Frigidaire 809160305 Control Board (Main Oven Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dryer Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160305 replaces AP5948942, 137260130, 3515939, PS9865098.

Description

This main electronic control board manages oven functions and user commands so your range responds correctly to temperature settings, timers, and cooking modes. Replaces a failed board to restore control and display operation. What it does:

• Receives input from the front control panel and regulates oven heating cycles and timers
• Controls bake, broil and other cooking modes by sending power signals to heating elements
• Can cause a blank display, unresponsive touchpad/buttons, or failure to start if defective
• May trigger control-related error codes or intermittent operation when malfunctioning

What's included: One main electronic control board Install notes:

• Disconnect power at the breaker or unplug the appliance before any service
• Handle the board carefully; avoid static discharge and contact with circuit traces
• Basic appliance disassembly and wire-labeling required; verify connections match before reassembly
