Parts for Ge ZIPS360NHA: Doors Parts

The water filter is an OEM part for GE refrigerators. This filter removes or reduces various contaminants.

Features and Benefits:

• Easy DIY replacement, typically mounted inside the refrigerator at the back of the compartment.
• Removes or reduces various contaminants in your water and ice, including lead, cysts, asbestos, atrazine, , taste and odor, chlorine, sediment, turbidity, and more
• NSF/ANSI 42 and 53 standards
• 6 Month lifespan filter
• Carbon Block media
• Micron rating: 0.5-1 micron (Class I)

When to replace your filter:

• Bad taste or odor in water and ice
• Cloudy or discolored ice
• Reduced water flow or pressure
• Refrigerator replace filter indicator light is on

Note: If replacing the Culligan metal canister design filter for the first time, a special adapter, part number AP2615702 is needed, which is not included with this part. The compatible bypass cap is part number AP6891551.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This bracket and bumper assembly secures and cushions the refrigerator door hinge to keep the door aligned and closing smoothly. It replaces worn or broken hinge hardware to restore proper door fit and reduce closing noise. What it does:

• Supports the door hinge mounting and keeps the hinge correctly positioned
• Provides a rubber bumper surface to prevent metal-on-metal contact and absorb impact
• Helps maintain door alignment and an even gap for a proper seal
• Commonly used when the door hangs unevenly, binds, or makes noise while closing

• One bracket and bumper assembly

• Disconnect power to the appliance before starting any work
• Support the door while removing hinge fasteners to prevent the door from shifting or falling
• Use basic hand tools; remove any trim or shelves only if they obstruct access
• After installation, check door alignment and adjust as needed

Size: 10-32 GXTT FLP.595 S

This replacement door gasket seals the refrigerator door to help maintain proper temperature and reduce moisture buildup. It restores a tight seal so your fridge runs more efficiently and keeps food fresher. What it does:

• Creates an airtight seal around the door to help prevent cold air loss and reduce energy waste
• Helps stop warm air and moisture from entering the compartment, limiting frost and condensation
• Reduces temperature swings that can cause food spoilage
• Addresses common symptoms like warm interior temperatures, excess frost build-up, or a door that feels drafty

• One replacement door gasket

• Designed for direct replacement; inspect the door frame and mounting channel before installing
• Clean the gasket channel and let adhesives or sealer dry fully if previously used
• Seat the gasket evenly around the door, checking for gaps; warm the gasket slightly if needed to aid fit
• Always unplug the appliance or disconnect power before servicing

This replacement fresh-food door gasket seals the refrigerator compartment to help keep cool air in and reduce energy loss. Restores an airtight seal so the refrigerator maintains proper temperature and efficiency. What it does:

• Replaces a worn, cracked or torn fresh-food door seal that lets warm air in
• Helps stop condensation and frost buildup around the door edge
• Reduces excessive compressor run time caused by leaking seals
• Restores proper door closure and consistent internal temperatures

• One fresh-food door gasket

• Inspect door frame and magnetic strip for damage before installing the new gasket
• Clean mounting surface and allow to dry for best adhesion and fit
• Seat the gasket evenly around the door, working corners last; trim only if manufacturer documentation explicitly permits
• Disconnect power or follow appliance safety instructions if removing interior door components

This foam-filled freezer door panel provides the insulated inner surface that helps maintain cold temperatures and supports interior components. It replaces a damaged or worn inner door to help reduce frost buildup and improve cooling efficiency. What it does:

• Replaces the freezer's insulated inner door panel to restore proper insulation and structural support.
• Helps reduce temperature loss and potential frost accumulation when the outer door closes correctly.
• Supports door-mounted bins and shelves that attach to the inner panel.
• Common symptoms addressed: visible damage to the inner panel, soft or deformed door surface, or increased frost inside the freezer compartment.

• Disconnect power to the appliance before beginning any repair to avoid electrical shock.
• Installation typically requires removing the outer door trim and fastening hardware; handle the panel carefully to avoid damaging the foam core or mounting tabs.
• Inspect door gaskets and mounting hardware during replacement; replace any damaged components to ensure a proper seal.

The Freezer Drawer Gasket is an OEM replacement part for GE refrigerators. It serves as a critical seal between the freezer drawer and the refrigerator cabinet, preventing cold air from escaping and warm air from entering the freezer compartment.

Symptoms of a need to replace the freezer drawer gasket:

• Frost buildup or condensation inside the freezer compartment
• Difficulty opening or closing the freezer drawer due to a poor seal
• Visible gaps, cracks, or damage to the gasket material
• Gasket feeling brittle or not sealing properly when the drawer is closed

Causes of a faulty freezer drawer gasket can include general wear and tear over time, exposure to extreme temperatures, damage from mishandling or improper cleaning, and loss of flexibility or brittleness of the material.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore refrigerator models.

This is a #10-32 x 3/4 truss-head screw designed to fasten small appliance panels and components securely. It replaces missing or worn fasteners to restore stable mounting and reduce rattles or movement. What it does:

• Secures trim, control panels, brackets, and small assemblies
• Restores tight mounting to stop panel vibration or rattling
• Keeps electrical and mechanical components properly aligned
• Works where a #10-32 machine screw with a short 3/4" length and truss head is required

• Disconnect power before working on the appliance
• Use the correct screwdriver or nut driver to avoid stripping the head
• Tighten until secure; avoid over-tightening which can strip threads or crack plastic
• Keep removed hardware organized for reinstallation

This euro standoff kit provides the mounting hardware used to secure trim panels and components on compatible appliances, restoring proper panel alignment and preventing rattles or loose trim. It's a direct-fit replacement for the listed part number. What it does:

• Replaces worn or damaged mounting standoffs that hold panels or trim in place
• Restores secure panel attachment to reduce vibration, rattling, or misalignment
• Helps maintain proper spacing between panels and cabinet for correct fit and finish
• Designed to match the original part's fit and function for reliable repair

• Disconnect power to the appliance before servicing to avoid shock or injury
• Remove affected trim/panel carefully to access standoffs; retain screws and hardware
• Install standoffs in the original locations and tighten screws until snug — do not overtighten
• If alignment issues persist after replacement, check adjacent clips, fasteners, and mounting surfaces

This screw set contains #10-32 thread fasteners used to secure appliance panels and components. It provides direct-fit replacement screws to restore proper fastening and stop loose or rattling parts. What it does:

• Replaces missing or damaged #10-32 screws used on appliances
• Secures panels, brackets, trim pieces, and internal components
• Helps eliminate rattling, vibration noise, and loose fittings
• Restores factory fastening for safe, stable operation

• Disconnect power and water before servicing the appliance
• Keep small parts organized and use a magnetic tray to avoid loss
• Use the correct driver to avoid stripping screw heads; do not overtighten

This part is the door handle made for a refrigerator unit. The purpose of this handle is to provide a solid component that the user can pull to open the refrigerator door. Over time and with repeated use, this component may begin to show signs of wear and tear. The door handle can be replaced for cosmetic purposes. The door handle is simply held on with screws and is very easy to replace. A screwdriver will be needed to perform the replacement process for this refrigerator door handle. The person performing the replacement may wish to wear work gloves to protect the hande during this process.This particular white door handle is compatible with refrigerators that are manufactured by General Electric. It is sold individually. This high-quality and durable part is sourced directly from the manufacturer.

This Euro-style freezer door handle kit replaces a damaged or worn handle so the freezer door opens and closes securely. It restores a clean, finished look and reliable grip for everyday use. What it does:

• Replaces a broken, cracked or loose freezer door handle to restore proper opening and closing
• Provides a secure grip that helps prevent accidental drops or slippage when opening the freezer
• Matches the slim Euro-style profile used on many modern freezer doors for a consistent appearance
• Helps eliminate rattling or movement caused by damaged mounting points

• One Euro-style freezer door handle kit with fasteners

• Disconnect power to the appliance before beginning work and follow the manufacturer's safety guidelines
• Use basic hand tools; avoid overtightening fasteners which can crack trim or strip threads
• Support the door while removing and installing the handle to prevent stress on hinges or seals
