Frigidaire 809160903 Control Board (Main Electronic Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dryer Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 809160903 replaces AP5950035, 137260600, 3515954, PS10057459.

Description

Main electronic control board that manages an appliance's functions, timing and user interface. Replacing this circuit board restores proper operation when controls fail, the display is blank, or cycles run erratically. What it does:

• Interprets user inputs (buttons/knobs/touchpad) and sends commands to the appliance's systems
• Controls timing, sequencing and power to motors, valves, heaters and sensors
• Drives the display and status indicators so cycle information and error messages appear correctly
• Common symptoms: unresponsive controls, no display, appliances that won't start or that run unpredictably

What's included: One electronic control board. Install notes:

• Disconnect all power before handling or replacing the board to avoid shock or damage
• Handle the circuit board by the edges and avoid touching components; static discharge can damage electronics
• Confirm harness connectors seat fully and match the OEM connector locations during reassembly
