Parts for Ge GDE23ESEARSS: Doors Parts

This bracket support is a small mounting bracket that secures and stabilizes appliance components, helping keep panels and assemblies aligned for proper operation and reduced vibration. It's a direct-fit replacement when the original bracket is broken or missing. What it does

• Provides a sturdy mounting point to hold panels or internal components in place
• Restores proper alignment to doors, panels or assemblies that sit on the bracket
• Reduces rattling or vibration caused by a loose or damaged bracket
• Helps prevent wear or damage from parts shifting during use

• Unplug the appliance and shut off water/gas (if applicable) before starting work
• Use the original mounting screws; replace damaged fasteners as needed
• Handle sharp sheet-metal edges carefully and wear gloves and eye protection

This is a 1/4-20 UNC machine screw used to fasten appliance components securely. It restores proper fit and stability where threaded fasteners are required, preventing loose panels or shifting parts. What it does:

• Secures panels, brackets, or assemblies that use a 1/4-20 UNC threaded hole
• Stops rattling or movement caused by a missing or damaged screw
• Restores correct mechanical connection for safe operation
• Useful when replacing stripped, corroded, or lost fasteners

• Disconnect power to the appliance before servicing.
• Start threads by hand to avoid cross-threading; tighten until snug.
• Do not overtighten — use appropriate torque for the material to avoid stripping threads or damaging parts.
• Ensure proper contact and secure fastening.

This refrigerator door gasket forms an airtight seal between the door and cabinet. Replacing a worn or warped gasket restores proper sealing to improve temperature control, reduce frost and condensation, and help your fridge run efficiently.

• Creates a continuous seal around the door perimeter to prevent air leaks
• Helps maintain consistent temperatures and humidity inside the compartment
• Reduces frost, ice, and condensation caused by warm air infiltration
• Common symptoms: tears or warping, visible gaps/light, door not closing fully or popping open, excess frost or moisture

• Unplug the refrigerator before servicing
• Lay the gasket flat and warm it with hot water or gentle heat to relax folds; do not overheat
• Remove the old gasket and press the new one fully into the retainer channel, starting at the corners
• Close the door and check for uniform contact all around; reseat or adjust hinges if needed

This freezer handle assembly replaces a worn or broken handle on your refrigerator's freezer. The arc-style design restores a secure, comfortable grip and the original look so you can open the freezer confidently again.

• Provides the handhold needed to open and close the freezer
• Direct replacement when the handle is cracked, loose, or missing
• Restores a solid feel if the original handle wobbles or won't stay tight
• Refreshes appearance when the original handle is scuffed or marred

• Disconnect power and wear cut-resistant gloves to protect hands and finish
• Support the handle while loosening/tightening hardware; use the correct driver for your model
• Reuse existing studs/brackets unless they are damaged; align and tighten evenly
• Do not overtighten fasteners to avoid stripping threads or cracking the handle

This replacement screw fastens refrigerator components securely, restoring a tight, rattle-free fit when original hardware is missing, stripped, or corroded. Use it to secure panels, brackets, or trim and keep parts properly aligned.

• Secures panels, brackets, covers, or trim in place
• Helps maintain correct alignment of components and hardware
• Reduces vibration and rattling caused by loose or missing screws
• Replaces lost, rusted, or stripped screws

• Unplug the refrigerator and turn off water supply if working near water components
• Match thread and length to the removed fastener; hand-start threads to avoid cross-threading
• Tighten snugly; do not overtighten into plastic or thin sheet metal
• Keep track of any spacers or washers reused from the original assembly

A replacement lower right bracket that secures and supports the lower section of the assembly for proper alignment and stable operation. Restores the original mounting point to reduce sagging and movement. What it does:

• Provides a secure mounting point for the appliance's lower assembly so panels, doors or components stay aligned
• Helps prevent sagging, rattling or uneven gaps caused by a damaged or missing bracket
• Maintains correct part-to-frame spacing so connected components operate smoothly
• Fits into the OEM mounting locations and matches factory attachment points

• Disconnect power to the appliance before attempting any repair to avoid shock or injury
• Requires basic hand tools; keep fasteners from the original bracket for reinstallation unless replacements are provided
• Hand-tighten fasteners, then snug to manufacturer torque recommendations—do not overtighten to avoid stripping

This replacement screw secures appliance brackets, panels, and components. It restores a tight, aligned fit when the original hardware is stripped, rusted, or missing, helping reduce vibration and rattling for reliable operation.

• Fastens brackets, panels, or mounts to keep components secure and aligned
• Replaces missing, stripped, or corroded hardware
• Helps reduce vibration, rattling, or loose/misaligned parts
• Matches original spec for reliable hold and fit

• Disconnect power before servicing; use proper PPE
• Match thread and length to the removed screw before installation
• Start threads by hand to prevent cross-threading; tighten until snug—do not overtighten
• Ensure parts are aligned and seating surfaces are clean before tightening

2 Per Kit

2 Per Kit

The Lower Freezer Basket is an OEM replacement part for GE refrigerators designed to fit in the lower section of the freezer, providing a convenient storage area for your frozen items.

A bad lower freezer basket can occur due to regular wear and tear or damage from mishandling. If you notice symptoms such as cracks, broken parts, or difficulty in sliding the basket in and out, it may indicate a need to replace the basket.

Symptoms of a bad lower freezer basket include:

• Cracked or broken basket
• Difficulty in sliding the basket in and out
• Uneven or limited storage space

Restore your refrigerator's freezer section by replacing the faulty lower freezer basket with this genuine OEM part.

This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


The Arc Handle is an OEM part for GE refrigerators. This handle provides a comfortable and secure grip for opening and closing the refrigerator door.

Causes of a bad handle can include general wear and tear, repeated use, or accidental impact.

Symptoms of a bad arc handle include:

• Loose or wobbly handle
• Cracks or visible damage on the handle
• Difficulty in opening or closing the refrigerator door
• Handle detaching from the door

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Fastener Door Handle is an OEM component for GE refrigerators. This door handle provides a comfortable grip for accessing refrigerator shelves and bins. It attaches securely to the refrigerator door through durable metal fasteners.

Causes for a bad door handle could be cracks, damage, or stripped fastener holes resulting in a loose or detached handle. Regularly gripping and lifting may also cause normal wear over time.

Symptoms of a failing door handle include:

• The handle detaching completely from the door
• Looseness making the handle wobbly or unstable to hold
• Sharp edges or broken parts posing a safety risk

This OEM GE handle is also compatible with Hotpoint, RCA, and select Kenmore refrigerator models.

This 8-18 x 9/16 screw is a short sheet-metal fastener used to secure panels, trim and small components on appliances. It replaces missing or stripped screws to restore proper fit and reduce noise from loose parts. What it does

• Secures appliance panels, brackets and trim to prevent movement and rattling
• Holds small components in correct alignment for reliable operation
• Replaces lost, worn or stripped screws that cause gaps or loose fittings
• Common symptom link: fixes rattling panels, loose trim, or parts that shift during use

• One 8-18 x 9/16 screw

• Use the correct 8-18 driver bit and hand or low-torque power driver to avoid stripping
• Do not overtighten; snug until secure to prevent thread damage or panel deformation
• Turn power off/unplug appliance when installing near electrical components
• Keep extra screws on hand—hardware often comes in single quantities

This set screw secures refrigerator components—most commonly door handles—to their mounting studs. Replacing a missing or stripped screw restores a solid, secure feel and helps prevent loose or wobbly handles.

• Locks the handle to its mounting stud to keep it tight and secure
• Helps resolve a loose, wobbly, sliding, or rattling handle
• Replaces a missing, rounded, or damaged set screw
• Helps maintain proper handle alignment and consistent door operation

• Unplug the appliance or switch off power before servicing
• Ensure the handle is fully seated on the studs before tightening
• Start the screw by hand to avoid cross-threading; then tighten until snug
• Do not overtighten to prevent stripping the screw or handle threads
