Frigidaire 134197700 Burner Assembly, Gas Dryer OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dryer Burner & Related and Washer Dryer Combo Burner & Related.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 134197700 replaces AP3557518, 1036252, 7134197700, AH815519, EA815519, PS815519.

Description

This burner assembly restores proper gas flame and heat in your dryer. It directs and mixes gas and air for clean ignition at the igniter, helping clothes dry efficiently and consistently.

• Provides the flame path and mixing chamber for gas ignition
• Helps resolve symptoms like no heat, intermittent heat, or very long dry times
• Can address issues where the burner won't ignite or the flame will not stay lit
• Designed to fit the factory burner mount and align with the igniter and flame sensor

What's included: One complete burner assembly as supplied by the manufacturer. Installation notes:

• Disconnect power and shut off gas supply before servicing; allow the appliance to cool
• Access is typically from the front lower panel or burner compartment
• Transfer any reusable hardware from the original assembly if required
• After reassembly, restore gas and check all connections for leaks using a soapy water solution
