Parts for Kenmore 911.99003991 (91199003991, 911 99003991): Fan Parts

This oven door gasket restores a tight seal between the door and oven cavity, helping the oven heat efficiently and bake evenly. Replace a worn or damaged seal to stop heat loss and temperature swings.

• Seals the gap between the oven door and front frame to retain heat and maintain set temperature
• Can help resolve heat escaping around the door and uneven or extended bake times
• Common failure signs: tears, fraying, brittleness, or permanent flattening of the gasket
• Supports consistent preheat and recovery performance

• Disconnect power or shut off gas and allow the oven to cool completely
• Open the door and remove the old gasket from its retaining holes or channel; clean the area
• Align the new gasket and press the retainer ends into the mounting holes evenly—do not stretch the seal
• Close the door to check fit; a short preheat can help the new gasket seat

The Element Convx is an OEM part for GE ovens. This convection element is designed to provide consistent and even heat distribution within the oven, ensuring optimal cooking and baking results. It typically works in conjunction with the convection fan to circulate hot air evenly throughout the oven cavity.

Causes of a bad convection element can include regular wear and tear, electrical surges, or damage from physical impact. A malfunctioning element can lead to uneven cooking, longer preheating times, and overall reduced oven performance.

Symptoms of a bad convection element include:

• Uneven cooking or baking results
• The oven not reaching the set temperature
• Longer than usual preheating times
• The convection fan operating without generating heat

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

ST10-16 X 7/16"

This is a genuine OEM replacement nut that is used on convection oven fans. This nut holds the fan onto the spindle. If the nut becomes lost during repairs to the fan, it will need to be replaced before the fan will work. This nut locks the fan to the spindle to turn and move the air around inside the oven. The fan helps the food to cook more evenly and reduces areas in the oven that are not cool enough or hot enough. If the fan is not working, the convection oven will not cook correctly.Convection ovens are different from regular ovens, and the fan is part of the reason. Convection ovens use the fan and an exhaust system to move the heat around inside the oven to cook food more evenly and faster. Many convection ovens have a setting that allows the oven to be used as a regular oven. If the nut is missing and the fan is inoperable, the oven can be used for regular cooking if it has this feature. Otherwise, the convection oven should not be used until the nut is replaced.This nut is a silver metal replacement part that is sold individually. It is designed for use in convection ovens made by GE and Kenmore.
