Frigidaire 807022404 Control Board (Electronic) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dishwasher Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 807022404 replaces AP6025907, 807022403, 4452853, 807022402, PS11758324.

Description

This electronic control board governs the dishwasher's cycles and overall operation. Replacing a failed board can restore proper cycle selection, start-up, and progress so the appliance runs reliably again. What it does

• Orchestrates cycle timing and switching of internal components
• Processes inputs from sensors and the door switch to manage operations
• Communicates with the user interface/console and status indicators
• Failure symptoms include: won't start, unresponsive controls, cycles that pause or won't advance, random beeping, or error codes

What's included

• One electronic control board

Install notes

• Disconnect power at the breaker before servicing; verify no power is present
• Use ESD precautions; handle the board by the edges only
• Photograph/label connectors and transfer them one at a time to the new board without forcing pins
• Inspect wiring and the door switch/harness for damage before reassembly and testing
