Parts for Bosch HGS5052UC/01: Side Panels / Drawer Parts

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

This sealing ring creates a watertight seal in the dishwasher pump/motor area to help prevent leaks and protect the motor assembly. It's a small but essential replacement for worn or damaged seals. What it does:

• Seals pump housing joints to stop water leaks beneath the dishwasher
• Helps maintain proper water pressure and circulation for cleaning performance
• Prevents water from reaching the motor and electronics, reducing risk of damage
• Replaces brittle, cracked, or flattened seals that commonly cause under-unit leaks

• One sealing ring

• Turn off power and water to the appliance before starting any repair
• Inspect mating surfaces and clean away debris or buildup before installing the new ring
• Lubricate the seal lightly with OEM-recommended lubricant or a thin film of water if needed to ease installation
• If multiple seals or gaskets show wear, replace them together to ensure a complete seal.

This selector knob lets you choose the cooktop/oven function with a simple twist, restoring reliable tactile control and clear position feedback for precise operation. Replace a cracked, faded, or loose knob to regain safe, confident use. What it does:

• Rotates to select the oven or cooktop function and provides tactile position feedback
• Replaces a cracked, worn, or loose knob that's hard to turn or won't stay set
• Helps restore accurate function selection when markings are faded or missing
• Matches original fit and mounting style for straightforward replacement

• Disconnect power to the appliance before servicing for safety
• Most knobs pull straight off the shaft; align and press the replacement onto the control post
• If the knob uses a set screw, loosen/tighten with the correct screwdriver; avoid overtightening
• Test function selection after installation to ensure proper fit and operation

This mounting bracket secures appliance components in place to restore proper alignment and stability. It's a simple replacement part that helps reduce rattling and supports correct panel or assembly positioning. What it does:

• Secures a panel or assembly to the appliance frame to prevent movement and vibration
• Restores proper alignment for doors, panels, or internal components
• Helps stop rattling, noises, or loose components that occur when a support bracket fails
• Provides a direct mechanical replacement—no electrical function

• One replacement mounting bracket

• High-level: remove power and water to the appliance before starting repairs
• Use basic hand tools; keep fasteners from the original part for reinstallation unless new ones are supplied
• If the bracket mounts a door or heavy panel, support the panel during removal and reinstallation to avoid damage

The Burner Cap is an OEM part for Bosch Ranges. This part fits atop the burner assembly, playing a vital role in controlling and diffusing the flame for cooking.

A common issue with a malfunctioning or worn-out Burner Cap involves deterioration over time due to exposure to heat, grease, or cleaning agents. Damage or deformation to the cap can disrupt the flame pattern, leading to inefficient cooking or inconsistent heat distribution.

Symptoms of a defective Burner Cap may include:

• Uneven or erratic flames during burner operation
• Inadequate heat output or difficulties in achieving desired temperatures
• Visible signs of damage or wear on the burner cap's surface

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This burner housing secures the surface burner assembly on compatible gas cooktops and ranges, restoring proper burner alignment and stable flame performance. It replaces damaged or warped housings that cause burner wobble or inconsistent ignition. What it does

• Supports and positions the burner head and cap for correct flame pattern
• Aligns the igniter/electrode and maintains clearance from other components
• Helps prevent burner wobble, misalignment, and uneven heating
• Use when housing is cracked, corroded, bent, or otherwise damaged

• Shut off gas supply and power to the appliance before starting work
• Remove grates and burner caps to access the housing; keep track of fasteners
• Replace with the exact OEM part and secure fasteners without over-tightening

The Burner Cap is an OEM component for Bosch Ranges. This crucial part fits atop the burner assembly, playing a vital role in controlling and diffusing the flame for cooking.

A common issue with a malfunctioning or worn-out Burner Cap involves deterioration over time due to exposure to heat, grease, or cleaning agents. Damage or deformation to the cap can disrupt the flame pattern, leading to inefficient cooking or inconsistent heat distribution.

Symptoms of a defective Burner Cap may include:

• Uneven or erratic flames during burner operation
• Inadequate heat output or difficulties in achieving desired temperatures
• Visible signs of damage or wear on the burner cap's surface

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This burner housing secures and positions the cooktop's top burner components for stable ignition and even heat. Replacing a damaged housing restores proper burner alignment and helps prevent loose parts that affect flame performance. What it does:

• Holds the top burner head, igniter, and related components in the correct position
• Maintains proper alignment for reliable ignition and a steady flame
• Replaces bent, cracked or corroded housings that can cause loose burner parts or irregular flame
• Works with existing burner caps, heads, and igniters

• Turn off the appliance and disconnect gas and power before servicing
• Inspect and replace any worn gaskets, seals, or fasteners when reinstalling

This burner cap covers the gas burner head to help direct flame for even cooking and protect the burner assembly from spills and debris. Simple replacement restores proper flame shape and helps maintain safe operation. What it does:

• Centers and shields the burner head so flames distribute evenly across cookware
• Helps prevent food and liquid from entering the burner ports and clogging them
• Supports stable ignition by keeping the flame pattern consistent
• Can help reduce irregular or uneven flame appearance when damaged or misaligned

• Turn off gas supply and let cooktop cool completely before handling
• Lift off the old cap, clean the burner head and surrounding area, then set the new cap in place so it seats flat and centered
• No special tools required; ensure the cap is not rocking and does not block ignition ports
• If ignition problems persist after replacement, inspect burner ports and igniter for debris or damage

This burner housing is the metal mounting and enclosure that secures a gas burner and its ignition components, restoring proper burner alignment and stable flame control for safe cooking. Use to replace worn, rusted, or damaged housings. What it does:

• Holds and positions the burner head, electrode/igniter, and associated fittings for correct ignition and flame shape
• Shields and directs gas flow around the burner for consistent combustion
• Prevents burner wobble and helps maintain safe clearances between the flame and appliance cabinet
• Commonly replaced when the housing is bent, corroded, cracked, or causing ignition/misfire issues

• One burner housing assembly

• Turn off gas supply and disconnect power to the appliance before beginning work
• Only attempt installation if you are comfortable with gas appliance repair
• Inspect and replace any worn gaskets, screws, or mounting hardware as needed; ensure proper alignment of the igniter/electrode
• After installation, check for gas leaks and verify correct ignition and flame behavior before normal use

This replacement grill grid restores a flat, stable cooking surface so food cooks evenly and stays off the burner. Designed to fit compatible Bosch countertop grills and grilling modules for reliable performance. What it does:

• Provides a stable, heat-resistant surface for grilling and searing foods
• Keeps food elevated above the burner for even heat distribution
• Replaces bent, warped, or damaged grill surfaces that cause uneven cooking
• Helps prevent food from falling into the burner area during use

• One grill grid

• For safety, disconnect power and allow appliance to cool completely before removing or installing the grid
• Handle with care—edges may be sharp and surfaces hot after recent use
• Slide or position the grid into the existing support rails; no special tools typically required

Replacement holder used to secure internal parts inside the appliance, restoring proper positioning to reduce rattling and help components remain aligned during normal operation and improve reliability. What it does:

• Holds internal components or assemblies in place to prevent unwanted movement.
• Reduces vibration and rattling that can occur during operation.
• Helps maintain correct alignment of parts that can affect function or contact.
• Common symptom: loose or moving parts and audible noise during use.

• Disconnect power to the appliance before beginning any work; shut off water supply if the repair involves water-connected models.
• Use basic hand tools; keep track of screws and clips removed during service.
• Refer to the appliance's service manual or parts diagram for correct location and orientation.

This replacement holder secures internal components in compatible Bosch appliances to restore proper alignment and reduce noise from loose parts. It's a simple swap that helps maintain reliable operation and prevents shifting or rattling. What it does

• Secures and positions internal components or assemblies to keep them stable during operation
• Helps stop rattling, vibration noise, and misalignment caused by a worn or broken holder
• Restores part fit where clips or supports no longer hold components firmly
• Resolves symptoms such as loose panels, shifting trays, or intermittent contact caused by a failing holder

• One replacement holder

• Disconnect power (and water supply where applicable) before servicing the appliance
• Inspect mating surfaces and fasteners; replace any damaged screws or clips for a secure fit
• Install with the original hardware where possible; use only manufacturer-recommended parts

The Orifice Holder Assembly is an OEM part for Bosch gas ranges. It securely holds the orifice which regulate gas flow to each burner, allowing flame levels to be finely tuned during cooking.

Causes can include deformation from overheating, damage or wear to the small orifice holes. Exposure to water or food debris may also lead to blockage over time.

Symptoms of a bad orifice holder include:

• Inability to properly adjust or maintain burner flame levels
• Uneven or irregularly sized flames between burners
• Gas leaks or flames that fluctuate excessively

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This jet meters gas to the burner on your cooktop or range to produce a stable, properly sized flame. Replace a clogged, damaged, or stripped jet to restore consistent gas flow and reliable ignition.

• Meters gas from the valve to the burner for correct flame size and shape
• Helps resolve issues like burners not lighting or producing weak/uneven flames
• Replaces jets with damaged threads or internal blockage
• Supports safe, consistent burner performance when the original jet is compromised

• Disconnect power and shut off gas supply before servicing; allow unit to cool
• Use the correct wrench to remove and install the jet; do not overtighten
• Install in the correct burner position
• After reassembly, check all connections with an approved leak-detection solution

This cable harness is the wiring assembly that links dishwasher controls and internal components, restoring reliable electrical connections and helping resolve intermittent or failed component operation. Designed to replace a damaged or corroded factory harness. What it does

• Routes power and signals between the control board and internal parts so components can operate correctly
• Replaces broken, frayed, or corroded wires that cause intermittent power or communication failures
• Helps address symptoms such as devices not powering, erratic operation, or components that work intermittently
• Maintains correct wire routing and connector fit to prevent shorting or loose connections

• One cable harness assembly as shown

• Disconnect power to the appliance before starting any repair
• Compare the harness and connector shapes to the original before installation to ensure correct fit
• Handle connectors by the housings; avoid pulling on individual wires

This water inlet valve controls the flow of water into the appliance so cycles fill when needed and stop to prevent overfilling. Replaces a worn or failed inlet valve to restore reliable water fill operation. What it does:

• Opens and closes to allow water into the appliance during fill cycles
• Works with the control board and float/sensors to prevent overfill
• Common repair for no-fill, slow-fill, or continuous-fill symptoms
• Helps stop leaks caused by valves that fail to fully close

• Turn off power and shut off the water supply before starting
• Drain residual water and relieve pressure from the line before disconnecting
• Inspect and replace any worn inlet hoses, clamps, or seals during installation
• Test cycles and check for leaks after installation

This water inlet valve controls dishwasher water flow during fill cycles, restoring proper filling and preventing overfill. Replace a faulty valve to stop no-fill, slow-fill, or continuous-fill issues and restore normal wash cycles. What it does:

• Opens and closes to admit water into the dishwasher during fill cycles
• Maintains correct water flow and pressure for proper wash performance
• Stops water flow if inlet fails closed or prevents filling if stuck open
• Common symptom link: dishwasher won't fill, fills slowly, or shows error/overflow conditions

• One water inlet valve

• Disconnect power and shut off the water supply before starting
• Turn off the breaker; water and electrical safety first
• Basic hand tools typically required; keep track of hose clamps and fittings
• Inspect inlet hoses and gaskets and tighten or replace clamps as needed

The Valve is an OEM replacement part for Bosch gas ranges. Responsible operation delivers controlled flames through burners. Consistent cooking depends on precise regulation.

Causes of a bad valve can include wear from constant adjustments opening and closing fuel pathways thousands of times. Exposure to ambient heat and residual grease vapors also accelerates component decline over several years.

Symptoms of a bad valve include:

• Inability to modulate burner output properly for recipes
• Unstable pilot lights or sudden extinguishing during operation
• Gas buildups resulting in unpredictable combustion tendencies
• Failures illuminating control panels or kitchens with leak warnings

This OEM Bosch part is also compatible with Siemens or Gaggenau models.

This manifold directs and distributes incoming water to the appliance's internal wash circuits, restoring proper water routing for consistent cleaning performance. Replaces a worn or damaged manifold to stop leaks and restore normal fill and spray operation. What it does:

• Channels incoming water to the dishwasher's spray and circulation system for even cleaning
• Helps maintain correct water flow and pressure to internal valves and spray arms
• Commonly replaced if cracked, blocked, or leaking, which can cause poor wash performance or floor leaks
• Needed when multiple wash zones fail to fill or operate correctly

• Disconnect electrical power and shut off the water supply before starting work
• Inspect and replace any associated seals, O-rings, or clamps if damaged
• Use appropriate tools; avoid overtightening fittings to prevent damage

This clamp secures flexible hoses and small tubes to fittings, keeping connections tight to help prevent leaks and movement. It's a small replacement clip used on water and drain lines in many appliances. What it does

• Holds a hose or tube firmly to a barb or nipple to maintain a sealed connection
• Helps stop leaks caused by loose or damaged hose connections
• Prevents hoses from slipping off during operation and reduces vibration noise
• Used wherever a small retaining clamp is required on water or drain lines

• One clamp

• Turn off power and shut off water supply before replacing the clamp
• Slide clamp over the hose, push hose fully onto the fitting, then compress or tighten clamp as required
• Use pliers or the correct tool for the clamp type; avoid damaging the hose when installing
• Replace if corroded, cracked, or not seating properly

This replacement jet is the small spray nozzle that directs water inside the dishwasher to restore proper spray pattern and improve cleaning performance. It replaces a worn or clogged nozzle to help reduce spotting and uneven wash coverage. What it does:

• Directs water flow from the spray arm to target dishes and cookware
• Helps restore even spray coverage when original nozzle is clogged, cracked, or missing
• Can reduce poor cleaning, streaking, and food residue left on dishes
• Works as a simple wearable component in the dishwasher spray assembly

• Disconnect power and shut off water supply before servicing the appliance
• Access and replace the nozzle per the dishwasher service instructions or parts diagram
• Remove mineral buildup or debris from surrounding spray arm before installing new jet

This replacement holder secures internal components in compatible Bosch appliances to restore proper alignment and reduce noise from loose parts. It's a simple swap that helps maintain reliable operation and prevents shifting or rattling. What it does

• Secures and positions internal components or assemblies to keep them stable during operation
• Helps stop rattling, vibration noise, and misalignment caused by a worn or broken holder
• Restores part fit where clips or supports no longer hold components firmly
• Resolves symptoms such as loose panels, shifting trays, or intermittent contact caused by a failing holder

• One replacement holder

• Disconnect power (and water supply where applicable) before servicing the appliance
• Inspect mating surfaces and fasteners; replace any damaged screws or clips for a secure fit
• Install with the original hardware where possible; use only manufacturer-recommended parts

Replacement holder used to secure internal parts inside the appliance, restoring proper positioning to reduce rattling and help components remain aligned during normal operation and improve reliability. What it does:

• Holds internal components or assemblies in place to prevent unwanted movement.
• Reduces vibration and rattling that can occur during operation.
• Helps maintain correct alignment of parts that can affect function or contact.
• Common symptom: loose or moving parts and audible noise during use.

• Disconnect power to the appliance before beginning any work; shut off water supply if the repair involves water-connected models.
• Use basic hand tools; keep track of screws and clips removed during service.
• Refer to the appliance's service manual or parts diagram for correct location and orientation.

This replacement holder secures internal components in compatible Bosch appliances to restore proper alignment and reduce noise from loose parts. It's a simple swap that helps maintain reliable operation and prevents shifting or rattling. What it does

• Secures and positions internal components or assemblies to keep them stable during operation
• Helps stop rattling, vibration noise, and misalignment caused by a worn or broken holder
• Restores part fit where clips or supports no longer hold components firmly
• Resolves symptoms such as loose panels, shifting trays, or intermittent contact caused by a failing holder

• One replacement holder

• Disconnect power (and water supply where applicable) before servicing the appliance
• Inspect mating surfaces and fasteners; replace any damaged screws or clips for a secure fit
• Install with the original hardware where possible; use only manufacturer-recommended parts

This jet meters gas to the burner on your cooktop or range to produce a stable, properly sized flame. Replace a clogged, damaged, or stripped jet to restore consistent gas flow and reliable ignition.

• Meters gas from the valve to the burner for correct flame size and shape
• Helps resolve issues like burners not lighting or producing weak/uneven flames
• Replaces jets with damaged threads or internal blockage
• Supports safe, consistent burner performance when the original jet is compromised

• Disconnect power and shut off gas supply before servicing; allow unit to cool
• Use the correct wrench to remove and install the jet; do not overtighten
• Install in the correct burner position
• After reassembly, check all connections with an approved leak-detection solution

The Orifice Holder Assembly is an OEM part for Bosch gas ranges. It securely holds the orifice which regulate gas flow to each burner, allowing flame levels to be finely tuned during cooking.

Causes can include deformation from overheating, damage or wear to the small orifice holes. Exposure to water or food debris may also lead to blockage over time.

Symptoms of a bad orifice holder include:

• Inability to properly adjust or maintain burner flame levels
• Uneven or irregularly sized flames between burners
• Gas leaks or flames that fluctuate excessively

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This water inlet valve controls dishwasher water flow during fill cycles, restoring proper filling and preventing overfill. Replace a faulty valve to stop no-fill, slow-fill, or continuous-fill issues and restore normal wash cycles. What it does:

• Opens and closes to admit water into the dishwasher during fill cycles
• Maintains correct water flow and pressure for proper wash performance
• Stops water flow if inlet fails closed or prevents filling if stuck open
• Common symptom link: dishwasher won't fill, fills slowly, or shows error/overflow conditions

• One water inlet valve

• Disconnect power and shut off the water supply before starting
• Turn off the breaker; water and electrical safety first
• Basic hand tools typically required; keep track of hose clamps and fittings
• Inspect inlet hoses and gaskets and tighten or replace clamps as needed

This water inlet valve controls the flow of water into the appliance so cycles fill when needed and stop to prevent overfilling. Replaces a worn or failed inlet valve to restore reliable water fill operation. What it does:

• Opens and closes to allow water into the appliance during fill cycles
• Works with the control board and float/sensors to prevent overfill
• Common repair for no-fill, slow-fill, or continuous-fill symptoms
• Helps stop leaks caused by valves that fail to fully close

• Turn off power and shut off the water supply before starting
• Drain residual water and relieve pressure from the line before disconnecting
• Inspect and replace any worn inlet hoses, clamps, or seals during installation
• Test cycles and check for leaks after installation

The Valve is an OEM replacement part for Bosch gas ranges. Responsible operation delivers controlled flames through burners. Consistent cooking depends on precise regulation.

Causes of a bad valve can include wear from constant adjustments opening and closing fuel pathways thousands of times. Exposure to ambient heat and residual grease vapors also accelerates component decline over several years.

Symptoms of a bad valve include:

• Inability to modulate burner output properly for recipes
• Unstable pilot lights or sudden extinguishing during operation
• Gas buildups resulting in unpredictable combustion tendencies
• Failures illuminating control panels or kitchens with leak warnings

This OEM Bosch part is also compatible with Siemens or Gaggenau models.

This clamp secures flexible hoses and small tubes to fittings, keeping connections tight to help prevent leaks and movement. It's a small replacement clip used on water and drain lines in many appliances. What it does

• Holds a hose or tube firmly to a barb or nipple to maintain a sealed connection
• Helps stop leaks caused by loose or damaged hose connections
• Prevents hoses from slipping off during operation and reduces vibration noise
• Used wherever a small retaining clamp is required on water or drain lines

• One clamp

• Turn off power and shut off water supply before replacing the clamp
• Slide clamp over the hose, push hose fully onto the fitting, then compress or tighten clamp as required
• Use pliers or the correct tool for the clamp type; avoid damaging the hose when installing
• Replace if corroded, cracked, or not seating properly

This door seal restores a tight barrier between the oven door and cavity. Replacing a worn gasket helps your oven reach and hold temperature, reduces heat escaping at the door edges, and supports more consistent baking and roasting results.

• Creates a heat-resistant seal around the oven opening
• Helps the oven preheat and maintain set temperature
• Limits heat, steam, and odors from escaping at the door
• Typical signs it needs replacement: visible tears or flattening, heat felt around the door, longer preheat/cook times, or uneven baking

• Disconnect power at the breaker and let the oven cool completely
• Open the door, pull the old seal from its channel, and clean the groove
• Press the new seal evenly into the channel without stretching; ensure corners seat fully
• Close the door to verify uniform contact all around and adjust as needed

This service access cover protects internal components and wiring while keeping the appliance's exterior neat. It restores a clean appearance and helps prevent accidental contact with internal parts during normal use. What it does:

• Protects internal components, connectors and wiring from dust and debris
• Helps reduce risk of accidental contact with electrical parts
• Restores the appliance's finished look after repairs or maintenance
• Useful when replacing or servicing nearby components that require the cover removed

• Disconnect power (unplug or switch off circuit breaker) before starting any work
• Remove and reinstall using the factory mounting clips or screws; avoid forcing the cover to prevent breakage
• Handle plastic tabs gently—inspect tabs and mounting points for damage before final install

This replacement surface burner restores proper heat delivery on compatible cooktops, letting you cook reliably and maintain even heat across cookware. Designed to match the original burner shape and mounting for straightforward replacement. What it does

• Provides the cooking surface where gas/heat contacts cookware for normal operation
• Replaces a cracked, warped, or damaged burner that causes uneven heating
• Fixes burners that fail to ignite or produce an irregular flame when the valve is working
• Restores safe, stable flame pattern and consistent cooking performance

• One replacement burner

• Turn off power and gas supply before removing or installing the burner; follow all safety precautions
• Remove grates and any trim to access mounting screws or clips; keep track of fasteners
• Compare the new burner to the old one for correct size and burner port arrangement before installing
• If you smell gas after installation, shut off supply, ventilate the area.

The Sensor is an OEM part for Bosch ovens and ranges. It detects and monitors the actual interior temperature to maintain precise baking and roasting conditions.

Causes of a bad temperature sensor can include wear from prolonged heat exposure within the oven cavity. Physical damage, moisture intrusion or circuitry malfunctions may also lead to sensor failure over time.

Symptoms of a bad oven temperature sensor include:

• Inability to accurately read or achieve set target temperatures
• Fluctuations in readings displayed
• Cooking modes like bake and broil functioning abnormally

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Ignition Device is an OEM component specifically designed for Bosch gas ranges. This device is responsible for generating the spark needed to reliably light the burners on the cooktop.

Symptoms of a faulty ignition device include:

• Inconsistent or intermittent burner ignition
• Small flames that do not spread fully across burners
• Complete failure of one or more burners to light
• Burners extinguishing unexpectedly during use

Causes of ignition device problems tend to be worn over time from repeated use. Exposure to moisture, residue buildup, or physical impacts can also potentially damage sensitive electronic components.

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore gas ranges and cooktops.

This grille for pan is a replacement trim piece that restores proper airflow and appearance around the appliance pan. It helps keep the pan area protected and looking finished after repair. What it does:

• Covers and ventilates the pan opening to help direct airflow and prevent debris entry
• Replaces a cracked, warped, or missing grille to restore fit and finish
• Helps eliminate rattling or rubbing caused by a damaged trim piece
• Matches OEM fit so it installs cleanly with the original mounting points

• Install requires removal of the surrounding trim or access panel; follow your appliance manual
• Handle carefully to avoid scratching the finish; use non-marring tools as needed
• Disconnect power to the appliance before working in the service area
• Replace damaged clips or screws with OEM fasteners for secure fit

The Power Module is an OEM part for Bosch ranges and ovens that controls the power supply and operation of your oven. It receives signals from the control panel and relays the appropriate power to various heating elements and components, allowing you to cook.

A bad power module can occur due to electrical surges, component failure, or internal malfunctions. Signs of a faulty board include power irregularities, error codes, or unresponsive controls.

Symptoms of a bad power module include:

• Oven not turning on or heating
• Unresponsive or erratic control panel
• Error codes displayed

Replace your malfunctioning power module with this genuine OEM Bosch part to restore your oven. This Bosch part can also be used on Thermador and Gaggenau appliances.


This Terminal Box is an OEM part for Bosch Built-In Ovens. Integral to the oven's electrical system, this component serves as a secure connection point for various electrical wires within the appliance.

A common issue with a malfunctioning Terminal Box is loose connections or damage to the terminal block due to heat exposure or aging.

Symptoms of a defective Terminal Box may include:

• Inconsistent power supply to the oven
• Non-functional heating elements
• Sparks or electrical arcing within the terminal box area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This hinge is the OEM replacement that supports and pivots your appliance door for proper alignment and smooth opening. Replacing a worn hinge restores correct door fit and helps prevent sagging or binding. What it does:

• Provides a pivot point for the appliance door to open and close smoothly
• Maintains door alignment and seal to help prevent leaks or uneven gaps
• Worn or damaged hinges can cause the door to sag, rub, or close unevenly
• Matches OEM fit and mounting points for direct replacement

• Disconnect power and water before inspecting or replacing door hardware
• Support the door during removal to prevent dropping or damage
• Compare new hinge to the old part for correct orientation and mounting before final installation
• Tighten fasteners securely but avoid over-torquing; test door operation after installation

This replacement mounting bracket secures internal components and panels to restore proper alignment and stability. Use it when a broken or missing bracket causes loose parts, noise, or improper panel fit on compatible units. What it does

• Holds and supports adjacent panels or assemblies to maintain correct alignment.
• Prevents movement that can cause rattling, vibration noise, or scraping.
• Restores stable mounting for parts that may sag or sit unevenly.
• Helps ensure smooth operation by keeping components in their intended position.

• One mounting bracket

• Disconnect power before starting any repair to avoid electrical hazards.
• Basic hand tools are typically required; handle brackets carefully to avoid bending.
• Do not overtighten fasteners—secure snugly to avoid stressing the bracket.

The Foot is an OEM component specifically designed for Bosch freestanding and slide-in electric ranges. Constructed of rugged cast metal, anti-tip brackets stabilize cooking operation. Even weight distribution protects floors.

Causes of a broken foot commonly relate to impacts during moving or cleaning. Prolonged use weakens mounting clips requiring timely replacement.

Symptoms of a bad foot include:

• Instability raising tip-over hazards
• Major leaning endangering cooktop surfaces
• Loosening raising noise concerns

Causes of a bad foot can involve stress fractures from overloading or excessive slide-outs. Corrosion inhibits secure fastening necessitating replacment.

This OEM Bosch part is also compatible with some Thermador, Dacor, and Lynx ranges maintaining dependable positioning and anti-tilt protection over years of use. Replace for uninterrupted cooking confidence.


This door hinge secures and lets the appliance door pivot smoothly, restoring proper alignment and seal for reliable operation. Use this hinge to replace a worn, bent, or broken door pivot that prevents the door from seating correctly. What it does:

• Provides a stable pivot point so the door opens and closes smoothly
• Restores correct door alignment to improve sealing and reduce air leaks
• Stops door sagging, binding, or uneven gaps when mounting hardware has failed
• Prevents rubbing or unusual noises from a loose or damaged hinge

• One door hinge

• Disconnect power to the appliance and remove contents from the door before servicing
• Support the door while removing and installing the hinge to avoid damage or injury
• Tighten fasteners securely to the manufacturer's torque recommendations; replace any worn screws

This slide restores smooth in-and-out movement for a dishwasher rack by replacing worn or damaged sliding hardware. It helps racks glide evenly for easier loading and unloading and reduces sticking, scraping or unexpected drops. What it does:

• Guides and supports a dishwasher rack as it extends and retracts
• Replaces cracked, worn or stiff slides that cause a rack to stick, tilt or catch
• Reduces scraping, uneven travel and noisy operation
• Fits into the existing rack guide assembly to restore proper rack alignment

• Disconnect power to the appliance before servicing and remove the rack to access the slide
• Typically installs by sliding or snapping into the rack guide; retain or reuse any original fasteners if present
• After installation, verify the rack moves smoothly and is properly aligned

A replacement storage drawer that restores usable under-appliance or interior storage space and smooth sliding operation. Replaces damaged, cracked, or worn drawers to keep stored items safe and accessible. What it does:

• Provides a removable tray for storing cookware, utensils, or food items depending on the appliance configuration
• Restores smooth in-and-out sliding action when original drawer was broken or warped
• Keeps contents secured and organized to prevent shifting during use
• Helps maintain appliance appearance by replacing a damaged or discolored drawer

• One replacement drawer assembly

• Disconnect power to the appliance before servicing to reduce shock risk
• Remove any contents and slide out the old drawer; note rail alignment for reassembly
• Align the replacement drawer on the guides or rollers and slide in until it seats; secure any screws or clips removed
• Test full travel and closure; do not force if resistance is felt—recheck alignment

This inner door is the dishwasher's inner panel that supports the door assembly and helps contain water and steam during cycles, restoring a secure, finished door surface. It replaces damaged or corroded inner door panels to improve sealing and appearance. What it does:

• Serves as the interior face of the dishwasher door and provides structural support for inner components
• Helps maintain a watertight seal and prevents leaks from the door area
• Replaces dented, cracked, or corroded inner panels that can trap moisture or cause cosmetic damage
• Restores proper alignment so the door closes and latches correctly

• 1 inner door panel

• Disconnect power and water supply before starting any repair
• Handle panel edges carefully; use gloves to avoid cuts and protect finish
• Installation typically requires removing the outer door panel and disconnecting inner fasteners—keep hardware organized for reassembly

This hinge kit restores proper door alignment and smooth opening/closing on compatible Bosch appliances. It replaces worn or damaged hinge components so the door seals and operates correctly. What it does:

• Replaces damaged or worn door hinge parts to stop sagging or uneven gaps
• Restores smooth hinge movement and reduces scraping or grinding noises
• Helps the door close fully to maintain an effective seal
• Addresses door misalignment that can cause uneven wear or poor sealing

• One hinge kit

• Turn off power to the appliance and disconnect water before starting
• Support the door while removing and installing the hinge to avoid injury or damage
• Use basic hand tools and follow the OEM service manual or diagram for correct placement and torque

This hinge kit restores proper door alignment and smooth opening/closing on compatible Bosch appliances. It replaces worn or damaged hinge components so the door seals and operates correctly. What it does:

• Replaces damaged or worn door hinge parts to stop sagging or uneven gaps
• Restores smooth hinge movement and reduces scraping or grinding noises
• Helps the door close fully to maintain an effective seal
• Addresses door misalignment that can cause uneven wear or poor sealing

• One hinge kit

• Turn off power to the appliance and disconnect water before starting
• Support the door while removing and installing the hinge to avoid injury or damage
• Use basic hand tools and follow the OEM service manual or diagram for correct placement and torque

This glass front panel is the exterior replacement glass that restores the appliance's finished look and protects the underlying door and control area from scratches and wear. It fits into the door assembly to provide a clean, glossy surface. What it does:

• Replaces cracked, chipped, or heavily scratched front/door glass to restore appearance
• Protects internal components and trim from direct contact and debris
• Helps keep the door surface smooth and easy to clean
• Restores a secure fit when broken or loose glass affects the door finish

• One glass front panel

• Disconnect power to the appliance before starting any repair
• Handle glass with gloves and protective eyewear to avoid cuts
• Installation typically requires removing the door trim or bezel—follow the OEM service instructions for your model

This insulating part provides electrical and thermal isolation for internal appliance components, helping prevent shorting and reducing heat transfer where wiring or terminals meet sensitive parts. Use it to restore safe operation after damage or wear. What it does:

• Provides electrical insulation for terminals, connectors, or wiring to prevent shorts and arcing
• Reduces heat transfer between hot components and nearby wiring or plastic parts
• Helps maintain safe clearances and protects against chafing or contact-related failures
• Commonly replaced when cracked, melted, burned, or otherwise compromised

• One insulating part

• Always disconnect power (unplug appliance or switch off breaker) before servicing
• Verify correct orientation and seating; do not force the part into place
• Inspect surrounding wiring and terminals; replace any damaged connectors or wires

This heat shield is a replacement protective panel that helps block and deflect heat away from nearby components for safer operation and longer component life. It restores the original heat barrier where a damaged or missing shield allows excess heat exposure. What it does:

• Deflects and disperses heat away from wiring, insulation, and nearby plastic or sensitive parts
• Prevents heat-related charring, warping, or premature failure of adjacent components
• Reduces the risk of hot spots that can cause burning smells or visible scorch marks
• Restores the appliance's original thermal protection when the existing shield is bent, corroded, or missing

• One heat shield panel

• Always disconnect power (and gas if applicable) before servicing the appliance
• Handle carefully—edges may be sharp; wear gloves and eye protection
• Verify proper orientation and secure all fasteners to restore original clearance and airflow
