring of baked goods without compromising temps.

Causes of a bad oven light switch can include failures from the natural stresses of constant clicking associated with opening and closing the oven door.

Symptoms of a bad oven light switch include:

• Dim or unresponsive lights even when the door is opened properly
• Inability to turn lights off, leaving them burning needlessly
• Stuck in either the on or off position without toggle functionality
• Potentially hazardous exposed live terminals under switch housings

This OEM Bosch part can also be used on Thermador and Gaggenau appliances.

Replace your worn oven door gasket to restore a tight seal, prevent heat loss, and maintain consistent baking temperatures. Confirm fit with your model number.

This grille for pan is a replacement trim piece that restores proper airflow and appearance around the appliance pan. It helps keep the pan area protected and looking finished after repair. What it does:

• Covers and ventilates the pan opening to help direct airflow and prevent debris entry
• Replaces a cracked, warped, or missing grille to restore fit and finish
• Helps eliminate rattling or rubbing caused by a damaged trim piece
• Matches OEM fit so it installs cleanly with the original mounting points

• Install requires removal of the surrounding trim or access panel; follow your appliance manual
• Handle carefully to avoid scratching the finish; use non-marring tools as needed
• Disconnect power to the appliance before working in the service area
• Replace damaged clips or screws with OEM fasteners for secure fit

Restore oven visibility with this complete light assembly. Replace when bulb won't light, lens is cracked, or socket is damaged. Verify fit with your model.

Restore even baking when your oven heats unevenly. This convection fan blade circulates hot air for consistent cooking. Moderate DIY install.

This heating element is the direct-replacement heater assembly that provides the heat source for compatible appliances, restoring proper heating so cycles reach the temperatures needed for effective drying or cleaning. What it does:

• Generates heat for the appliance's thermal system (air or water heating depending on model).
• Replaces a failed or damaged heater element to restore normal temperature rise.
• Common symptoms it may fix: no heat, weak/no drying or cleaning performance, or unusually long cycles.
• Works as part of the appliance's safety and temperature-control circuit (thermostats or sensors may also be involved).

• Always disconnect power (and water, if applicable) before replacing the element.
• Allow the appliance to cool fully and wear protective gloves; heating elements can have sharp edges.
• After installation, restore power and run a short test cycle to check for any error codes.

The Sensor is an OEM part for Bosch ovens and ranges. It detects and monitors the actual interior temperature to maintain precise baking and roasting conditions.

Causes of a bad temperature sensor can include wear from prolonged heat exposure within the oven cavity. Physical damage, moisture intrusion or circuitry malfunctions may also lead to sensor failure over time.

Symptoms of a bad oven temperature sensor include:

• Inability to accurately read or achieve set target temperatures
• Fluctuations in readings displayed
• Cooking modes like bake and broil functioning abnormally

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The range door hinge plate is the metal bracket that anchors your oven door to the range frame and controls how the door opens and closes. It supports the full weight of the door and keeps it properly aligned. Replace this part if your oven door sags, won't stay open at a set angle, closes unevenly, or feels loose on one side.

Secures internal components and panels to restore proper alignment in your range. Replace when bracket is broken, cracked, or missing to fix loose parts.

Leveling foot for electric and gas ranges. Adjustable metal foot installs at base corner. Replace if cracked, broken, or missing to level your range.

Secures your range door and allows smooth pivoting for proper alignment and seal. Replace if your door won't close fully, sags, or doesn't seat correctly.

Restores smooth rack gliding in your oven. Replace when racks stick, scrape, or don't extend fully. Confirm fit with your model number before ordering.

This is a temperature sensor used in microwave ovens to monitor internal cooking temperatures. It sends temperature readings to the control board, allowing the appliance to regulate heating accurately. Replace this sensor if the microwave overheats, shuts off prematurely, displays error codes related to temperature, or fails to cook food to the correct temperature.

This is the front facia panel that mounts on the range and houses or surrounds the control knobs and displays. It provides a finished appearance to the control area and helps protect the internal wiring and components behind it. Replace this panel if it is cracked, warped, discolored from heat damage, or if mounting points are broken.

This inner door is the dishwasher's inner panel that supports the door assembly and helps contain water and steam during cycles, restoring a secure, finished door surface. It replaces damaged or corroded inner door panels to improve sealing and appearance. What it does:

• Serves as the interior face of the dishwasher door and provides structural support for inner components
• Helps maintain a watertight seal and prevents leaks from the door area
• Replaces dented, cracked, or corroded inner panels that can trap moisture or cause cosmetic damage
• Restores proper alignment so the door closes and latches correctly

• 1 inner door panel

• Disconnect power and water supply before starting any repair
• Handle panel edges carefully; use gloves to avoid cuts and protect finish
• Installation typically requires removing the outer door panel and disconnecting inner fasteners—keep hardware organized for reassembly

This kit includes the inner door hardware and hinge components needed to properly secure and align the oven door. The hinges allow the door to open, close, and stay in position while also maintaining a tight seal when shut. Replace this kit if the oven door is sagging, not closing flush, falling open, or if the hinges are visibly bent or broken.

This kit includes the inner door hardware and hinge components needed to properly secure and align the oven door. The hinges allow the door to open, close, and stay in position while also maintaining a tight seal when shut. Replace this kit if the oven door is sagging, not closing flush, falling open, or if the hinges are visibly bent or broken.

Replace your range door seal to prevent heat loss and improve cooking efficiency. Install when worn, cracked, or loose. Verify fit with your model number.

This glass front panel is the exterior replacement glass that restores the appliance's finished look and protects the underlying door and control area from scratches and wear. It fits into the door assembly to provide a clean, glossy surface. What it does:

• Replaces cracked, chipped, or heavily scratched front/door glass to restore appearance
• Protects internal components and trim from direct contact and debris
• Helps keep the door surface smooth and easy to clean
• Restores a secure fit when broken or loose glass affects the door finish

• One glass front panel

• Disconnect power to the appliance before starting any repair
• Handle glass with gloves and protective eyewear to avoid cuts
• Installation typically requires removing the door trim or bezel—follow the OEM service instructions for your model

This insulating part provides electrical and thermal isolation for internal appliance components, helping prevent shorting and reducing heat transfer where wiring or terminals meet sensitive parts. Use it to restore safe operation after damage or wear. What it does:

• Provides electrical insulation for terminals, connectors, or wiring to prevent shorts and arcing
• Reduces heat transfer between hot components and nearby wiring or plastic parts
• Helps maintain safe clearances and protects against chafing or contact-related failures
• Commonly replaced when cracked, melted, burned, or otherwise compromised

• One insulating part

• Always disconnect power (unplug appliance or switch off breaker) before servicing
• Verify correct orientation and seating; do not force the part into place
• Inspect surrounding wiring and terminals; replace any damaged connectors or wires

Replace a damaged heat shield causing nearby components to overheat or melt. This protective panel restores the heat barrier on your gas range.
