Parts for Lg DLEX8100W: Drawer Panel And Guide Parts

This water tank assembly holds and delivers chilled water to the dispenser and ice system, restoring proper water flow and preventing dispenser dry-running. Direct-fit replacement designed to match the original reservoir's form and function. What it does

• Stores and supplies water for the refrigerator dispenser and ice-making components.
• Replaces cracked or damaged reservoirs that cause leaks or loss of water supply.
• Helps resolve intermittent or no-water dispense when the tank is compromised.
• Works with the refrigerator's fill and drain pathways to maintain correct water levels.

• One water tank assembly

• Disconnect power and shut off the water supply before servicing.
• Drain remaining water from the lines and tank to avoid spills during removal.
• Handle the tank carefully to avoid damaging fittings or mounting tabs.
• After installation, restore water and power, then check connections and test for leaks and proper dispense/ice fill.

Restore reliable steam performance to your washer. This steam generator assembly heats water to create steam for steam-enabled wash cycles, helping improve cleaning and fabric care when the original unit has failed or scaled up.

• Produces steam used during designated steam wash cycles
• A failing unit can cause little/no steam output or cycles to end early when steam is selected
• Replacing the assembly can resolve steam-related performance issues

• Disconnect power and water; allow the appliance and generator to cool completely before service
• Access location varies by model; note wire and hose routing for correct reassembly
• Transfer and secure any hoses/fittings; use proper clamps and check all connections
• After installation, run a steam cycle and inspect for proper operation and leaks

The DC pump motor assembly powers the pump that moves water through your appliance. Replacing a worn motor helps restore proper water flow so cycles can complete and reduces issues like standing water and excessive noise.

• Drives the pump impeller to move water for draining or circulation, as designed by the appliance
• Supports proper cycle completion by clearing water from the tub or sump
• Common symptoms of a failing motor include standing water, incomplete draining/circulation, loud humming or grinding near the pump, or cycle errors
• May run intermittently, stall, or overheat as internal components wear

• Disconnect power and turn off the water supply before servicing
• Expect residual water; protect the area with towels or a shallow pan
• Note wiring connectors and hose routing; transfer any brackets, grommets, or seals from the original as needed
• Secure hose clamps and test for leaks while running a brief test cycle

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.
