Parts for Bosch HGS5052UC/01: Door Parts

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

Replacement cooktop frame for your range. Installs around the burner assembly to provide structural support. Order a new frame if yours is cracked or damaged.

This is a sealing ring designed for the pump housing area of a cooktop. It creates a watertight or airtight seal to prevent leaks and ensure proper operation of internal components. Replace this ring if you notice leaking, loss of pressure, or visible cracking and deterioration of the original seal.

Cracked, loose, or faded selector knob making it hard to switch oven functions? This range selector knob restores reliable control and clear settings.

This mounting bracket secures appliance components in place to restore proper alignment and stability. It's a simple replacement part that helps reduce rattling and supports correct panel or assembly positioning. What it does:

• Secures a panel or assembly to the appliance frame to prevent movement and vibration
• Restores proper alignment for doors, panels, or internal components
• Helps stop rattling, noises, or loose components that occur when a support bracket fails
• Provides a direct mechanical replacement—no electrical function

• One replacement mounting bracket

• High-level: remove power and water to the appliance before starting repairs
• Use basic hand tools; keep fasteners from the original part for reinstallation unless new ones are supplied
• If the bracket mounts a door or heavy panel, support the panel during removal and reinstallation to avoid damage

Replace your gas range's scratched, dented, or discolored stainless steel main top. This cooktop surface panel restores appearance and covers damage.

Gas range burner cap sits atop the burner to distribute flames evenly for cooking. Replace if cracked, warped, or causing uneven flames. Verify fit with your model number before ordering.

Fix wobbly burners or uneven flames with this gas range burner housing. Secures surface burner assembly for stable operation and proper alignment.

Burner cap for gas ranges. Sits atop the burner assembly to control and diffuse the flame. Replace if cracked, chipped, worn, or missing.

Fix a loose or misaligned cooktop burner with this burner housing. Secures the burner head and igniter for stable flames and even heating on your range.

Uneven flames or weak heat? This range burner cap directs gas flames for even cooking and protects the burner from spills. Easy 5-minute replacement.

This is the burner base housing for a gas range cooktop surface burner. It sits beneath the burner cap and distributes gas evenly to produce a consistent flame ring. Replace this part if you notice uneven flames, yellow or irregular burning, or if the base is cracked or corroded from spills and buildup.

This replacement grill grid restores a flat, stable cooking surface so food cooks evenly and stays off the burner. Designed to fit compatible Bosch countertop grills and grilling modules for reliable performance. What it does:

• Provides a stable, heat-resistant surface for grilling and searing foods
• Keeps food elevated above the burner for even heat distribution
• Replaces bent, warped, or damaged grill surfaces that cause uneven cooking
• Helps prevent food from falling into the burner area during use

• One grill grid

• For safety, disconnect power and allow appliance to cool completely before removing or installing the grid
• Handle with care—edges may be sharp and surfaces hot after recent use
• Slide or position the grid into the existing support rails; no special tools typically required

Mounting holder that secures burner assemblies to the cooktop. Replace if cracked, rusted, or missing to restore proper burner positioning and stability.

Mounting clip that secures burners to your gas range cooktop. Replace if rusted, broken, or missing to properly position burners and prevent rattling.

Fix weak or uneven burner flames with a new orifice holder assembly. Secures gas flow orifices for proper flame control. DIY-friendly, under 30 minutes.

Uneven flame or poor ignition? This burner orifice meters gas flow to create a stable flame. Replace clogged or damaged orifices to restore performance.

If your range has intermittent power issues or components that won't operate, a damaged cable harness may be the cause. This wiring assembly restores connections.

This is a gas valve that controls the flow of gas to an individual surface burner on a gas range or cooktop. It connects to the burner control knob and regulates the flame from high to low settings. Replace this valve if a burner will not ignite, the flame cannot be adjusted properly, or you detect a gas smell when the knob is in the off position.

This gas valve controls the flow of gas to an individual surface burner on a range cooktop. It connects to the burner control knob and regulates flame intensity from low to high settings. Replace this valve if a burner won't ignite, the flame is uneven or won't adjust properly, or you detect a gas smell around the cooktop controls.

Fixes burner flame issues on gas ranges. Controls gas flow for consistent cooking temperatures. Replacing a worn valve restores precise flame control.

This manifold directs and distributes incoming water to the appliance's internal wash circuits, restoring proper water routing for consistent cleaning performance. Replaces a worn or damaged manifold to stop leaks and restore normal fill and spray operation. What it does:

• Channels incoming water to the dishwasher's spray and circulation system for even cleaning
• Helps maintain correct water flow and pressure to internal valves and spray arms
• Commonly replaced if cracked, blocked, or leaking, which can cause poor wash performance or floor leaks
• Needed when multiple wash zones fail to fill or operate correctly

• Disconnect electrical power and shut off the water supply before starting work
• Inspect and replace any associated seals, O-rings, or clamps if damaged
• Use appropriate tools; avoid overtightening fittings to prevent damage

Secures flexible hoses to fittings on your range to prevent leaks. Replace if connections are loose or clamp is damaged. Verify fit with your model.

Decor frame for gas ranges. Installs around the control panel to provide a finished appearance. Order a replacement if your frame is cracked or damaged.

Replace a damaged or clogged burner jet on your gas range. This small brass component controls gas flow to the burner and may need replacement if cracked or worn.

Replace your range burner jet if it's clogged, damaged, or missing. This small brass component controls gas flow to the burner for proper flame output.

This replacement jet is the small spray nozzle that directs water inside the dishwasher to restore proper spray pattern and improve cleaning performance. It replaces a worn or clogged nozzle to help reduce spotting and uneven wash coverage. What it does:

• Directs water flow from the spray arm to target dishes and cookware
• Helps restore even spray coverage when original nozzle is clogged, cracked, or missing
• Can reduce poor cleaning, streaking, and food residue left on dishes
• Works as a simple wearable component in the dishwasher spray assembly

• Disconnect power and shut off water supply before servicing the appliance
• Access and replace the nozzle per the dishwasher service instructions or parts diagram
• Remove mineral buildup or debris from surrounding spray arm before installing new jet

Mounting clip that secures burners to your gas range cooktop. Replace if rusted, broken, or missing to properly position burners and prevent rattling.

Fix range control issues or power problems with this cable harness. Common fix for unresponsive controls or electrical faults. Moderate DIY repair.

Mounting holder that secures burner assemblies to the cooktop. Replace if cracked, rusted, or missing to restore proper burner positioning and stability.

Mounting clip that secures burners to your gas range cooktop. Replace if rusted, broken, or missing to properly position burners and prevent rattling.

Uneven flame or poor ignition? This burner orifice meters gas flow to create a stable flame. Replace clogged or damaged orifices to restore performance.

Fix weak or uneven burner flames with a new orifice holder assembly. Secures gas flow orifices for proper flame control. DIY-friendly, under 30 minutes.

This gas valve controls the flow of gas to an individual surface burner on a range cooktop. It connects to the burner control knob and regulates flame intensity from low to high settings. Replace this valve if a burner won't ignite, the flame is uneven or won't adjust properly, or you detect a gas smell around the cooktop controls.

This is a gas valve that controls the flow of gas to an individual surface burner on a gas range or cooktop. It connects to the burner control knob and regulates the flame from high to low settings. Replace this valve if a burner will not ignite, the flame cannot be adjusted properly, or you detect a gas smell when the knob is in the off position.

Fixes burner flame issues on gas ranges. Controls gas flow for consistent cooking temperatures. Replacing a worn valve restores precise flame control.

Secures flexible hoses to fittings on your range to prevent leaks. Replace if connections are loose or clamp is damaged. Verify fit with your model.

Restore even baking when your oven heats unevenly. This convection fan blade circulates hot air for consistent cooking. Moderate DIY install.

Replace your worn oven door gasket to restore a tight seal, prevent heat loss, and maintain consistent baking temperatures. Confirm fit with your model number.

Cover sheet for gas ranges. Replaces cracked, damaged, or missing cover panels. Essential cosmetic component that protects internal parts.

This service access cover protects internal components and wiring while keeping the appliance's exterior neat. It restores a clean appearance and helps prevent accidental contact with internal parts during normal use. What it does:

• Protects internal components, connectors and wiring from dust and debris
• Helps reduce risk of accidental contact with electrical parts
• Restores the appliance's finished look after repairs or maintenance
• Useful when replacing or servicing nearby components that require the cover removed

• Disconnect power (unplug or switch off circuit breaker) before starting any work
• Remove and reinstall using the factory mounting clips or screws; avoid forcing the cover to prevent breakage
• Handle plastic tabs gently—inspect tabs and mounting points for damage before final install

This burner tube is used in the broil burner assembly of a gas range, delivering gas to produce the flame needed for broiling. It connects to the gas valve and distributes gas evenly across the burner for consistent heat. Replace this part if you notice uneven broiling, weak or no flame from the broiler, or visible damage such as corrosion or cracks on the tube.

The Sensor is an OEM part for Bosch ovens and ranges. It detects and monitors the actual interior temperature to maintain precise baking and roasting conditions.

Causes of a bad temperature sensor can include wear from prolonged heat exposure within the oven cavity. Physical damage, moisture intrusion or circuitry malfunctions may also lead to sensor failure over time.

Symptoms of a bad oven temperature sensor include:

• Inability to accurately read or achieve set target temperatures
• Fluctuations in readings displayed
• Cooking modes like bake and broil functioning abnormally

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

If your gas range oven won't heat or igniter glows but burner won't light, this igniter likely needs replacement. DIY-friendly repair in minutes.

This grille for pan is a replacement trim piece that restores proper airflow and appearance around the appliance pan. It helps keep the pan area protected and looking finished after repair. What it does:

• Covers and ventilates the pan opening to help direct airflow and prevent debris entry
• Replaces a cracked, warped, or missing grille to restore fit and finish
• Helps eliminate rattling or rubbing caused by a damaged trim piece
• Matches OEM fit so it installs cleanly with the original mounting points

• Install requires removal of the surrounding trim or access panel; follow your appliance manual
• Handle carefully to avoid scratching the finish; use non-marring tools as needed
• Disconnect power to the appliance before working in the service area
• Replace damaged clips or screws with OEM fasteners for secure fit

The Power Module is an OEM part for Bosch ranges and ovens that controls the power supply and operation of your oven. It receives signals from the control panel and relays the appropriate power to various heating elements and components, allowing you to cook.

A bad power module can occur due to electrical surges, component failure, or internal malfunctions. Signs of a faulty board include power irregularities, error codes, or unresponsive controls.

Symptoms of a bad power module include:

• Oven not turning on or heating
• Unresponsive or erratic control panel
• Error codes displayed

Replace your malfunctioning power module with this genuine OEM Bosch part to restore your oven. This Bosch part can also be used on Thermador and Gaggenau appliances.


This Terminal Box is an OEM part for Bosch Built-In Ovens. Integral to the oven's electrical system, this component serves as a secure connection point for various electrical wires within the appliance.

A common issue with a malfunctioning Terminal Box is loose connections or damage to the terminal block due to heat exposure or aging.

Symptoms of a defective Terminal Box may include:

• Inconsistent power supply to the oven
• Non-functional heating elements
• Sparks or electrical arcing within the terminal box area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

The range door hinge plate is the metal bracket that anchors your oven door to the range frame and controls how the door opens and closes. It supports the full weight of the door and keeps it properly aligned. Replace this part if your oven door sags, won't stay open at a set angle, closes unevenly, or feels loose on one side.

Secures internal components and panels to restore proper alignment in your range. Replace when bracket is broken, cracked, or missing to fix loose parts.

Leveling foot for electric and gas ranges. Adjustable metal foot installs at base corner. Replace if cracked, broken, or missing to level your range.

Secures your range door and allows smooth pivoting for proper alignment and seal. Replace if your door won't close fully, sags, or doesn't seat correctly.

Restores smooth rack gliding in your oven. Replace when racks stick, scrape, or don't extend fully. Confirm fit with your model number before ordering.

This is the front facia panel that mounts on the range and houses or surrounds the control knobs and displays. It provides a finished appearance to the control area and helps protect the internal wiring and components behind it. Replace this panel if it is cracked, warped, discolored from heat damage, or if mounting points are broken.

This inner door is the dishwasher's inner panel that supports the door assembly and helps contain water and steam during cycles, restoring a secure, finished door surface. It replaces damaged or corroded inner door panels to improve sealing and appearance. What it does:

• Serves as the interior face of the dishwasher door and provides structural support for inner components
• Helps maintain a watertight seal and prevents leaks from the door area
• Replaces dented, cracked, or corroded inner panels that can trap moisture or cause cosmetic damage
• Restores proper alignment so the door closes and latches correctly

• 1 inner door panel

• Disconnect power and water supply before starting any repair
• Handle panel edges carefully; use gloves to avoid cuts and protect finish
• Installation typically requires removing the outer door panel and disconnecting inner fasteners—keep hardware organized for reassembly

Restores proper door alignment and sealing on gas ranges. Replace when door sags, hangs loose, or won't close tightly. Confirm fit with your model.

Restores proper door alignment and sealing on gas ranges. Replace when door sags, hangs loose, or won't close tightly. Confirm fit with your model.

Replace your range door seal to prevent heat loss and improve cooking efficiency. Install when worn, cracked, or loose. Verify fit with your model number.

This glass front panel is the exterior replacement glass that restores the appliance's finished look and protects the underlying door and control area from scratches and wear. It fits into the door assembly to provide a clean, glossy surface. What it does:

• Replaces cracked, chipped, or heavily scratched front/door glass to restore appearance
• Protects internal components and trim from direct contact and debris
• Helps keep the door surface smooth and easy to clean
• Restores a secure fit when broken or loose glass affects the door finish

• One glass front panel

• Disconnect power to the appliance before starting any repair
• Handle glass with gloves and protective eyewear to avoid cuts
• Installation typically requires removing the door trim or bezel—follow the OEM service instructions for your model

This insulating part provides electrical and thermal isolation for internal appliance components, helping prevent shorting and reducing heat transfer where wiring or terminals meet sensitive parts. Use it to restore safe operation after damage or wear. What it does:

• Provides electrical insulation for terminals, connectors, or wiring to prevent shorts and arcing
• Reduces heat transfer between hot components and nearby wiring or plastic parts
• Helps maintain safe clearances and protects against chafing or contact-related failures
• Commonly replaced when cracked, melted, burned, or otherwise compromised

• One insulating part

• Always disconnect power (unplug appliance or switch off breaker) before servicing
• Verify correct orientation and seating; do not force the part into place
• Inspect surrounding wiring and terminals; replace any damaged connectors or wires

Replace a damaged heat shield causing nearby components to overheat or melt. This protective panel restores the heat barrier on your gas range.
