Parts for Ge PT7050DF9BB: Door Parts

This door liner kit replaces a damaged or worn refrigerator door interior to restore a clean, sealed surface and improve door appearance. Designed to fit the OEM mounting points for a proper fit and reliable performance. What it does:

• Replaces cracked, warped, stained or otherwise damaged door liner surfaces
• Restores a smooth interior surface to help door shelves and bins mount correctly
• Helps maintain a consistent door seal by providing a true mounting surface for gaskets and hardware
• Improves overall appearance of the refrigerator door interior

• Disconnect power to the appliance before beginning service
• Remove door shelves, bins, and any trim before removing the old liner
• Retain and reuse any existing screws, clips, or hardware unless replacements are provided in the kit

This door insulation retainer is a small plastic clip that secures insulation inside a refrigerator/freezer door to help maintain proper temperature and reduce noise. It replaces worn or missing retainers to keep the door liner insulation in place. What it does:

• Secures the door insulation to the inner door liner so insulation stays positioned
• Helps prevent insulation from shifting or sagging that can affect door seal performance
• Commonly used when insulation falls out or the liner shows gaps around the insulation
• Works as a direct-fit replacement for the original retainer designed for the door assembly

• One door insulation retainer clip

• Installation generally requires removing the door panel or liner; keep track of fasteners and trim
• Handle the door liner and insulation carefully to avoid damage or tearing the insulation
• Use proper tools and disconnect power if working near electrical components or lights
• Replace all affected clips for an even, secure fit

A replacement liner support that secures the refrigerator cabinet liner and keeps interior trim and panels aligned for a proper seal and appearance. Restores stability to cracked or broken support points. What it does:

• Holds the cabinet liner and interior trim in position to prevent gaps and movement
• Helps maintain door seal alignment by keeping liner edges stable
• Reduces rattling or shifting caused by a damaged support
• Commonly replaced when liner pieces are cracked, broken, or loose

• One liner support

• Disconnect power to the appliance before beginning any repair
• Remove food, shelves, and trim pieces as needed to access the damaged support
• This part typically secures with clips or fasteners; inspect existing hardware and replace if necessary

The Oven door gasket is an OEM part for GE wall ovens and ranges. It fits around the inner rim of the oven door, creating an essential heat and air seal when closed.

Symptoms of a bad door gasket include:

• Excessive heat loss around the door when preheating or cooking
• Ghosting or condensation buildup visible on the door glass
• Worn or misshapen gasket that no longer presses firmly against the door rim

Gasket material naturally hardens over time through repeated exposure to temperature changes. Accidental damage from cleaning can also impact the gasket's integrity. Replacing it with this genuine GE part helps maintain an efficient cooking environment.

This OEM GE replacement gasket is also compatible with some Kenmore, Hotpoint, and RCA wall oven and range models. Proper sealing is important for energy efficiency as well as consistent cooking results.


This black replacement handle restores a clean, secure grip to the appliance door for safer opening and closing. It matches the original form and finish to keep the door functional and looking factory-correct. What it does:

• Replaces a worn, cracked, or broken door handle to restore secure operation
• Provides a sturdy grip so the door opens and closes smoothly
• Helps prevent accidental drops or slippage from a damaged handle
• Maintains the appliance's original appearance with a factory-style finish

• Basic hand tools typically required; for instructions
• Power off and unplug the appliance (or turn off breaker) before beginning work
• Handle with care to avoid scratching the finish; align mounting points before tightening
• Reuse original screws or order separately

This outer door assembly restores the exterior of the oven with a finished black outer panel and frame, returning the unit's look and protection. Fits as the complete outer door piece to replace damaged or worn exterior doors. What it does:

• Replaces a cracked, dented or cosmetically damaged oven outer door panel
• Restores the door's exterior finish and helps protect internal door components
• Works with existing inner glass and hardware when undamaged
• Helps eliminate light drafts or visible gaps caused by a bent or warped outer panel

• Disconnect power to the appliance before starting any repair
• Outer door assemblies can be heavy or awkward—use two people when removing/reinstalling
• Handle glass areas carefully; do not overtighten fasteners to avoid cracking inner glass
• Follow OEM service manual instructions for safe removal/installation and to verify any needed additional parts

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

The Window Pack Assembly is an OEM part for GE ovens. This component includes the oven door window and its associated parts, providing visibility into the oven cavity during cooking. It helps retain heat within the oven while allowing users to monitor the cooking process without opening the door.

Causes of a bad window pack assembly can include thermal stress from repeated heating and cooling, accidental impact, or general wear and tear. A damaged window can compromise the oven's efficiency and safety by allowing heat to escape.

Symptoms of a bad window pack assembly include:

• Cracks or damage to the window glass
• Heat escaping from the oven door
• Condensation or discoloration between the window panes
• Difficulty seeing through the window during cooking

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

ST10-16 X 7/16"

Black. 8-18 AB HXW 3/8

Includes 12 washers.

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This hex-washer-head screw secures appliance components and panels. The correct 10-16 thread, 1-inch length fastener restores a tight, factory fit when an original screw is missing, stripped, or corroded.

• Fastens brackets, shields, trim, or panels to the appliance chassis
• Helps resolve rattling, gaps, or loose parts caused by a missing/damaged screw
• 10-16 thread with 1-inch length matches factory hardware for specified locations
• Hex-washer head provides solid tool engagement and distributes load to protect surfaces

• Disconnect power before servicing; if working on a gas appliance, also shut off the gas supply
• Support the part being secured and align holes before tightening
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing
• Replace any additional missing screws in the same area for uniform support
