Parts for Husqvarna YTH2348-917287561: Drive Parts

This is a greaseable mandrel kit, also called a blade spindle assembly. It is the part of a riding lawnmower where the blade assembly fits. It's attached to the bottom of the engine with four self-tapping screws, which assure the stability of the spindle when the blades are turning. The mandrel assembly is a part of the riding mower that is intentionally meant to be the most breakable. This is by design, so the other, more expensive, more challenging to repair parts are spared. As a result, mandrels often need to be replaced. If you have to replace the mandrel, first take off the blade assembly and the mandrel cover. After removing the nut holding the pulley in place, remove the pulley. From there, it’s just a matter of unscrewing the four bolts holding the mandrel to the cutting deck. Replace the original mandrel with the new unit and walk back through the disassembly instructions. This is a genuine OEM part manufactured by Husqvarna and Poulan. The mandrel is also compatible with Ariens, Dixon, and Craftsman. This OEM part is sold individually.

This is an idler pulley meant to be used on many brands of lawn tractor or mower. It is designed to create tension on the drive belt, and it can wear with years of use or be damaged by a blow to the mower deck or by an over-accumulation of debris that causes it to become jammed. To repair or replace this genuine OEM part, it requires pliers and a wrench. The steps used include removing the mower deck, removing the bolt securing the pulley and drive belt, removing the washer and bolt from the pulley, and replacing it with a new one. Then, the original or a new belt can be installed before the mower deck is restored. This parts fits with mowers, trimmers, and tractors sold by brands like Husqvarna, Poulan, Weed Eater, and Jonsered. It ships individually and is made of durable plastic.

This is a genuine OEM replacement that is designed for use with riding lawn mowers. This idler pulley helps drive the engine of the Lawn Mower. This part experiences a lot of constant motion, which can cause it to wear over time. It can also become damaged due to an impact or in the course of other repairs, which would require a replacement. This genuine OEM part features a 3/8-inch mounting hole and 3.5-inch exterior diameter, and includes a one-year warranty and can provide a replacement for compatible engines. This OEM idler pulley is manufactured by Husqvarna and designed to be compatible with select machines from the brand, as well as brands like Poulan, Weed Eater, and Jonsered. It is made of durable plastic with a metal bushing and fitting and will provide an exact replacement fit for hundreds of compatible engines. This part is sold individually and does not include any necessary hardware. Ensure that the engine is cool and gloves are worn for hand protection when replacing this part.

This replacement part is a spring. This is a genuine replacement part made by Husqvarna. This spring is used to connect multiple parts together and provide tension and torque within the engine so that the parts may operate smoothly. A new spring might be needed if the current one is stripped or worn down. It is common for springs to snap over time due to the amount of pressure they experience on a regular basis. If this is the case, it is best to replace this part as soon as possible. Wear work gloves when repairing or replacing this part to ensure the safety of those in the vicinity. This is a genuine OEM replacement part. This part is sold individually and is sourced directly from the manufacturer.

A hex screw can be used on a variety of different types of lawn and garden equipment. On small machines, it can be used to hold the housing together while on larger machines, it might be used to mount on the gas tank. It's versatile with the ability to secure items including wood, plastic, metal, and brick together. The screw is made of high-quality metal and measures 5/16-18 x ¾ inches. Sometimes these screws can become stripped, get damaged, or even break and will need to be replaced.Inspect the screw for any damage, looseness, or debris that might be causing issues. If the damage is major or the screw is stripped, it will need to be replaced. In most cases, the screw can be removed using nothing more than a screwdriver before inserting the replacement screw. For stripped screws, pliers may be needed to get the original screw out of the equipment.This hex screw is a genuine OEM replacement part sourced directly from the manufacturer. It is sold individually. The screw is compatible with lawnmowers, string trimmers, snowblowers, and tillers by Craftsman, Ariens, Husqvarna, Poulan Pro, Weed Eater, and Poulan.

This is a bellcrank ground drive intended for use with riding mowers, tractors, and trimmers. The bellcrank ground drive employs the idler pulleys when the pedal brake control shaft assembly is pressed. A new bellcrank may be needed if the original was faulty, or if it becomes significantly worn through general operation of the machinery. However, installation of a new bellcrank is relatively simple. Only a few tools will be required when replacing this item, including: a socket set, a set of pliers and a hex wrench. The removal of the mower deck will also be required. The user should refer to their owner's manual for guidance regarding their specific model.This is an OEM part sourced directly from the manufacturer. It is sold individually. The bellcrank ground drive is designed for use in Husqvarna, Poulan, Weed Eater, and Jonsered models.

This part is a replacement clutch link. This is a genuine OEM part made by Husqvarna and has been sourced directly from the manufacturer. This part can be used to replace a defective or broken clutch link in a variety of lawn tractor models. The clutch link is a critical component's clutch, which allows the user to switch gears. This part will need to be replaced if broken, bent, dented, snapped, or rendered ineffective in any way. When working on or near an enginee, it is important to ensure the equipment is powered down and completely cool before beginning repairs. For more accurate information on how and where to place this clutch link, the appropriate owner's manual and equipment diagrams should be referred to. As an authentic replacement part, this clutch link is suitable for use on lawn tractors manufactured by Husqvarna, Poulan, and other brands. Please note that this is a genuine part made of high-quality, durable metal and is sold individually.

This transaxle belt keeper is a genuine Husqvarna part, sold individually. This transaxle belt keeper can be used as a replacement part in a lawn mower. This part maintains the position of the transaxle belt.If the belt frequently slips out of place or the belt keeper is detached from the transaxle altogether, the transaxle belt keeper should be removed and replaced by this genuine OEM replacement part. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. Always unplug the appliance before performing any kind of repair or replacement.Sourced directly from the manufacturer, this component is a genuine replacement part that is sold individually. This transaxle belt keeper is compatible with the following outdoor appliance brands: Husqvarna and Craftsman.

This genuine OEM replacement washer is a specially hardened washer to provide more support for a wide range of different lawn appliances. Washers are usually used in conjunction with a nut and a bolt and act as a barrier between those two parts. Washers help to redistribute pressure to prevent the bolt from giving out over time, as well as to provide a stronger grip. Washers can begin to corrode over time, and when this happens, the washer can fuse together with the bolt or nut. This would make the connection difficult to disengage in the case of a bigger repair. It is good practice, then, to replace washers anytime the nut or bolt is also replaced. This way, all parts age at the same rate and will not have to be individually changed out. Use a wrench to unthread the nut and change out a washer. This part is a top of the line replacement washer for a Husqvarna, Weed Eater, Ryobi, Jonsered, or Poulan engine. It comes sourced from the original manufacturer and does not include any other hardware.
